STEP1, STEP2, STEP3
ERR 1, ERR 2, ERR 3, ERR 4
The options and descriptions in the Setpoint directory are shown in the following table:
Options
PV
SV
Setpoint source
HART Setpoint input
The options and descriptions in the Status directory are shown in the following table:
Options
Working status
Cutoff status
Working status signs and descriptions are shown in the following table:
Signs
NOINI
Config mode
Auto mode
Manu mode
Cutoff status signs and descriptions are shown in the following table:
Signs
No
Cutoff down
Cutoff up
8.5. Feedback signal
The positioner can be optionally equipped with a 4-20 mA feedback signal. It indicates the
percentage value of the valve position.
The feedback signal module is based on a two-wire system, it needs 24V DC power supply. The
feedback signal will stop updating after entering the menu.
Intelligent Valve Positioner IP6000 Series User's Manual
Initialization steps.
Initialization error message.
Device dynamic variable.
Device dynamic variable.
Set the setpoint source. Can be set to 4-20mA or HART, the default is
4-20mA.
When set to 4-20mA, the setpoint value is determined by the external
4-20mA signal. When set to HART, the setpoint value is determined by
the input value from HART communication.
The HART Setpoint input option is jumped out from the directory. It is
used to enter the setpoint value.
Enter the setpoint value if Setpoint source is set to HART.
System working status.
Cutoff status in automatic mode.
The system is not initialized.
The system is in menu configuration mode.
The system is in automatic mode.
The system is in manual mode.
The system is not in cutoff status.
Cutoff status corresponds to C MIN.
Cutoff status corresponds to C MAX.
Description
Description
Description
Description
