Step 6: Assembly of the handlebar covers
Secure the covers (U1 and
U2) to the handlebar (T) with
two screws (W3). Repeat this
process for the other side.
Step 7: Assembly of the hand grips
Remove the screws (O7) from the console mast (O) and the screw (S3) from the hand
grip (S). Connect the cable from the hand grip (S5) to the sensor cable (O6). Insert the
hand grips (S) into the console mast (O) and twist the grips together. Secure the hand
grips with two screws (O7) and one screw (S3).
Use tool
16
T
U2
S3
S
O6
U1
Handlebar clip
S5
O7
W3
W3
S3
O
O7
