Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehi- cle.
Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Page 5: Table Of Contents
Table of contents Foreword Vehicle information Safety system Instrument cluster Convenience features Driving your vehicle Driver assistance system Emergency situations Maintenance Index...
Page 7: Foreword
1. Foreword Foreword ......................1-2 Hyundai Motor Company ................1-2 How to use this manual ..................1-3 Safety messages .....................1-3 Fuel requirements ...................1-5 Gasoline engine ......................1-5 Vehicle modifications ..................1-8 Vehicle handling instructions ............... 1-8 Vehicle break-in process ................1-8 Returning used vehicles ................1-9...
Page 8: Foreword
HYUNDAI we build. Your Owner’s Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle.
Page 9: How To Use This Manual
HOW TO USE THIS MANUAL We want to help you get the greatest possible driving pleasure from your vehicle. Your Owner’s Manual can assist you in many ways. We strongly recommend that you read the entire manual. In order to minimize the chance of death or injury, you must read the DANGER, WARNING and CAUTION sections in the manual.
Page 10 Foreword Throughout this manual DANGER, WARNING, CAUTION, NOTICE and the SAFETY ALERT SYMBOL will be used. This is the safety alert symbol. It is used to alert you to potential physical injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
Page 11: Fuel Requirements
Also, severe wear and crack of piston ring, valve, etc. may occur and knocking noise may be heard from your engine. Never add any fuel system cleaning agents to the fuel tank other than what has been specified (We recommend that you consult an authorized HYUNDAI dealer for details.) WARNING •...
Page 12 Leaded (if equipped) For some countries, your vehicle is designed to use leaded gasoline. When you are going to use leaded gasoline, we recommend that you ask an authorized HYUNDAI dealer. Octane rating of leaded gasoline is same with unleaded one.
Page 13 Fuel Additives HYUNDAI recommends that you use unleaded gasoline which has an octane rating of RON (Research Octane Number) 95 / AKI (Anti Knock Index) 91 or higher (for Europe) or Octane Rating of RON (Research Octane Number) 91 / AKI (Anti-Knock Index) 87 or higher (except Europe).
Page 14: Vehicle Modifications
Foreword VEHICLE MODIFICATIONS • This vehicle should not be modified. Modification of your vehicle could affect its per- formance, safety or durability and may even violate governmental safety and emis- sions regulations. In addition, damage or performance problems resulting from any modification may not be covered under warranty.
Page 15: Vehicle Data Collection And Event Data Recorders
HYUNDAI promotes an environmentally sound treatment for end of life vehicles and offers to take back your Hyundai end of life vehicles in accordance with the European Union (EU) End of Life Vehicles Directive. You can get detailed information from your national HYUNDAI homepage.
Page 17: Vehicle Information
2. Vehicle information Exterior overview (front view) ............... 2-2 Exterior overview (rear view) ................ 2-5 Interior overview (left-hand drive) ............... 2-8 Interior overview (right-hand drive) .............2-11 Center console overview (left-hand drive) ..........2-14 Center console overview (right-hand drive) ..........2-16 Engine compartment overview ..............2-18 Dimensions ....................
Page 18 Vehicle information 5 Door 5 Door The actual shape may differ from the illustration. OBC3013001L OBC3013001L 1. Hood .............................. 5-37 2. Headlight ............................9-71 3. Daytime running light & Position light ..................9-71 4. Tires and wheels ......................... 9-44 5. Outside rearview mirror ......................5-24 6.
Page 19 N-line N-line The actual shape may differ from the illustration. OBC3TN013001L OBC3TN013001L 1. Hood .............................. 5-37 2. Headlight ............................9-71 3. Daytime running light & Position light ..................9-71 4. Tires and wheels ......................... 9-44 5. Outside rearview mirror ......................5-24 6. Front windshield wiper blades ....................9-39 7.
Page 20 Vehicle information The actual shape may differ from the illustration. OBC3V011001 OBC3V011001 1. Hood .............................. 5-37 2. Headlight ............................9-71 3. Tires and wheels ......................... 9-44 4. Outside rearview mirror ......................5-24 5. Front windshield wiper blades....................9-39 6. Windows ............................5-27 7.
Page 21 5 Door 5 Door The actual shape may differ from the illustration. OBC3013002L OBC3013002L 1. Antenna ............................5-95 2. Doors..............................5-13 3. Fuel filler door ..........................5-40 4. Rear ultrasonic sensors ......................7-133 5. High mounted stop light ......................9-89 6. Wide-rear view camera ......................7-107 7.
Page 22 Vehicle information N-line N-line The actual shape may differ from the illustration. OBC3TN013002L OBC3TN013002L 1. Antenna ............................5-95 2. Doors .............................5-13 3. Fuel filler door ..........................5-40 4. Rear ultrasonic sensors ......................7-133 5. High mounted stop light ......................9-89 6. Wide-rear view camera ......................7-107 7.
Page 23 The actual shape may differ from the illustration. OBC3V011002 OBC3V011002 1. Antenna ............................5-95 2. Doors..............................5-13 3. Fuel filler door ..........................5-40 4. Rear ultrasonic sensors ......................7-133 5. High mounted stop lamp ......................9-89 6. Wide-rear view camera ......................7-107 7. Rear window wiper blade ......................9-39 8.
Page 24 Vehicle information 5 Door 5 Door The actual shape may differ from the illustration. OBC3013003L OBC3013003L 1. Door handle ...........................5-15 2. Outside rearview mirror control switch ..................5-25 3. Outside rearview mirror folding button ..................5-26 4. Power window switches......................5-27 5.
Page 25 N-line N-line The actual shape may differ from the illustration. OBC3TN013003L OBC3TN013003L 1. Door handle ...........................5-15 2. Outside rearview mirror control switch ..................5-25 3. Outside rearview mirror folding button ..................5-26 4. Power window switches......................5-27 5. Power window lock button ......................5-31 6.
Page 26 Vehicle information The actual shape may differ from the illustration. OBC3013005L OBC3013005L 1. Door handle ...........................5-15 2. Outside rearview mirror control switch ..................5-25 3. Outside rearview mirror folding button ..................5-26 4. Power window switches......................5-27 5. Power window lock button ......................5-31 6.
Page 27 5 Door 5 Door The actual shape may differ from the illustration. OBC3013003R OBC3013003R 1. Door handle ...........................5-15 2. Outside rearview mirror control switch ..................5-25 3. Outside rearview mirror folding button ..................5-26 4. Power window switches......................5-27 5. Power window lock button ......................5-31 6.
Page 28 Vehicle information N-line N-line The actual shape may differ from the illustration. OBC3TN013003R OBC3TN013003R 1. Door handle ...........................5-15 2. Outside rearview mirror control switch ..................5-25 3. Outside rearview mirror folding button ..................5-26 4. Power window switches......................5-27 5. Power window lock button ......................5-31 6.
Page 29 The actual shape may differ from the illustration. OBC3013005R OBC3013005R 1. Door handle ...........................5-15 2. Outside rearview mirror control switch ..................5-25 3. Outside rearview mirror folding button ..................5-26 4. Power window switches......................5-27 5. Power window lock button ......................5-31 6.
Page 30 Vehicle information The actual shape may differ from the illustration. OBC3013004L OBC3013004L 1. Lighting control/ 14. Hazard warning light button ....8-3 Turn signals switch ........5-43 15. Central door lock/unlock button ..5-15 2. Steering wheel audio controls .....5-96 16. Passenger’s front air bag ....3-43 3.
Page 31 N-line N-line The actual shape may differ from the illustration. OBC3TN013004L OBC3TN013004L 1. Lighting control/Turn signals switch ..5-43 12. USB port ..........5-95 2. Steering wheel audio controls ....5-96 13. Climate control system ....5-58/ 5-67 3. Instrument cluster ........4-2 14.
Page 32 Vehicle information The actual shape may differ from the illustration. OBC3013004R OBC3013004R 1. Lighting control/ 14. Hazard warning light button ....8-3 Turn signals switch ........5-43 15. Central door lock/unlock button ..5-15 2. Steering wheel audio controls .....5-96 16. Passenger’s front air bag ....3-43 3.
Page 33 N-line N-line The actual shape may differ from the illustration. OBC3TN013004R OBC3TN013004R 1. Lighting control/Turn signals switch ..5-43 12. USB port ..........5-95 2. Steering wheel audio controls ....5-96 13. Climate control system ....5-58/ 5-67 3. Instrument cluster ........4-2 14.
Page 34 Vehicle information Smartstream G 1.0 T-GDi / Smartstream G1.0 T-GDi (48V) MHEV Smartstream G 1.0 T-GDi / Smartstream G1.0 T-GDi (48V) MHEV - Left-hand drive - Left-hand drive - Right-hand drive - Right-hand drive The actual engine room in the vehicle may differ from the illustration. OBC3090001/OBC3090001R OBC3090001/OBC3090001R 1.
