Intelligent Valve Positioner IP6000 Series User's Manual

4. The actuator type has been set before the positioner leaves the factory. The user only needs

one-key operation to execute the automatic initialization (INITA) function to complete the

matching of the valve. In the initial interface (NOINI) or manual / automatic mode interface,

press and hold

button for approx. 3s to run the automatic initialization. After the

initialization is completed, FINSH is displayed on the LCD, press

button to exit. After

exiting, the system enters the manual mode interface, press

button again to switch to the

automatic mode. At this time, the user can control the valve position through the 4-20mA signal.

For some reasons, the system will display an error message in the function option line during

the automatic initialization process and the automatic initialization will be interrupted.

Descriptions of error messages and solutions are showed in chapter 8.3.3.
