Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all local
codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure's
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install the three fasteners. Place the enclosure's upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 10).
Secure enclosure to earth ground. It is recommended to first review the following tables to facilitate installation:
Output Voltage and Stand-by Specifications Charts
Typical Application Diagram
LED Diagnostics
Terminal Identification Tables
Hook-up Diagrams
2. Set output voltage:
AL400ULACMCB and AL600ULACMCB set desired DC output voltage by setting switch SW1 to the appropriate
position on the power supply board. AL1012ULACMCB is factory set at 12VDC and AL1024ULACMCB is factory
set at 24VDC (Output Voltage and Stand-by Specification Charts below).
AL400ULACMCB
Voltage Switch Position
12VDC SW1 - ON
24VDC SW1 - OFF
AL600ULACMCB
Voltage Switch Position
12VDC SW1 - ON
24VDC SW1 - OFF
AL1012ULACMCB
Voltage Switch Position
12VDC N/A
AL1024ULACMCB
(refer to AL1024ULACMCB Battery Size Calculation Worksheet, pg. 9).
Stand-by
Voltage
Battery
24VDC 12AH
24VDC 65AH
3. Measure voltage before connecting devices. This helps avoiding potential damage.
4. Connect AC (Fig. 2, pg. 6):
Connect unswitched AC power (115VAC 60Hz) to the terminals marked [L, G, N]. Use 14 AWG or larger for all power
connections. Secure green wire lead to earth ground.
Keep power-limited wiring separate from non power-limited wiring (115VAC 60Hz Input, Battery Wires).
Minimum 0.25" spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment.
There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel.
5. Output options (Fig. 1, pg. 5):
The unit will provide eight (8) switched power outputs or eight (8) unswitched auxiliary power outputs.
(a) Switched Power outputs:
Connect the negative (-) input of the device being powered to the terminal marked [COM].
For Fail-Safe operation connect the positive (+) input of the device being powered to the terminal marked [NC].
For Fail-Secure operation connect the positive (+) input of the device being powered to the terminal marked [NO].
ACMCB series

Installation Instructions:

Output Voltage and Stand-by Specification Charts:

Stand-by Battery 4 hr. Stand-by / 5 mins. Alarm 24 hr. Stand-by / 5 mins. Alarm
40AH
40AH
Stand-by Battery 4 hr. Stand-by / 5 mins. Alarm 24 hr. Stand-by / 5 mins. Alarm
40AH
40AH
Stand-by Battery 4 hr. Stand-by / 5 mins. Alarm 24 hr. Stand-by / 5 mins. Alarm
40AH
15 mins. Stand-by /
5 mins. Alarm
7.7 amp / 9.7 amp
- - - - - - - - - - - -
(pg. 3)
(pg. 5)
(pg. 5)
(pg. 7)
(pg. 8)
3.5 amp / 3.5 amp
2.75 amp / 2.75 amp
5.5 amp / 5.5 amp
5.75 amp / 5.75 amp
9.5 amp / 9.5 amp
4 hr. Stand-by /
5 mins. Alarm
1.2 amp / 9.7 amp
7.7 amp / 9.7 amp
1 amp / 4 amp
1 amp / 3 amp
0.5 amp / 5.5 amp
0.75 amp / 5.75 amp
0.5 amp / 9.5 amp
24 hr. Stand-by /
5 mins. Alarm
- - - - - - - - - - - -
1.2 amp / 9.7 amp
60 hr. Stand-by /
5 mins. Alarm
- - - - - - - - - - - -
200mA / 9.7 amp