Page 35 Smartstream G1.2 Smartstream G1.2 - Left-hand drive - Left-hand drive - Right-hand drive - Right-hand drive The actual engine room in the vehicle may differ from the illustration. OBC3090003/OBC3090003R OBC3090003/OBC3090003R 1. Engine coolant reservoir ......................9-27 2. Engine oil filler cap ........................9-25 3.
Page 36 Vehicle information Gasoline 1.4 Gasoline 1.4 - Left-hand drive - Left-hand drive - Right-hand drive - Right-hand drive The actual engine room in the vehicle may differ from the illustration. OBC3090004/OBC3090004R OBC3090004/OBC3090004R 1. Engine coolant reservoir ......................9-27 2. Engine oil filler cap ........................9-25 3.
Page 37 mm (in.) 5 Door N-line Items 4,065 (160.04) 4,075 (160.43) 4,180 (164.56) Overall length 1,775 (69.88) 1,775 (69.88) 1,775 (69.88) Overall width 1,490 (58.66) / Overall height 1,450 (57.09) 1,455 (57.28) 1,500 (59.05)* 185/65R15 1,545 (60.82) 1,551 (61.06) 195/55R16 1,539 (60.59) 1,545 (60.82) Front tread 215/45R17...
Page 38 Vehicle information 5 Door 5 Door Light bulb Bulb type Wattage Headlight (Low/High) 60/55 Type A Turn signal light PY21W Position light (if equipped) Headlight (High/Low) Turn signal light Type B Daytime running light & Front Position light Static bending light Daytime running light (Bulb) P21W Daytime running light (LED)
Page 39 N-line N-line Light bulb Bulb type Wattage Headlight (Low/High) 60/55 Type A Turn signal light PY21W Position light (if equipped) Headlight (High/Low) Turn signal light Front Type B Daytime running light & Position light Static bending light Daytime running light (LED) Side repeater light WY5W Fog light (if equipped)
Page 40 Vehicle information Light bulb Bulb type Wattage Headlight (Low/High) Type A Turn signal light PY21W Headlight (High/Low) Type B Static bending light Front Daytime running light & Position light Daytime running light & Position light & Turn signal light Side repeater light WY5W Tail light P21/5W...
Page 41 Inflation pressure, bar (psi, kPa) Wheel lug Wheel nut torque Normal load * Maximum load Tire size Item size kgf·m Front Rear Front Rear (lbf·ft, N•m) 185/65R15 2.35 2.15 6.0J X 15 (5DR/CUV) (34, 235) (31, 215) (35, 240) (36, 250) 195/55R16 2.35 2.15...
Page 42 R-1234yf 500 ± 25 g (16.07 ± 0.8) R-134a g (oz.) Compressor lubricant 100 (3.52) g (oz.) We recommend that you contact an authorized HYUNDAI dealer for more details. Load capacity Speed capacity Tire size Wheel size Item km/h LI * kg (lbs.)
Page 43 - 5DR, N-line kg (lbs.) Smartstream G 1.0 Smartstream G 1.0 T-GDi Smartstream G 1.2 Gasoline 1.4 T-GDi (48V) MHEV 6 M/T 7 DCT 6 M/T 7 DCT 5 M/T 6 A/T 1,600 1,630 1,620 1,650 1,550 1,590 (3,527) (3,593) (3,571) (3,637) (3,417)
Page 44 Vehicle information The following table indicates the maximum trailer weight for your vehicle. Do not exceed the maximum allowable trailer weight. The maximum trailer weight includes the weight of the trailer, any cargo, and equipment or items attached to the trailer. The towing load in excess of these limits can seriously affect vehicle steering and perfor- mance, and may damage the engine and drivetrain.
Page 45 (0.087 US qt.) DOT-4, FMVSS116 DOT-3 fluid SK ATF SP4M-1, MICHANG Automatic ATF SP4M-1, S-OIL ATF Gasoline 1.4 transmission fluid SP4M-1, Hyundai Genuine ATF SP4M-1 API GL-4, SAE 70W Smartstream G 1.0 HK D DCTF TGO-10 PLUS Dual clutch T-GDi/Smartstream (SK) transmission fluid (1.69~1.78 US qt.)
Page 46 Vehicle information Lubricant Volume Classification Brake/Clutch (if equipped) fluid FMVSS116 DOT-4 (0.7~0.8 US qt.) Fuel : Refer to the recommended SAE viscosity numbers on the next page. : Requires <API SN PLUS (or Above) Full synthetic> grade engine oil. If a lower grade engine oil (mineral oil including Semi-synthetic) is used, then the engine oil and engine oil filter must be replaced as indicated severe maintenance condition : Requires <API Latest(ILSAC Latest) Full synthetic>...
Page 47 Recommended SAE viscosity number NOTICE • Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mecha- nisms that could be damaged.
Page 48 Vehicle information Frame number Frame number OBC3010020 OBC3010020 OBC3010022 OBC3010022 The vehicle identification number (VIN) The vehicle certification label attached is the number used in registering your on the driver’s (or front passenger’s) side vehicle and in all legal matters pertaining center pillar gives the vehicle identifica- to its ownership, etc.
Page 49 Smartstream G 1.0 T-GDi/Smartstream G1.0 Smartstream G 1.0 T-GDi/Smartstream G1.0 T-GDi (48V) MHEV T-GDi (48V) MHEV OBC3010023 OBC3010023 Smartstream G1.2 Smartstream G1.2 OBC3010021 OBC3010021 The tires supplied on your new vehicle are chosen to provide the best perfor- mance for normal driving. The tire label located on the left side cen- ter pillar gives the tire pressures recom- mended for your vehicle.
Page 50 HYUNDAI Motor Company will provide the open source code to you in storage medium such as CD-ROM for minimum charge covering the cost of performing OHC081001...
Page 51 The fuel label is attached on the fuel filler door. OTM013030L OTM013030L A. Octane rating of unleaded Gasoline (Petrol) 1) RON/ROZ : Research Octane Number 2) (R+M)/2, AKI : Anti Knock Index B. Identifiers for Petrol-type fuels This symbol means usable fuel. Do not use any other fuel. C.
Page 52 Vehicle information CE0678 CE0678 The radio frequency components of the vehicle comply with requirements and other relevant provisions of Directive 1995/5/EC. Further information including the manu- facturer’s declaration of conformity is available on Hyundai web site as follows: http://service.hyundai-motor.com 2-36...
Page 53: Safety System
3. Safety system Important safety precautions ............... 3-2 Always wear your seat belt ..................3-2 Restrain all children ....................3-2 Air bag hazards ......................3-2 Driver distraction .......................3-2 Control your speed ....................3-3 Keep your vehicle in safe condition ................ 3-3 Seats ........................ 3-4 Safety precautions ....................
Page 54: Important Safety Precautions
Safety system IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Driver distraction and recommendations throughout this Driver distraction presents a serious and section, and throughout this manual. The potentially deadly danger, especially for safety precautions in this section are inexperienced drivers.
Page 55: Control Your Speed
Control your speed Excessive speed is a major factor in crash injuries and deaths. Generally, the high- er the speed, the greater the risk, but serious injuries can also occur at lower speeds. Never drive faster than is safe for current conditions, regardless of the maximum speed posted.
Page 56: Seats
Safety system SEATS Left-hand drive Left-hand drive Driver's Side Driver's Side Passenger's Side Passenger's Side Rear Seat Rear Seat The actual feature in the vehicle may differ from the illustration. OBC3030001 OBC3030001 Front seats Rear seats 1. Forward and backward 6.
Page 57 Right-hand drive Right-hand drive Passenger's Side Passenger's Side Driver's Side Driver's Side Rear Seat Rear Seat The actual feature in the vehicle may differ from the illustration. OBC3030001R OBC3030001R Front seats Rear seats 1. Forward and backward 6. Headrest (outboard and/or center*) 2.
Page 58: Safety Precautions
Safety system Safety precautions Air bags You can take steps to reduce the risk Adjusting the seats so that you are sitting of being injured by an inflating air bag. in a safe, comfortable position plays an Sitting too close to an air bag greatly important role for the safety of the driver increases the risk of injury in the event and passengers, along with seat belts and...
Page 59: Front Seats
Seat belts Front seats Always fasten your seat belt before start- The front seat can be adjusted by using ing any trip. the control lever or switches located on At all times, passengers should sit upright the outside of the seat cushion. Before and be properly restrained.
Page 60 Safety system Forward and rearward adjustment CAUTION To prevent injury: • Do not adjust your seat while wear- ing your seat belt. Moving the seat cushion forward may cause strong pressure on your abdomen. • Do not allow your hands or fingers to get caught in the seat mechanisms while the seat is moving.
