2.3 Header Information

As outlined in Table 2-1, header J1 provides connections to the low-voltage side of the SENSE capacitors
(corresponding to the SENSE pins of the IC), the low-voltage side of the inject capacitor, the IC bias power
supply (VDD and GND pins), which is set between 8 V and 16 V, and a remote enable (EN) signal.
(1)
POSITION LABEL
1 EN
2 VDD
3 INJ
4 GND
5 S1
6 S2
(1) Pin positions of header J1 are designated right to left when viewed from the top side of the EVM.
(2) Working at an ESD-protected workstation, verify that any wrist straps, bootstraps or mats are connected and referencing the user to
Earth ground before power is applied to the EVM.
A 6-pin right-angle header, part number TSW-106-08-G-S-RA, connects the EVM to a corresponding female
receptacle, part number SSW-106-01-G-S, which mounts on the EMI filter board that carries the passive filter
components – the CM chokes, X-capacitors and Y-capacitors – as well as the sense and inject capacitors. The
EVM includes both the header and the receptacle, manufactured by Samtec. See
2.4 EVM Performance Validation
1. Connect the EVM to the filter board (see receptacle J2 in
2. Apply a VDD bias supply voltage of 8 V to 16 V (nominal 12 V, with ripple voltage less than 20 mV
peak-to-peak) between the VDD and GND terminals of J1.
3. Measure the voltage at the INJ pin of the TPSF12C1 (pin 13) with respect to GND; a DC voltage of V
and have no AC perturbations that indicate instability. The VDD current consumption must be approximately
12 mA. If the INJ pin voltage is oscillating, modify the damping network components on the EVM to achieve
stability.
4. The user must perform low-voltage testing prior to connecting the high-voltage power stage. To provide a
CM stimulus, connect a 5-V peak-to-peak square-wave source from a function generator as shown in
2-4. Set the signal frequency to the switching freqeuncy of the power stage and choose a duty cycle that
creates all the spectral harmonics (aside: 50% duty cycle eliminates the even harmonics, 33.3% removes
the triple-n harmonics, and so forth). A 1-nF capacitor in series with the signal source emulates a practical
CM noise source impedance.
• Using this CM excitation source, verify the dynamic voltage range of the TPSF12C1 INJ pin. Ensure that
the INJ pin voltage relative to GND operates in a window between 2.5 V and V
5. Connect a LISN on each input power line and measure the EMI with AEF disabled (EN tied to GND) to
benchmark the existing passive filter. Short the low-voltage (bottom) terminal of the inject capacitor to GND
when AEF is disabled by tying the INJ terminal on J1 to GND. This emulates the Y-capacitor connection in
an equivalent passive filter design.
6. Remove the pulldown short on the inject capacitor and enable the AEF circuit by allowing EN to float high.
Repeat the EMI measurement, thus quantifying the EMI reduction with AEF.
7. In a similar fashion, perform a comparison of filter insertion loss or attenuation performance using a network
analyzer. For a true insertion loss measurement with 50-Ω source and load impedances, replace the LISN by
a 50-Ω load tied from L or N to GND.
8. Using high-voltage safety precautions, connect the switching power stage as shown in
regulator ON and, similar to step 4, verify that the IC's INJ pin voltage is not getting clipped. To improve the
dynamic range of the INJ voltage, increase one or more of the following:
• Regulator-side Y-capacitance, C
• Inject capacitance, C
• VDD supply voltage, V
9. Measure the EMI with AEF enabled and disabled, similar to the procedure outlined in steps 5 and 6.
10. Turn the regulator OFF. Wait for all high-voltage capacitors to fully discharge.
