IA Spectrum Analyzer (Option 24)
1
1. The map zoom tool is used to increase (+) or decrease (-) zoom level. You can also drag the zoom level
indicator up or down, or you can pinch to change zoom level.
2. Interference signal.
3. Direction of bearing degrees.
4. Re-centering tool to center map on current GPS position. A GPS is required for this icon to appear.
5. Max channel power.
Figure 4-7. Interference Polar Measurement
Spectrum Analyzer MG
2
5
PN: 10580-00447 Rev. E
4-5 Interference Polar
3
4
4-9