Page 61 Reclining seatback Seatback angle Sitting in a reclined position when the vehicle is in motion can be dangerous. Even when buckled up, the protections of your restraint system (seat belts and/ or air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seatback when the vehicle is moving.
Page 62 Safety system Seat height (for driver’s seat, if Seatback pocket (if equipped) equipped) OAI3039033 OAI3039033 The seatback pocket is provided on the OBC3030004 OBC3030004 back of the front seatback. To change the height of the seat cushion: • Push down the lever several times, to CAUTION lower the seat cushion.
Page 63: Rear Seats
Rear seats (if equipped) The rear seatbacks can be folded to facili- tate carrying long items or to increase the luggage capacity of the vehicle. WARNING • Never allow passengers to sit on top of the folded down seatback while the vehicle is moving.
Page 64 Safety system WARNING WARNING When you return the rear seatback to Cargo its upright position after being folded Cargo should always be secured to pre- down: vent it from being thrown about the Be careful not to damage the seat belt vehicle in a collision and causing injury webbing or buckle.
Page 65: Headrest
Headrest The vehicle’s front and rear seats have adjustable headrests. The headrests pro- vide comfort for passengers, but more importantly they are designed to help protect passengers from whiplash and other neck and spinal injuries during an accident, especially in a rear impact col- lision.
Page 66 Safety system Front seat headrests OAC3039039TU OAC3039039TU OBC3030006 OBC3030006 Adjusting the height up and down The driver’s and front passenger’s seats To raise the headrest: are equipped with adjustable headrests 1. Pull it up to the desired position (1). for the passenger’s safety and comfort. To lower the headrest: 1.
Page 67 OBC3030007 OBC3030007 OBC3030008 OBC3030008 Removal/Reinstall To reinstall the headrest : To remove the headrest: 1. Recline the seatback. 1. Recline the seatback (2) using the 2. Put the headrest poles (2) into the seatback lever (1). holes while pressing the release but- ton (1).
Page 68 Safety system Rear seat headrests OBC3030036TU OBC3030036TU Removal and installation OBC3030009 OBC3030009 To remove the headrest : The rear seats are equipped with head- 1. Raise the headrest as far as it can go. rests in all the seating positions for the 2.
Page 69: Seat Warmers
Seat warmers (if equipped) WARNING Seat warmers are provided to warm the NEVER place anything on the seat that seats during cold weather. insulates against heat when the seat warmer is in operation, such as a blan- ket or seat cushion. This may cause the WARNING seat warmer to overheat, causing a burn The seat warmers can cause a SERIOUS...
Page 70 Safety system - Rear seat Front Front HIGH ( LOW ( • The seat warmer temperature is low- ered automatically and then goes off after a certain time to prevent low temperature burns. If high temperature is selected again after the seat warmer turns off, the temperature is controlled automatically again.
Page 71: Seat Belts
SEAT BELTS This section describes how to use the • Do not latch the seat belt into the seat belts properly. It also describes buckles of other seats. some of the things not to do when using • NEVER unfasten the seat belt while seat belts.
Page 72: Seat Belt Warning Light
Safety system Seat belt warning light Front passenger’s seat belt (if equipped) Driver’s seat belt As a reminder to the front passenger, the Instrument cluster Instrument cluster front passenger’s seat belt warning lights will illuminate for approximately 6 seconds each time you turn the ignition switch ON regardless of belt fastening.
Page 73 Rear seat belt warning Rear left / right side seat (if equipped) (if equipped) As a reminder to the rear passenger, the rear passenger’s seat belt warning lights will illuminate for approximately 6 seconds each time you turn the ignition switch ON regardless of belt fastening.
Page 74: Seat Belt Restraint System
Safety system Information • Although the rear passenger seat is not occupied, the seat belt warning light will blink or illuminate for 6 seconds. • The rear passenger’s seat belt warning may operate when luggage, laptop or other electronic device is placed on the rear passenger seat.
Page 75 WARNING OHI038142 OHI038142 To release your seat belt: OHI038182L OHI038182L Press the release button (1) in the locking Improperly positioned seat belts may buckle. increase the risk of serious injury in an When it is released, the belt should auto- accident.
Page 76: Pre-Tensioner Seat Belt
Safety system Rear center seat belt Pre-tensioner seat belt (if equipped) (if equipped) OAC3039044TU OAC3039044TU OJX1039118 OJX1039118 When using the rear center seat belt, the [1] : Retractor pre-tensioner seat belt buckle with the “CENTER” mark must be used. Your vehicle is equipped with Pre- tensioner Seat Belts (Retractor Pre- tensioner).
Page 77 HYUNDAI dealer. • Do not place anything near the buck- le. This may adversely affect the buck- le and cause it to function improperly.
Page 78 (1) SRS air bag warning light nates when the vehicle is being driven, (2) Front retractor pre-tensioner we recommend the pre-tensioner seat (if equipped) belts and/or SRS air bags be inspected (3) SRS control module by an authorized HYUNDAI dealer as soon as possible. 3-26...
Page 79: Additional Seat Belt Safety Precautions
NOTICE Additional seat belt safety precautions • Pre-tensioner seat belts may be acti- vated in certain frontal or side colli- Seat belt use during pregnancy sions. The seat belt should always be used dur- • When the pre-tensioner seat belts are ing pregnancy.
Page 80 Safety system Seat belt use and children Larger children Children under age 13 and who are too Infant and small children large for a booster seat must always Most countries have Child Restraint occupy the rear seat and use the avail- Systems laws which require children able lap/shoulder belts.
Page 81: Care Of Seat Belts
We slide under the lap belt or the passenger’s recommend that you consult an autho- neck will strike the shoulder belt. rized HYUNDAI dealer. WARNING • NEVER ride with a reclined seatback when the vehicle is moving.
Page 82: Child Restraint System (Crs)
Safety system Children under age 13 should always ride Our recommendation: in the rear seats and must always be Children always in the rear properly restrained to minimize the risk of injury in an accident, sudden stop or sudden maneuver. According to acci- WARNING dent statistics, children are safer when Always properly restrain children in the...
Page 83: Selecting A Child Restraint System (Crs)
• After an accident, we recommend seats. They are classified according to the child’s age, height and weight. a HYUNDAI dealer check the Child Restraint System, seat belts, ISOFIX anchorages and top-tether anchor- ages. 3-31...
Page 84 Safety system CRS09 CRS09 OIB034017 OIB034017 Rearward-facing Child Restraint Forward-facing Child Restraint System System A rearward-facing Child Restraint System A forward-facing Child Restraint System provides restraint with the seating sur- provides restraint for the child’s body face against the back of the child. The with a harness.
Page 85: Installing A Child Restraint System (Crs)
• Make sure the Child Restraint System Installing a Child Restraint is firmly secured. After installing a System (CRS) Child Restraint System to the vehicle, push and pull the seat forward and from side-to-side to verify that it is WARNING securely attached to the seat.
Page 86 Safety system 3-34...
Page 87 Position Seat Number Seating positions in the vehicle Front left Front center Front right row left row center row right If the vehicle headrest prevents proper installation of a CRS, the headrest of the seating posi- tion shall be readjusted or entirely removed Never place a rearward facing Child Restraint System on the front passenger seat, unless the air bag is deactivated.
Page 88 Safety system ISOFIX anchorage and top-tether anchorage (ISOFIX anchorages system) for children The ISOFIX system holds a Child Restraint System during driving and in an accident. This system is designed to make installa- tion of the Child Restraint System easier and reduce the possibility of improperly installing your Child Restraint System.
Page 89 Securing a Child Restraint System with the “ISOFIX Anchorage System” To install a ISOFIX-compatible Child Restraint System in either of the rear out- board seating positions: 1. Move the seat belt buckle away from the ISOFIX anchorages. 2. Move any other objects away from the anchors that could prevent a secure connection between the Child OBC3030015...
Page 90 Safety system Securing a Child Restraint System WARNING seat with “Top-tether Anchorage” system Take the following precautions when using the ISOFIX system: • Read and follow all installation instructions provided with your Child Restraint System. • To prevent the child from reaching and taking hold of unretracted seat belts, buckle all unused rear seat belts and retract the seat belt web-...
Page 91 Securing a Child Restraint System WARNING with a lap/shoulder belt Take the following precautions when When not using the ISOFIX system, all installing the top-tether: Child Restraint Systems must be secured • Read and follow all installation to a rear seat with the lap part of a lap/ instructions provided with your Child shoulder belt.
