AL1024NKA8 Series

Dual Output Access Power Controllers

Models Include:

AL1024NKA8

- 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) selectable by output.

- Eight (8) fuse protected outputs.

- Eight (8) selectable Fail Safe, Fail-Secure or Form "C" dry outputs

- Fire Alarm Disconnect selectable by output

- Built-in Charger for sealed lead acid or gel type batteries

AL1024NKA8D

- 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) selectable by output.

- Eight (8) Class 2 power-limited PTC protected outputs.

- Eight (8) selectable Fail Safe, Fail-Secure or Form "C" dry outputs.

- Fire Alarm Disconnect selectable by output.

- Built-in Charger for sealed lead acid or gel type batteries.

Installation Guide

Rev. AL1024NKA8-113021

Installing Company: _______________ Service Rep. Name: __________________________________

Address: _____________________________________________ Phone #: __________________

More than just power.

Table of Contents

Need help?

Do you have a question about the AL1024NKA8 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Altronix AL1024NKA8 Series

Page 1 AL1024NKA8 Series Dual Output Access Power Controllers Models Include: AL1024NKA8 - 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) selectable by output. - Eight (8) fuse protected outputs. - Eight (8) selectable Fail Safe, Fail-Secure or Form “C” dry outputs...
Page 2 Access Power Controller’s dual input design allows power to be steered from two (2) factory installed independent low voltage 12 or 24VDC Altronix power supplies to eight (8) independently controlled fuse (AL1024NKA8) or PTC (AL1024NKA8D) protected outputs. Power outputs can be converted to dry form “C” contacts. Outputs are activated by an open collector sink, normally open (NO), normally closed (NC) dry trigger input, or wet output from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc.
Page 3: Power
Specifications: Inputs: Battery Backup: AL1024ULXB2: • Built-in charger for sealed lead acid or • 115VAC, 60Hz, 4.2A. gel type batteries. ACMS8/ACMS8CB: • Automatic switch over to stand-by battery • Eight (8) trigger inputs: when AC fails. a) Normally open (NO) inputs (dry contacts). •...
Page 4: Installation Instructions
Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, the Canadian Electrical Code and with all local codes and authorities having jurisdiction. Product is intended for indoor use only. 1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the enclosure.
Page 5: Facp En <-- > Dis
15. Installation of tamper switch: Mount UL Listed tamper switch (Altronix model TS112 or equivalent) at the top of the enclosure. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 6a, pg. 8).
Page 6: Maintenance
Maintenance: Unit should be tested at least once a year for the proper operation as follows: Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level. Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage both at the battery terminal and at the board terminals marked [–...
Page 7: Output 8
LED Diagnostics: AL1024ULXB2 - Power Supply Board Red (DC) Green (AC) Power Supply Status Normal operating condition. Loss of AC. Stand-by battery is supplying power. No DC output. Loss of AC. Discharged or no stand-by battery. No DC output. ACMS8 and ACMS8CB Access Power Controller LED 1- LED 8 (Red) Output relay(s) de-energized.
Page 8: Output 3
Fig. 6 - AL1024NKA8(D) Tamper Switch Power Output Factory wired to ACMS8(CB) and VR6 (non power-limited) AL1024ULXB2 Power Supply Battery Output (non power-limited) AC DELAY Independently controlled Input Triggers +INP1-- +INP2-- +INP3-- +INP4-- +INP5-- +INP6-- +INP7-- +INP8-- PWR1 + PWR1 + PWR2 + PWR2 + 24VDC from...
Page 9: Table Of Contents
Typical Application Diagram: Fig. 7 Normally Open (N.O.) Door Releasing Device Access Control Panel FACP Output (Fire Alarm Relay Control Panel) +INP1-- +INP2-- +INP3-- +INP4-- +INP5-- +INP6-- +INP7-- +INP8-- PWR1+ PWR1+ PWR2+ PWR2+ FACP Power FACP Supply (req'd.) ACMS8 EOL JMP ACMS8CB Power 2 Power...
Page 10: Eol Jmp
Hook-Up Diagrams: Fig. 8 - Daisy-chaining one or more ACMS8(CB) units. EOL Jumper [EOL JMP] should be installed in the EOL position. Non-Latching. FACP FACP EOL JMP EOL JMP Jumper Jumper FACP FACP Fig. 9 - Daisy-chaining one or more ACMS8(CB) units. EOL Jumper [EOL JMP] should be installed in the EOL position.
Page 11: Facp
Hook-Up Diagrams: Fig. 11 - Polarity reversal input from FACP Fig. 12 - Polarity reversal input from FACP signaling circuit output (polarity is signaling circuit output (polarity is referenced in alarm conditiion). referenced in alarm condition). Non-Latching. Latching. FACP FACP 10K EOL 10K EOL N.O.
Page 12 Enclosure Dimensions (BC400): 15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm) 1.5” 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) 1.75” (44.5mm) 1.25” 1.25” 4.5” (114.3mm) 4.5” (114.3mm) 12.23” (310.6mm) (31.8mm) (31.8mm) 1.1” (27.9mm) 1.1” (27.9mm) 1.375” 1.5” 1.5” (34.9mm) (38.1mm) (38.1mm)
