8.3.2.13. FACT
All setting parameters in the menu reset to factory default values.
Select this function in the menu interface, press and hold
factory setting. Then the system is in an uninitialized state and the LCD displays FINSH.
8.3.2.14. WP
This function is a parameter write protection function. The parameter oFF is write protection
disabled, and the parameter on is write protection enabled.
Select this function in the menu interface, press
flash. Press buttons to set parameter and press
When the write protection is enabled, menu options 1-13 are not operational.
8.3.2.15. ACT
This function is used to set acting mode. It is used for the manufacturer. It is not recommended for
users to operate this option without special circumstances.
8.3.2.16. REF
Calibrate the reference point of the linear feedback lever. It is used for the manufacturer. It is not
recommended for users to operate this option without special circumstances.
8.3.3. Error message during initialization
Sign Meaning
ERR 1 Actuator action error
For non-separate
type positioner,
rotation angle of
actuator feedback
ERR 2 lever or rotating
shaft is error.
For separate type
positioner, valve
stroke does not meet
Intelligent Valve Positioner IP6000 Series User's Manual
button to start setting, and the parameter will
Possible reasons
 No air pressure or
insufficient air
pressure
 There is a leakage
from actuator or
positioner.
 The non-separate
type positioner is not
installed correctly.
As a result, the
rotation angle of
actuator feedback
lever or rotating
shaft doesn't meet
the installation
button for approx. 3s to reset to
button to confirm.
Solutions
 Check air source and it's pressure
to make sure that it meets the
requirement
 Eliminate air leakage
 For the non-separate type
positioner, in the initial interface
(NOINI), adjust the installation
position by the angle sensor
percentage value displayed on
LCD, make sure the minimum
and maximum percentage
difference of the angle sensor
rotation is greater than 16%.