Page 92 Safety system OHI038146 OHI038146 OHI038183L OHI038183L 2. Fasten the lap/shoulder belt latch 3. Remove as much slack from the belt into the buckle. Listen for the distinct as possible by pushing down on the “click” sound. Child Restraint System while feeding the shoulder belt back into the retrac- tor.
Page 93 The actual air bags in the vehicle may differ from the illustration. OBC3033040L OBC3033040L 1. Driver’s front air bag 2. Passenger’s front air bag* 3. Side air bag* 4. Curtain air bag* 5. Front passenger’s air bag ON/OFF switch* * : if equipped 3-41...
Page 94 Safety system This vehicle equipped with WARNING Supplemental Air Bag System for the driver’s seat and front passenger’s seats. AIR BAG SAFETY PRECAUTIONS The front air bags are designed to supple- ALWAYS use seat belts and Child ment the three-point seat belts. For these Restraint Systems - every trip, every air bags to provide protection, the seat time, everyone! Even with air bags, you...
Page 95: Where Are The Air Bags
Where are the air bags? WARNING Driver’s and passenger’s air bags To reduce the risk of serious injury or (if equipped) death from an inflating front air bags, take the following precautions: Driver’s front air bag Driver’s front air bag •...
Page 96 Safety system Type A Type A OBC3030021 OBC3030021 OAC3039014TU OAC3039014TU Type B Type B Passenger’s front air bag ON/OFF switch (if equipped) The purpose of the switch is to disable the passenger’s front air bag in order to transport occupants who are at increased risk for air bag-related injury due to age, size, or medical condition.
Page 97 ON/OFF switch is set to the OFF position. • We recommend that an authorized HYUNDAI dealer inspect the passen- ger’s front air bag ON/OFF switch and the SRS air bag system as soon as possible.
Page 98 The side air bags are not designed to position or this may cause the side air deploy in all side impact. bags to inflate. • If the seat or seat cover is damaged, we recommend that the system be serviced by an authorized HYUNDAI dealer. 3-46...
Page 99 HYUNDAI dealer. They are designed to help protect the heads of the front seat occupants and the rear outboard seat occupants in certain side impact collisions.
Page 100: How Does The Air Bags System Operate
• The light blinks when the engine is running. (12) Passenger’s front air bag ON/OFF switch * We recommend that an authorized HYUNDAI dealer inspect the SRS as soon * : if equipped as possible if any of these conditions occur. The SRSCM continually monitors SRS...
Page 101 During a frontal collision, sensors will • To help provide protection, the air detect the vehicle’s deceleration. If the bags must inflate rapidly. The speed rate of deceleration is high enough, the of air bag inflation is a consequence control unit will inflate the front air bags, of extremely short time in which to at the time and with the force needed.
Page 102 Safety system Driver's front air bag (1) Driver's front air bag (1) Driver's front air bag (3) Driver's front air bag (3) ODN8039077L ODN8039077L ODN8039079L ODN8039079L Passenger’s front air bag Passenger’s front air bag When the SRSCM detects a sufficiently severe impact to the front of the vehicle, it will automatically deploy the front air bags.
Page 103: What To Expect After An Air Bag Inflates
• Always wash exposed skin areas thor- oughly with cold water and mild soap. • We recommend that an authorized HYUNDAI dealer replace the air bag immediately after deployment. Air bags are designed to be used only once.
Page 104: Do Not Install A Child Restraint System On The Front Passenger Seat
Child Restraint System bag system we recommend to replace on a seat protected by an air bag in the bumper with genuine HYUNDAI front of it! part or the equivalent (of the genuine • NEVER use a rearward facing Child part) specified for your vehicle.
Page 105 OBC3033024L/OAI3039024L/OBC3033025L/OBC3030037TU/OBI3030014L OBC3033024L/OAI3039024L/OBC3033025L/OBC3030037TU/OBI3030014L 1. SRS control module* 2. Front impact sensor 3. Side pressure sensor* 4. Side impact sensor* * : if equipped 3-53...
Page 106 Safety system Air bag inflation conditions OBC3033028L OBC3033028L OBC3030027 OBC3030027 Front air bags Front air bags are designed to inflate in a frontal collision depending on the sever- ity of impact of the front collision. OAC3039029TU OAC3039029TU Side and curtain air bags Side and curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on...
Page 107 Air bag non-inflation conditions OBC3033028L OBC3033028L Front air bags may not inflate in side OBC3030029 OBC3030029 impact collisions, because occupants In certain low-speed collisions the air move in the direction of the collision, bags may not deploy. The air bags are and thus in side impacts, front air bag designed not to deploy in such cases deployment would not provide additional...
Page 108 Safety system OBC3030032 OBC3030032 OBC3033033L OBC3033033L Air bags may not inflate if the vehicle col- Just before impact, drivers often brake lides with objects such as utility poles or heavily. Such heavy braking lowers trees, where the point of impact is con- the front portion of the vehicle caus- centrated and the collision energy is ing it to “ride”...
Page 109: Srs Care
HYUNDAI dealer. • Do not place objects over or near We recommend any work on the SRS the air bag modules on the steer-...
Page 110: Additional Safety Precautions
Safety system Additional safety precautions Air bag warning labels (if equipped) Passengers should not move out of or change seats while the vehicle is mov- Left Hand Drive Left Hand Drive ing. A passenger who is not wearing a seat belt during a crash or emergency stop can be thrown against the inside of the vehicle, against other occupants, or be ejected from the vehicle.
Page 111 4. Instrument cluster Instrument cluster ..................4-2 Instrument cluster control ..................4-5 Gauges and meters ....................4-6 Transmission shift indicator ..................4-10 Warning and indicator lights ................... 4-12 Cluster display messages ..................4-22 Cluster display (Type A, C)................4-27 Cluster display control .....................4-27 Cluster display modes.....................
Page 112: Instrument Cluster
Instrument cluster INSTRUMENT CLUSTER Type A Type A OBC3040001 OBC3040001 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. Warning and indicator lights 6. Cluster display The actual cluster in the vehicle may differ from the illustration. For more details, refer to the “Gauges and Meters”...
Page 113 Type B Type B OBC3040020 OBC3040020 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. Warning and indicator lights 6. Cluster display The actual cluster in the vehicle may differ from the illustration. For more details, refer to the “Gauges and Meters”...
Page 114 Instrument cluster Type C Type C OBC3043001L OBC3043001L 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. Warning and indicator lights 6. Cluster display The actual cluster in the vehicle may differ from the illustration. For more information, refer to “Gauges and meters”...
Page 115: Instrument Cluster Control
Instrument cluster control Type A OCN7040019L OCN7040019L • The brightness of the instrument panel illumination is displayed. OBC3043002L OBC3043002L • If the brightness reaches the maximum When the vehicle's position lights or or minimum level, an alarm will sound. headlamps are on, press the illumination control button to adjust the brightness of WARNING the instrument panel illumination.
Page 116: Gauges And Meters
Instrument cluster Gauges and meters Tachometer Speedometer Type A Type A Type B Type B Type A km/h km/h OAC3049004TU/OBC3040006 OAC3049004TU/OBC3040006 Type C Type C OAC3049002TU/OAC3049003TU OAC3049002TU/OAC3049003TU Type B km/h km/h OAC3043004TU OAC3043004TU The tachometer indicates the approxi- mate number of engine revolutions per minute (RPM).
Page 117 Engine Coolant Temperature Gauge Fuel Gauge Type A Type A Type B Type B Type A Type A Type B Type B OBC3040009/OBC3040008 OBC3040009/OBC3040008 OBC3040007/OCN7040011L OBC3040007/OCN7040011L Type C Type C Type C Type C OAC3043009TU OAC3043009TU OAC3043010TU OAC3043010TU This gauge indicates the temperature This gauge indicates the approximate of the engine coolant when the ignition amount of fuel remaining in the fuel tank.
Page 118 Instrument cluster Outside Temperature Gauge WARNING Type A/C Type A/C Type B Type B Running out of fuel can expose vehicle occupants to danger. You must stop and obtain additional fuel as soon as possible after the warn- ing light comes on or when the gauge indicator comes close to the “0”...
Page 119 Odometer Information Type A/C Type A/C Type B Type B • If the vehicle is not on level ground or the battery power has been interrupted, the distance to empty function may not operate correctly. • The distance to empty may differ from the actual driving distance as it is an esti- mate of the available driving distance.
Page 120: Transmission Shift Indicator
Instrument cluster Fuel economy (for cluster type B) Transmission shift indicator Manual transmission shift indicator (if equipped) Type A/C Type A/C OTM040062L OTM040062L The average fuel economy (1) and instant fuel economy (2) is displayed at the bot- tom of the cluster. OPDE046142 OPDE046142 Type B...
