Table 7. STM32F303VCT6 MCU pin description versus board function (continued)
MCU pin
Main
Alternate function
function
TIM2_CH4, G6_IO1,
PB11 USART3_RX,
COMP2_OUT
G6_IO2,
I2C2_SMBAL,
SPI2_NSS/I2S2_WS,
PB12
TIM1_BKIN,
USART3_CK,
AOP4_OUT
G6_IO3,
SPI2_SCK/I2S2_CK,
PB13
TIM1_CH1N,
USART3_CTS
TIM15_CH1,
G6_IO4,
PB14 SPI2_MISO/I2S2_DI
N, TIM1_CH2N,
USART3_RTS
TIM15_CH2,
TIM15_CH1N,
PB15 TIM1_CH3N,
SPI2_MOSI/
I2S2_DOUT
PC0
PC1
PC2 COMP7_OUT
PC3 TIM1_BKIN2
