Chore-Time Endura 53464-21 Installation & Operator's Instruction Manual

Thank You
The employees of CTB Inc. would like to thank you for your recent Chore-Time
purchase. If a problem should arise, your Chore-Time distributor can supply the necessary information
to help you.
Fan Part Numbers and Specifications
Fan Part No. Bess Lab
Test No.
53464-21 12615
53464-21S
53464-22 12614
53464-22S
53464-23 17224
53464-41 12616
53464-41S
53464-45 21134
53464-42 12619
53464-42S
53464-51 12617
53464-51S
53464-52 12618
53464-52S
Operating static pressure should be less than 0.15 inches water column [37.5 Pa].
The Fan Inlet and exhaust must be kept clear of obstructions. Failure to keep the Fan
airflow path clear of obstructions could cause loss of Fan performance and Fan damage.
August 2024
57" Belt Drive Endura
Voltage Phase Hz
230 1 60
230 1 60
230 1 60
200-230/400-460 3 60
230/460 3 60
200-230/400-460 3 60
200-230/380-415 3 50
200-230/380-415 3 50
Installation & Operator's
Instruction Manual
Nominal Amps Starting
RPM Amps
542 6.9 36.0
543 5.4 27.5
538 4.0 27.5
534 4.8 43
594 6.0 43
539 4.1 43
527 5.2 45.0
534 4.7 45.0
®
Static Pressure at Static Pressure
.10" w.c. at .15" w.c.
[25 Pa] [37.5 Pa]
CFM CFM/W CFM
[cmh] [cmh/W] [cmh]
30400 20.4 28400
[51600] [34.7] [48200]
27100 23 25100
[46100] [39.1] [42700]
21200 24.6 18900
[36000] [41.7] [32200]
30000 20.9 27800
[51100] [35.6] [47200]
33400 18.6 31700
[56800] [31.7] [53900]
26900 23.3 24800
[45600] [39.6] [42200]
29500 20.8 27200
[50100] [35.3] [46200]
26500 22.9 24500
[45100] [38.9] [41600]
Fan
CFM/W
[cmh/W]
18.1
[30.7]
20.1
[34.2]
20.8
[35.3]
18.1
[30.8]
16.9
[28.6]
20.4
[34.6]
18.1
[30.8]
20.1
[34.1]
MV2406U