Page 121 Automatic transmission shift Dual clutch transmission shift indicator (if equipped) indicator (if equipped) Type A/C Type A/C Type A/C Type A/C OBC3040010 OBC3040010 OTL045132 OTL045132 Type B Type B Type B Type B OBC3040011 OBC3040011 OCN7040013 OCN7040013 This indicator displays which shift lever This indicator displays which automatic position is selected.
Page 122: Warning And Indicator Lights
If this occurs, we recommend that you 2. With the engine stopped, check the have the vehicle inspected by an autho- brake fluid level immediately and add rized HYUNDAI dealer. fluid as required (For more details, refer to “Brake Fluid” in chapter 9). Seat warning light After adding brake fluid, check all brake components for fluid leaks.
Page 123 If this occurs, we recommend that is safe to do so. you have the vehicle inspected by an authorized HYUNDAI dealer. WARNING Parking Brake & Brake Fluid warning Electronic Brake Force...
Page 124 Also, the MDPS warning light may illumi- nate and the steering effort may increase or decrease. If this occurs, we recommend you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. 4-14...
Page 125 If the Malfunction Indicator Lamp (MIL) illuminates, potential catalytic convert- er damage is possible which could result in loss of engine power. In this case, we recommend that you have the vehicle inspected by an autho- rized HYUNDAI dealer as soon as pos- sible. 4-15...
Page 126 If the warning light remains on after adding oil or if oil is not available, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. Continued driving with the warning light on may cause engine failure. Information When engine oil pressure decreases due to insufficient engine oil, etc., the Engine Oil...
Page 127 In this case, we recommend that you (TPMS) malfunction have the vehicle inspected by an To identify the details of the warning, authorized HYUNDAI dealer as soon as look at the cluster display. possible. For more details, refer to “Tire Pressure Monitoring System (TPMS)”...
Page 128 This indicator light blinks: ommend that you have the GPF system checked by an authorized HYUNDAI deal- • While the ESC is operating. For more details, refer to “Electronic Stability Control (ESC)” section in chap- NOTICE ter 6.
Page 129 When the engine enters the Idle Stop have the vehicle inspected by an mode of ISG (Idle Stop and Go) system. authorized HYUNDAI dealer. This indicator light blinks: When the engine automatically starts, the AUTO STOP indicator on the cluster will blink for 5 seconds.
Page 130 • When the smart key is not in the vehi- If any of these conditions occur, we cle. recommend that you have your vehicle - At this time, you cannot start the inspected by an authorized HYUNDAI engine. dealer. This indicator light illuminates for 2 seconds and goes off: Low beam indicator light •...
Page 131 If this occurs, we recommend that you ceding vehicles, High Beam Assist will have the vehicle inspected by an autho- switch the high beam to low beam auto- rized HYUNDAI dealer. matically. For more details, refer to “Forward For more details, refer to “High Beam Collision-Avoidance Assist (FCA)”...
Page 132: Cluster Display Messages
Instrument cluster Cluster display messages Cruise Indicator Light (if equipped) Key not in vehicle (for smart key system) This warning message is displayed if the This indicator light illuminates: smart key is not in the vehicle when you • When Cruise Control is enabled. open or close door in the ACC position or ON position.
Page 133 If this occurs, attempt to start the engine by pressing the Engine Start/Stop button again. If the warning message appears each time you press the Engine Start/Stop button, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer. 4-23...
Page 134 Instrument cluster Door, Hood, Tailgate open indicator Lights mode OBC3040012 OBC3040012 OIK047163L OIK047163L This warning is displayed if any door or This indicator displays which exterior hood or tailgate is left open. The warning light is selected using the lighting control. will indicate which door is open in the display.
Page 135 50-100 km (30-60 mi.) after the engine warms up, we rec- ommend that the system be checked by Heated Steering Wheel turned off an authorized HYUNDAI dealer. (if equipped) This message illuminates if the heated steering wheel will turn off automatically approximately 30 minutes after the heat- ed steering wheel is turned on.
Page 136 Instrument cluster Engine has overheated (if equipped) This warning message is displayed when the engine coolant temperature is above 120°C (248°F). This means that the engine is overheated and may be damaged. If your vehicle is overheated, refer to “Overheating” section in chapter 8. Check headlight (if equipped) This warning message is displayed if the headlamps are not operating properly.
Page 137: Cluster Display Control
Cluster display control OBC3043037L OBC3043037L 4-27...
Page 138 Instrument cluster N Line N Line OBC3043051L OBC3043051L The cluster display modes can be changed by using the control buttons. Switch Function MODE button for changing modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item 4-28...
Page 139: Cluster Display Modes
Cluster display modes Modes Symbol Explanation This mode displays driving information such as the tripmeter, Trip fuel economy, etc. Computer For more details, refer to "Trip Computer" in this chapter. Turn By This mode displays the state of the navigation. Turn (TBT) - Smart Cruise Control Driving...
Page 140 Instrument cluster Trip computer group Turn By Turn (TBT) group OBC3043042L OBC3043042L OBC3043043L OBC3043043L The trip computer group displays infor- This group displays the state of the nav- mation related to vehicle driving param- igation. eters including fuel economy, tripmeter information and vehicle speed.
Page 141 Driving Assist mode Master warning OBC3043044L OBC3043044L OBC3053062L OBC3053062L SCC/ISLA This warning light informs the driver the following situations. This mode displays the state of Smart Cruise Control, Intelligent Speed Limit - Forward Collision-Avoidance Assist Assist. malfunction (if equipped) - Forward Collision-Avoidance Assist For more details, refer to each system radar blocked (if equipped) information Section in chaptet 7.
Page 142: User Settings Mode
Instrument cluster User settings mode (if equipped) In this mode, you can change the settings of the instrument cluster, doors, lamps, etc. 1. Driver Assistance 2. Cluster 3. Lights 4. Door 5. Convenience OBC3043045L OBC3043045L 6. Units Tire Pressure 7. Language This mode displays information related to 8.
Page 143 1. Driver Assistance Explanation Items • Smart Cruise Control To set the Distance, Acceleration, Reaction Speed of Smart Cruise Driving Control. Convenience For more details, refer to “Smart Cruise Control (SCC)” in chapter 7. To adjust Speed Limit Assist • Speed Limit Assist / Speed Limit Warning / Off Speed Limit For more details, refer to “Intelligent Speed Limit Assist (ISLA)”...
Page 144 Instrument cluster 2. Cluster Explanation Items To activate or deactivate the Wiper/ Light mode. Wiper/Lights When activated, the cluster display shows the selected Wiper/Light Display mode whenever you changed the mode. To set the traffic signs displayed. Traffic Signs Icy Road To activate or deactivate the icy road warning.
Page 145 4. Door Explanation Items • Enable on Shift : All doors will be automatically locked if the shift button is shifted from the P (Park) position to the R (Reverse), N (Neutral), or D (Drive) position. (only when the engine is running.) Automatically •...
Page 146 Instrument cluster 6. Units Explanation Items To select the speed unit. (km/h, MPH) Speed Unit To select the temperature unit. (°C,°F) Temperature Unit Fuel Economy Unit To select the fuel economy unit. (km/L, L/100km, MPG) To select the tire pressure unit. (psi, kPa, bar) Tire Pressure Unit 7.
Page 147: Trip Computer (Type A)
Trip computer (Type A) (if equipped) The trip computer is a microcomput- er-controlled driver information system that displays information related to driv- ing. Information Some driving information stored in the trip OBC3043039L OBC3043039L computer (for example Average Vehicle Speed) resets if the battery is disconnected. To change the trip mode, toggle the "...
Page 148 Instrument cluster Manual reset Accumulated Info display To clear the average fuel economy manu- Type A Type A ally, press the [OK] button on the steering wheel for more than 1 second when the average fuel economy is displayed. Automatic reset To automatically reset the average fuel economy after refueling, select the "Fuel Econ.
Page 149 The information is accumulated starting Drive Info display from the last reset. Type A Type A To manually reset the information, press and hold the OK button when viewing the accumulated driving info. The trip distance, the average fuel economy, and total driving time will reset simultane- ously.
Page 150 Instrument cluster The information is combined for each Digital speedometer ignition cycle. However, when the engine has been OFF for 4 hours or longer the Drive Info screen will reset. To manually reset the information, press and hold the OK button when viewing the Drive Info.
Page 151: Trip Computer (Type C)
Trip Computer (Type C) (if equipped) The trip computer is a microcomput- er-controlled driver information system that displays information related to driv- ing. Information Some driving information stored in the trip OBC3043039L OBC3043039L computer (for example, Average Vehicle Speed) resets if the battery is disconnected. To change the trip mode, toggle the "...
