Installation
Attaching the Door Stop Cable
Secure the Door Stop Cable to the bottom Grill/Cone Bolt using two (ST99070) Washers and a (46764) Nut.
Installing the Belt
Install the belt as shown in Figure 11.
10
Door Stop
Cable
Figure 8.Attaching Door Stop Cable
Figure 9.Installing the Belt
(46764)
(ST99070)
(46764)
(54287)
Door Stop Cable
even with the
edge of Cone
Belt
MV2477C
