Chore-Time 50576 Installation And Operators Instruction Manual

24" Basket Fan (50576 and 50576-230)
Installation and Operators Instruction Manual
3
Recommended Tools for
Assembly (Not Provided)
4
5
Item Description
1 Socket Wrench
2 7/16" & 9/16" Combination Wrench
3 Safety Glasses
4 Measuring Tape
5 7/16" & 9/16" Socket
Please read over all instructions carefully before you begin. For additional parts and information,
December 2018
1
Item Description
1 Motor, .5HP, 1PH, 60HZ, 115/230V
2 Decal, CT Round Fan
3 Capacitor
3
1
2
Item Qty.
contact your nearest Chore-Time distributor or representative.
Find your nearest distributor at: www.choretime.com/contacts
Included Assembly
Hardware-Full Scale
1
Description
1 1 3/8" x 1-1/4" Hex Bolt
2 2 3/8" Flat Washer
3 1 3/8" Nylock Nut
2
50576 50576-230
115V Fan 230V Fan
Qty. Part No.
1 53143 53143
1 ST79001 ST79001
1 55337 55337
2
3
6
4
Item Qty Description
4 1 1/4" x 1" Bolt
5 2 1/4" Flat Washer
6 1 1/4" Nylock Nut
MV
5