Page 152 Instrument cluster Drive info display Accumulated info display Type A Type A Type A Type A OBC3043048L OBC3043048L OBC3043046L OBC3043046L Type B Type B Type B Type B OBC3043049L OBC3043049L OBC3043047L OBC3043047L This display shows the accumulated trip This display shows the accumulated trip distance (1), the total driving time (2), and distance (1), the total driving time (2), and the average fuel economy (3).
Page 153 Auto Stop (if equipped) OBC3043050L OBC3043050L This message shows the information of Auto Stop. 4-43...
Page 154: Cluster Display Control
Instrument cluster Cluster display control OBC3043037L OBC3043037L 4-44...
Page 155 N Line N Line OBC3043051L OBC3043051L The cluster display modes can be changed by using the control switches. Function Switch Operation MODE button for changing View modes Press UP, DOWN switch for changing items in Utility view and Press Option menu SELECT/RESET switch for entering Option menu Press SELECT/RESET switch for retrieving assist information or...
Page 156: View Modes
Instrument cluster View modes Function View modes Utility view displays driving information such as the trip distance, fuel Utility economy and etc. Driving Assist view displays the status of the vehicle’s Driving Assistance Driving Assist systems. Turn By Turn view displays the state of the navigation. Turn by Turn The information provided may differ depending on which functions are applicable to your vehicle.
Page 157 Utility view Type A Type A Type B Type B In the Utility view, using the (UP, DOWN) switch, you may change through items in the following order. OJX1049011L/OJX1049065L OJX1049011L/OJX1049065L Drive info Trip distance (1), average fuel economy (2), and total driving time (3) are dis- played.
Page 158 Instrument cluster Type A Type A Type B Type B OTM070191L OTM070191L OJX1049012L/OJX1049067L OJX1049012L/OJX1049067L Attention level (if equipped) Accumulated info The driver’s attention level is shown Accumulated trip distance (1), average based on the driver’s driving pattern. fuel economy (2), and total driving time (3) are displayed.
Page 159 Additional information display Type A Type A Type B Type B OTMH040007 OTMH040007 Engine temperature (if equipped) OJX1049042L/OJX1049069L OJX1049042L/OJX1049069L Engine coolant temperature gauge dis- Drive info / Drive information play shows the temperature of the engine Drive information is displayed for 4 sec- coolant when the engine is running.
Page 160: Vehicle Settings (Infotainment System)
Instrument cluster Driving Assist view Vehicle settings (infotainment system) Vehicle Settings in the infotainment sys- tem provides user options for a variety of settings including door lock/unlock features, convenience features, driver assistance settings, etc. Vehicle Settings menu 1. Driver Assistance 2.
Page 161 Setting your vehicle OBC3043040L OBC3043040L 1. Press the SETUP button on the main keyboard. OBC3043041L OBC3043041L 2. Select ‘Vehicle’ and change the setting of the features. Information The infotainment system may change after software updates. For more information, refer to the manual provided in the info- tainment system and the quick reference guide.
Page 163 5. Convenience features Accessing your vehicle ................... 5-4 Remote key ........................ 5-4 Smart key ........................5-7 Immobilizer system ....................5-12 Door locks ......................5-13 Operating door locks from outside the vehicle ............. 5-13 Operating door locks from inside the vehicle ............5-15 Automatic door lock and unlock features ............
Page 164 Interior lights ....................5-53 Wipers and washers ..................5-55 Windshield wipers ....................5-55 Windshield washers ....................5-56 Rear window wiper and washer switch ..............5-57 Manual climate control system ..............5-58 Heating and air conditioning .................. 5-59 System operation ....................5-63 System maintenance ....................5-65 Automatic climate control system ...............
Page 165 5. Convenience features Exterior features ....................5-94 Roof rack ........................5-94 Infotainment system ..................5-95 USB port ........................5-95 Antenna ........................5-95 Steering wheel audio control ................. 5-96 Voice recognition ....................5-98 ® Bluetooth Wireless Technology hands-free ............5-98 How vehicle radio works ..................5-99...
Page 166: Convenience Features
“cluster Display” in chapter 4. Information OIB034040 OIB034040 Your HYUNDAI uses a remote key, which After unlocking the doors, the doors will you can use to lock or unlock a door (and lock automatically after 30 seconds unless tailgate) and even start the engine.
Page 167 Start-up Mechanical key For detailed information, refer to “Key Type A Type A Ignition Switch” in chapter 6. NOTICE To prevent damaging the remote key: • Keep the remote key away from water or any liquid and fire. If the inside of the remote key gets damp (due to drinks or moisture), or is heated, internal circuit may malfunction,...
Page 168 If you have a problem with the remote key, it is recommended that you contact an authorized HYUNDAI dealer. If the remote key is in close proximity to your mobile phone, the signal could be blocked by your mobile phone's nor- mal operational signals.
Page 169: Smart Key
Make sure the battery OIB044179 OIB044179 position is correct. Your HYUNDAI uses a Smart Key, which 3. Reinstall the rear cover of the remote you can use to lock or unlock a door (and key. tailgate) and even start the engine.
Page 170 Convenience features Even though you press the outside door Locking handle button, the doors will not lock and the chime will sound for three seconds if any of the following occurs : • The Smart Key is in the vehicle. •...
Page 171 Unlocking Tailgate unlocking To unlock: 1. Carry the smart key. 2. Either press the tailgate handle button or press the Tailgate Unlock button on the smart key for more than one sec- ond. 3. The hazard warning lights will blink two times.
Page 172 If you have a problem remove the mechanical key (2). Insert with the smart key, it is recommended the mechanical key into the key hole on that you contact an authorized HYUNDAI the door. dealer. To reinstall the mechanical key, put the...
Page 173 3. Reinstall the rear cover of the smart key. If you suspect your smart key might have sustained some damage, or you feel your smart key is not working correctly, it is recommended that you contact an authorized HYUNDAI dealer. 5-11...
Page 174: Immobilizer System
If the system repeatedly does not recog- nize the coding of the key, it is recom- mended that you contact your HYUNDAI dealer. Do not attempt to alter this system or add other devices to it. Electrical problems could result that may make your vehicle inoperable.
Page 175: Door Locks
DOOR LOCKS Operating door locks from Information outside the vehicle • Be careful when locking the door by Mechanical key mechanical key operation, only the driv- er’s door can be locked/unlocked. Remote key Remote key • When all doors are locked with the mechanical key, lock all doors by using the central door lock switch inside the vehicle.
Page 176 Convenience features Remote key Smart key OBC3050001 OBC3050001 OIB034040 OIB034040 To lock the doors, press the Door Lock button (1) on the remote key. To unlock the doors, press the Door Unlock button (2) on the remote key. Once the doors are unlocked, they may be opened by pulling the door handle.
Page 177: Operating Door Locks From Inside The Vehicle
With the central door lock/unlock Information switch • In cold and wet climates, door lock and door mechanisms may not work prop- erly due to freezing conditions. • If the door is locked/unlocked multiple times in rapid succession with either the vehicle key or door lock switch, the sys- tem may stop operating temporarily in order to protect the circuit and prevent...
Page 178: Automatic Door Lock And Unlock Features
Convenience features WARNING WARNING • The doors should always be fully If you stay in the vehicle for a long time closed and locked while the vehicle is while the weather is very hot or cold, in motion. If the doors are unlocked, there are risks of injuries or danger to the risk of being thrown from the life.
Page 179: Child-Protector Rear Door Locks
Child-protector rear door locks How to lock the door in case of emergency OBC3050012 OBC3050012 The child safety lock is provided to help OBC3050006 OBC3050006 prevent children seated in the rear from In case of an emergency (battery dis- accidentally opening the rear doors. charge, etc.), you can manually lock the door using the emergency key.
Page 180: Rear Occupant Alert (Roa)
Convenience features Rear Occupant Alert prevents the driver WARNING from leaving a passenger in the rear seats. Rear Occupant Alert provides informa- tion to the driver to check the rear seats but it does not detect whether there is Rear Occupant Alert Operation an object or passenger.
Page 181 HYUNDAI dealer. Arbitrary modification or altera- The hazard warning lights will blink and tion of the burglar alarm system may the chime will sound once to indicate the result in a malfunction.
Page 182: Steering Wheel
We recommend that you take your occur. If the temperature rises, the noise vehicle to an authorized HYUNDAI deal- will disappear. This is a normal condi- er and have the system checked as soon tion.
Page 183: Tilt Steering / Telescope Steering
Tilt steering / Telescope steering (if equipped) WARNING Never adjust the steering wheel while driving. You may lose steering control and cause severe personal injury, death or accidents. OBC3053007L OBC3053007L Information To change the steering wheel angle and After adjustment, sometimes the lock- height: release lever may not lock the steering 1.
