8.4. HART DD file description
8.4.1. Device dynamic variable description
Dynamic variable
PV
SV
8.4.2. Device custom function description
The device custom function is in the Detailed setup directory of the DD file. The function options
and descriptions are shown in the following table:
Options
TYPE See chapter 8.3.2.1 for details.
INIT Automatic initialization start or stop, initialization status indication.
For the initialization function, please refer to Chapter 8.3.2.2 and Chapter
8.3.2.3.
SDIR See chapter 8.3.2.5 for details.
CHAR See chapter 8.3.2.6 for details.
FREE See chapter 8.3.2.7 for details.
DB See chapter 8.3.2.8 for details.
LIM See chapter 8.3.2.9 for details.
YDIR See chapter 8.3.2.10 for details.
CUT See chapter 8.3.2.11 for details.
Setpoint Setpoint value setting.
Status System status indication.
The options and descriptions in the INIT directory are shown in the following table:
Options
INIT status Initialization status indication.
INIT start Automatic initialization starts.
INIT stop Automatic initialization stops.
INIT status signs and descriptions are shown in the following table:
Signs
NOINI
FINSH
Intelligent Valve Positioner IP6000 Series User's Manual
point of the linear
feedback lever
Position setpoint percentage value
Position percentage value
Uninitialized.
Initialization finish.
Description
Description
Description
Description
