Hookup Diagrams - Altronix ACMCB Series Installation Manual

Fig. 3 Optional hook-up using two (2) isolated
power supply inputs:
CUT JUMPERS
J1 AND J2
J2
J1
Fig. 5 Normally Open - Non-Latching FACP
trigger input:
J3
TRG
Fig. 7 Normally Closed - Non-Latching FACP
trigger input:
J3
TRG
- 8 -
Hook-Up Diagrams:
ISOLATED POWER INPUT
12 OR 24 VAC OR VDC
(ACM8CB POWER)
ISOLATED POWER INPUT
12 OR 24 VAC OR VDC
(LOCK POWER)
N.O. TRIGGER
INPUT
N.C. DRY
TRIGGER
INPUT
JUMPER
Fig. 4 Polarity reversal input from FACP signaling circuit
output (polarity is referenced in alarm condition):
CUT
JUMPER J3
J3
TRG
Fig. 6 Normally Open FACP Latching trigger input
with reset:
(This output has not been evaluated by UL)
J3
TRG
Fig. 8 Normally Closed - Latching FACP trigger input
with reset:
(This output has not been evaluated by UL)
J3
TRG
FACP
OUTPUT EOL
-- FROM FACP
OUTPUT
+
CIRCUIT
N.O.
TRIGGER
INPUT
N.C. RESET
SWITCH
JUMPER
N.C. RESET
SWITCH
N.C. TRIGGER
JUMPER
INPUT
ACMCB series