Page 184: Heated Steering Wheel
Convenience features Heated steering wheel Horn (if equipped) Type A Type A OBC3053051L OBC3053051L OBC3053013L OBC3053013L Type B Type B When the ignition switch is in the ON position or when the engine is running, press the heated steering wheel button to warm the steering wheel.
Page 185: Inside Rearview Mirror
Inside rearview mirror Day/night rearview mirror (if equipped) Before you start driving, adjust the rear- view mirror to the center on the view through the rear window. WARNING Make sure your line of sight is not obstructed. Do not place objects in the rear seat, cargo area, or behind the rear headrests which could interfere with your vision through the rear window.
Page 186: Outside Rearview Mirrors
Convenience features Electric Chromic Mirror (ECM) Outside rearview mirrors (if equipped) OAI3059018 OAI3059018 OBC3050014 OBC3050014 Be sure to adjust mirror angles before The electric rearview mirror automatical- driving. ly controls the glare from the headlamp Your vehicle is equipped with both left- of the vehicle behind you in nighttime or hand and right-hand outside rearview low light driving conditions.
Page 187 NOTICE • Do not scrape ice off the mirror face; this may damage the surface of the glass. • If the mirror is jammed with ice, do not adjust the mirror by force. Use an approved de-icer (not radiator anti- freeze) spray, or a sponge or soft cloth with very warm water, or move the vehicle to a warm place and allow the...
Page 188 Convenience features Folding the outside rearview mirror • If 'Convenience Welcome mirror On door unlock' is selected in the User Settings mode on the cluster display, the User Settings mode on the cluster display, the outside mirror will fold or unfold automatically as follows: - The mirror will fold or unfold when the door is locked or unlocked by the...
Page 189: Windows
WINDOWS Power windows (if equipped) Left-hand drive Left-hand drive OBC3N050008 OBC3N050008 (5) Window opening and closing 5-27...
Page 190 Convenience features Right-hand drive Right-hand drive OBC3N050008AU OBC3N050008AU (5) Window opening and closing 5-28...
Page 191 The ignition switch must be in the ON Window opening and closing position to be able to raise or lower the windows. Each door has a Power Window driver has a Power Window Lock switch which can block the operation of rear passenger windows.
Page 192 OIB024001 OIB024001 authorized HYUNDAI dealer. If a window senses any obstacle while it is closing automatically, it will stop and WARNING lower approximately 30 cm (12 inches) to The automatic reverse feature doesn’t...
Page 193 NOTICE WARNING Do not install any accessories on the • NEVER leave the keys in your vehicle windows. The automatic reverse feature with unsupervised children, when the may not operate. engine is running. • NEVER leave any child unattended in Power window lock button the vehicle.
Page 194 Convenience features Remote window opening/closing Information function (if equipped) • The remote window opening/closing Type A Type A function will be operated only with the Safety Power Windows equipped. • The remote window opening/closing function may abruptly stop when you move away from your vehicle during operation.
Page 195 If your vehicle is equipped with a sunroof, Sunshade you can slide or tilt your sunroof with the sunroof switch located on the overhead console. OCN7050029 OCN7050029 Use the sunshade to block direct sunlight coming through the sunroof glass. Open or close the sunshade by hand. OBC3053020L OBC3053020L The sunroof can only be operated when...
Page 196 Convenience features Tilt open/close Slide open/close OCN7051144 OCN7051144 OCN7N051031 OCN7N051031 [1]: Tilt open • Push the sunroof switch rearward, the [2]: Tilt close sunshade and sunroof glass will slide open. • Push the sunroof switch upward, the sunroof glass will tilt open. •...
Page 197 NOTICE Automatic reversal • Do not continue to push the sun- roof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor could occur. • Continuous operations such as slide open/close, tilt open/close, etc., may cause the motor or sunroof system to malfunction.
Page 198: Sunroof
Convenience features Resetting the sunroof Information If the sunroof is not reset when the vehicle battery is disconnected or discharged, or the sunroof fuse is blown, the sunroof may not operate normally. Sunroof open warning OBC3053072L OBC3053072L In some circumstances resetting the sunroof operation may need to be per- formed.
Page 199: Hood
HOOD Hood Opening the hood OBC3N050012 OBC3N050012 4. Pull out the support rod from the hood. 5. Hold the hood opened with the sup- OBC3N050010 OBC3N050010 port rod. 1. Park the vehicle and set the parking brake. WARNING 2. Pull the release lever to unlatch the Support rod hood.
Page 200: Tailgate
Convenience features Closing the hood Tailgate 1. Before closing the hood, check the fol- Opening the tailgate lowing: • All filler caps in engine compart- ment must be correctly installed. • Gloves, rags or any other combus- tible materials must be removed from the engine compartment.
Page 201 NOTICE WARNING Make certain that you close the tailgate Always keep the tailgate lid completely before driving your vehicle. Possible closed while the vehicle is in motion. If damage may occur to the tailgate lift it is left open or ajar, poisonous exhaust cylinders and attaching hardware if the gases containing carbon monoxide (CO) tailgate is not closed prior to driving.
Page 202: Emergency Tailgate Safety Release
Convenience features Emergency tailgate safety Fuel filler door release Opening the fuel filler door 5 Door, N-line OIB047188 OIB047188 Your vehicle is equipped with the emer- OBC3053027L OBC3053027L gency tailgate safety release lever locat- 1. Turn the engine off. ed on the bottom of the tailgate. When someone is inadvertently locked in the luggage compartment, the tailgate can 3.
Page 203 Closing the fuel filler door 1. To install the fuel tank cap, turn it clockwise until it “Clicks”. 2. Close the fuel filler door until it is latched securely. WARNING Gasoline is highly flammable and explo- sive. Failure to follow these guidelines may result in SERIOUS INJURY or DEATH: •...
Page 204 • If the fuel filler cap requires replace- ment, we recommend that you use a genuine HYUNDAI cap or the equiv- alent specified for your vehicle. An incorrect fuel filler cap can result in a serious malfunction of the fuel system or emission control system.
Page 205: Exterior Lights
EXTERIOR LIGHTS Lighting control OBC3053029L OBC3053029L OBC3053081L OBC3053081L AUTO light (if equipped) To operate the lights, turn the knob at the When the light switch is in the AUTO end of the control lever to one of the fol- position, the position light and headlight lowing positions: will be turned ON or OFF automatically (1) OFF (O)
Page 206 Convenience features High beam operation OBC3053082L OBC3053082L Position light ( OBC3053083L OBC3053083L To turn on the high beam headlight, push The position light, license plate light and the lever away from you. instrument panel light are turned ON. The high beam indicator will light when the headlight high beams are switched To turn off the high beam headlight, pull the lever towards you.
Page 207 Turn signals and lane change signals OBC3053085L OBC3053085L To flash the high beam headlight, pull the lever towards you, then release the lever. OBC3053086L OBC3053086L The high beams will remain ON as long as you hold the lever towards you. To signal a turn, push down on the lever for a left turn or up for a right turn in posi- tion (A).
Page 208 Convenience features Front fog light (if equipped) Rear fog light OBC3053074L OBC3053074L OBC3053073L OBC3053073L Fog lamps are used to provide improved To turn on the rear fog lamp: visibility when visibility is poor due to fog, Position the light switch in the position rain or snow, etc.
Page 209 Battery saver function The purpose of this feature is to pre- vent the battery from being discharged. The system automatically turns off the position lamp when the driver turns the engine off and opens the driver-side door. With this feature, the position lamps will turn off automatically if the driver parks on the side of road at night.
Page 210 Convenience features NOTICE Headlight leveling device If the driver exits the vehicle through another door besides the driver door, the battery saver function does not operate and the headlight delay func- tion does not turn OFF automatically. This may cause the battery to discharge. To avoid battery discharge, turn OFF the headlights manually from the headlight switch before exiting the vehicle.
Page 211 WARNING If the function does not work proper- ly, we recommend that the system be inspected by an authorized HYUNDAI dealer. Do not attempt to inspect or replace the wiring yourself. Low Beam Assist-Static light While driving a corner, for greater vis-...
Page 212: High Beam Assist Settings
Convenience features High Beam Assist settings With the ignition switch in the ON posi- from the Settings menu to turn on High Beam Assist and deselect to turn off the function. WARNING For your safety, change the Settings OBC3053087L OBC3053087L after parking the vehicle at a safe loca- tion.
Page 213: High Beam Assist Operation
High Beam Assist, low beam ommend that you take your vehicle to an will turn on and High Beam Assist authorized HYUNDAI dealer and have the will turn off. system checked. - If the headlamp switch is placed...
Page 214 Convenience features Limitations of High Beam Assist Information High Beam Assist may not work properly For more details on the limitations of in the following situations: the front view camera, refer to “Forward • Light from an oncoming or front vehi- Collision-Avoidance Assist (FCA)”...
