Hardware layout and configuration

The STM32F3DISCOVERY board is designed around the STM32F303VCT6
microcontroller in a 100-pin LQFP package.
Figure 2
(ST-LINK/V2, push-buttons, LEDs, USB, ST MEMS gyroscope, ST MEMS E-compass, and
connectors).
Figure 2
board.
illustrates the connections between the STM32F303VCT6 and its peripherals
and Figure 3 help the user to locate these features on the STM32F3DISCOVERY

Figure 2. Hardware block diagram

Mini USB
Embedded
ST-LINK/V2 (or V2-B)
STM32F303VCT6
IO
IO RESET
LEDs
LD3...LD10 RESET
L3GD20 or
USER
I3G4250D
LSM303DLHC or
LSM303AGR
Mini-USB
UM1570 Rev 7
Hardware layout and configuration
IO
B2
B1
MSv41785V3
