Specifications - Altronix ACMCB Series Installation Manual

These units distribute and switch power to access control systems and accessories. They convert a 115VAC 60Hz input
into eight (8) independently controlled 12VDC or 24VDC PTC protected outputs. Outputs are activated by an open col-
lector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button,
PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks, Electric Strikes,
Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure modes. The FACP Interface enables
Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature
is individually selectable for any or all of the eight (8) outputs.
AL400ULACMCB
AL600ULACMCB
AL1012ULACMCB 10A - - - - - - - - -
AL1024ULACMCB - - - - - - - - - 10A 8
Power Supply Input Options:
a) One (1) common power input for ACM8CB and lock power (factory installed).
b) Two (2) isolated power inputs (external power supply is required).
(current is determined by the power supply connected, not to exceed a maximum of 10 amp total).
• Eight (8) Access Control System trigger inputs.
Input options:
a) Eight (8) normally open (NO) inputs.
b) Eight (8) open collector inputs.
c) Any combination of the above.
• Eight (8) independently controlled outputs.
Output Options:
• Eight (8) Fail-Safe and/or Fail-Secure power outputs.
• Eight (8) auxiliary power outputs (unswitched) (PTC protected outputs are rated 2 amp).
• ACM8CB board main fuse is rated at 10 amp.
• Red LEDs indicate outputs are triggered (relays energized).
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs.
Fire Alarm disconnect input options:
a) Normally open (NO) or normally closed (NC) dry contact input.
b) Polarity reversal input from FACP signaling circuit.
• Alarm output relay indicates that FACP input is triggered
(form "C" contact rated @ 1 amp 28VDC not evaluated by UL).
• Green LED indicates when FACP disconnect is triggered.
• Filtered and electronically regulated outputs (built-in power supply).
• Built-in charger for sealed lead acid or gel type batteries.
• AL400ULXB2, AL600ULXB and AL1012ULXB (Power Supply Board) maximum charge current 0.7 amp.
AL1024ULXB2 (Power Supply Board) maximum charge current 3.6 amp.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when unit switches over to battery backup (AC failure condition).
• Thermal and short circuit protection with auto reset.
• AC input and DC output LED indicators.
• AC fail supervision (form "C" contact).
• Battery fail and battery presence supervision (form "C" contact).
• Enclosure accommodates up to two (2) 12AH batteries.
Enclosure dimensions: 15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm).
- 2 -
ACMCB Series Configuration Reference Chart:
4A 3A 8 2A Yes
6A 6A 8 2A Yes
8 2A Yes
2A Yes
Overview:
3.5A 5A/250V 15A/32V
3.5A 5A/250V
2.6A 5A/250V 15A/32V
4.2A 5A/250V 15A/32V

Specifications:

140 58th St. Brooklyn, NY
NYC
- - - - - - - - - California
Dept. of
State Fire
Buildings
Marshal
LISTED
UL 294
Altronix Corp.
(File # BP6714)
UL Listed for Access
Control System Units.
"Signal Equipment"
Evaluated to CSA
Standard C22.2
No.205-M1983
ACMCB series
