10.

Maintenance/Cleaning

This unit is maintenance-free for customers.
Exceptions are the battery pack and micro-SD card, which can be accessed via the rear panel.
The fuses are in the voltage leads.
0
Remove the rubber protective cover,
0
open the housing cover by unscrewing the 4 screws on the back.
Spare parts no.
0
Replacement battery pack
0
Fuse for voltage leads; 500 mA (FF) 50 kA AC/DC; 600 V 6,3 mm x 32 mm
DANGER!
Danger to life due to electric shock!
 Do not open the unit.
 Maintenance of the equipment can only be carried out
by KBR GmbH.
For service, contact KBR GmbH.
Service address:
A. KBR Gmbh
Am Kiefernschlag 7
D-91126 Schwabach
11.

Calibration

We recommend a calibration interval of three years for the network analyzer multilog 3 to maintain the
accuracy of GEFOR-made-IEC61000-4-30 Class A instruments.
12.

Disposal

To dispose of the device and its accessories, send all components to KBR GmbH.
29