Page 215: Interior Lights
INTERIOR LIGHTS NOTICE Front map lamp: Press either of these lens to turn the map Do not use the interior lights for extend- lamp on or off. This light produces a spot ed periods when the engine is turned off beam for convenient use as a map lamp or the battery will discharge.
Page 216 Convenience features Rear lamps Glove box lamp (if equipped) OCN7050057 OCN7050057 OBC3N050018 OBC3N050018 Rear Interior Lamp Switch ( The glove box lamp comes on when the glove box is opened. Press this button to turn the interior lamp on and off. Luggage compartment lamp OBC3050032 OBC3050032...
Page 217: Wipers And Washers
WIPERS AND WASHERS Front windshield wiper/washer Front windshield wiper/washer Windshield wipers Operates as follows when the ignition switch is in the ON position. MIST ( ) : For a single wiping cycle, push the lever upward and release. The wipers will oper- ate continuously if the lever is held in this position.
Page 218: Windshield Washers
Convenience features AUTO (Automatic) control Windshield washers (if equipped) The rain sensor located at the top of the windscreen glass senses the amount of rainfall and controls the wiping cycle for the proper interval. The wiper opera- tion time will be automatically controlled, depending on rainfall.
Page 219: Rear Window Wiper And Washer Switch
CAUTION • To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. • To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry. •...
Page 220 Convenience features Left Hand Drive Left Hand Drive Right Hand Drive Right Hand Drive OBC3050100/OBC3050100R OBC3050100/OBC3050100R 1. Temperature control knob 2. Fan speed control knob 3. Mode selection knob 4. Air intake control button (recirculated air position or outside (fresh) air position) 5.
Page 221: Heating And Air Conditioning
Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. To improve the effectiveness of heating and cooling : - Heating: - Cooling: 3. Set the temperature control to the desired position. 4. Set the air intake control to Fresh mode. 5.
Page 222 Convenience features Floor-Level (A, C, D, E) Most of the air flow is directed to the floor, with a small amount of the air being directed to the windshield, side window defrosters and side vents. OBC3050103TU OBC3050103TU Floor/Defrost-Level The mode selection knob controls the (A, C, D, E) direction of the air flow through the ven- tilation system.
Page 223 Air intake control OBC3053010L OBC3053010L Instrument panel vents OBC3050105TU OBC3050105TU The instrument panel vent air flow can be The air intake control button is used to directed up/down or left/right using the select either Fresh mode (outside air) or vent adjustment lever. Recirculation mode (cabin air).
Page 224 Convenience features Fan speed control Information Operating the system primarily in Fresh mode is recommended. Use Recirculation mode temporarily only when needed. Prolonged operation of the heater in Recir- culation mode and without the A/C ON can cause fogging of the windshield. In addition, prolonged use of the A/C ON in Recirculation mode may result in exces- sively dry, dehumidified air in the cabin...
Page 225: System Operation
System operation Air conditioning HYUNDAI Air Conditioning Systems are Ventilation filled with R-134a or R1234yf refrigerant. 1. Select the Face Level mode. 1. Start the engine. 2. Set the air intake control to fresh 2. Push the air conditioning button.
Page 226 Convenience features Air conditioning system operation tips Information • If the vehicle has been parked in direct • When using the air conditioning system, sunlight during hot weather, open the monitor the temperature gauge closely windows for a short time to let the hot while driving up hills or in heavy traf- air inside the vehicle escape.
Page 227: System Maintenance
Overfilling also has a bad influ- ence on the air conditioning system. Therefore, if abnormal operation is found, we recommend that the system be inspected by an authorized HYUNDAI dealer. NOTICE OIK047401L OIK047401L It is important that the correct type and amount of oil and refrigerant is used.
Page 228 Convenience features Example Example WARNING • Type A • Type A Vehicles equipped with R-1234yf Since the refrigerant is mild- ly flammable and operated at high pressure, the air con- ditioning system should only be serviced by trained and certified technicians. It is important that the correct type and amount of oil and OHYK059004...
Page 229 Left Hand Drive Left Hand Drive Right Hand Drive Right Hand Drive OBC3050108/OBC3050108R OBC3050108/OBC3050108R 1. Temperature control switch 2. Fan speed control switch 3. AUTO (automatic control) button 4. OFF button 5. Front window defroster button 6. Mode selection button 7.
Page 230: Automatic Heating And Air Conditioning
Convenience features - Fan speed control toggle switch Automatic heating and air conditioning The selected function will be con- trolled manually while other func- tions operate automatically. • For your convenience, use the AUTO button and set the temperature to 22°C (72°F).
Page 231: Manual Heating And Air Conditioning
Manual heating and air conditioning The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons selected. When pressing any button except the AUTO button while using automatic operation, the functions not selected will be controlled automatically.
Page 232 Convenience features OBC3050113 OBC3050113 OBC3050112 OBC3050112 The mode selection button controls the Defrost-Level (A, D) direction of the air flow through the ven- Most of the air flow is directed to the tilation system. windshield with a small amount of air directed to the side window defrosters.
Page 233: Instrument Cluster
Temperature control Air intake control OBC3050111 OBC3050111 OBC3050114 OBC3050114 The temperature will increase by pushing This is used to select the outside (fresh) the switch to up. air position or recirculated air position. The temperature will decrease by push- To change the air intake control position, ing the switch to down.
Page 234: Convenience Features
Convenience features Fan speed control Information Operating the system primarily in Fresh mode is recommended. Use Recirculation mode temporarily only when needed. Prolonged operation of the heater in Recir- culation mode and without the A/C ON can cause fogging of the windshield. In addition, prolonged use of the A/C ON in Recirculation mode may result in exces- sively dry, dehumidified air in the cabin...
Page 235: System Operation
Air conditioning System operation Ventilation 1. Select the Face Level mode. 2. Set the air intake control to fresh mode. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed. Heating OBC3050116 OBC3050116 1.
Page 236 Convenience features Air conditioning Operation Tips • To keep dust or unpleasant fumes from HYUNDAI Air Conditioning Systems are entering the vehicle through the ven- filled with R-134a or R-1234yf refrigerant. tilation system, temporarily set the 1. Start the engine.
Page 237 NOTICE Air conditioning system operation tips • If the vehicle has been parked in direct • When using the air conditioning sunlight during hot weather, open the system, monitor the temperature windows for a short time to let the hot gauge closely while driving up hills air inside the vehicle escape.
Page 238: System Maintenance
Overfilling also has a bad influ- ence on the air conditioning system. Therefore, if abnormal operation is found, we recommend that the system be inspected by an authorized HYUNDAI dealer. NOTICE OIK047401L OIK047401L...
Page 239 Example Example WARNING • Type A • Type A Vehicles equipped with R-1234yf Since the refrigerant is mild- ly flammable and operated at high pressure, the air con- ditioning system should only be serviced by trained and certified technicians. It is important that the correct type and amount of oil and OHYK059004...
Page 240: Manual Climate Control System
Convenience features Manual climate control system WARNING To defog inside windshield Windshield heating Do not use the position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface of the windshield to fog up, causing loss of visibility.
Page 241: Automatic Climate Control System
To defrost outside windshield Automatic climate control system To defog inside windscreen OBC3050119 OBC3050119 1. Set the fan speed to the highest (extreme right) position. OBC3050120 OBC3050120 2. Set the temperature to the extreme 1. Select desired blower speed. hot position. 2.
Page 242: Auto Defogging System (Only For Automatic Climate Control System)
Convenience features To defrost outside windscreen Auto defogging system (only for automatic climate control system, if equipped) OBC3050121 OBC3050121 1. Set blower speed to the highest posi- OBC3050124 OBC3050124 tion. 2. Set temperature to the extreme hot Auto defogging helps reduce the pos- (HI) position.
Page 243: Defroster
Defroster To cancel or reset the Auto Defogging System Press the front windscreen defroster NOTICE button for 3 seconds when the ignition switch is in the ON position. To prevent damage to the conductors When the Auto Defogging System is can- bonded to the inside surface of the rear celled, defrost button indicator will blink window, never use sharp instruments or...
Page 244 Convenience features Rear window defroster Information Manual climate control system Manual climate control system • If there is heavy accumulation of snow on the rear window, brush it off before operating the rear defroster. • The rear window defroster automatically turns off after approximately 20 minutes or when the ignition switch is in the LOCK/OFF position.
Page 245: Storage Compartment
Center console storage WARNING Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for extended periods. WARNING ALWAYS keep the storage compartment covers closed securely while driving.
Page 246: Glove Box
Convenience features Glove box OBC3N050025 OBC3N050025 To open the glove box, pull the lever and the glove box will automatically open. Close the glove box after use. WARNING ALWAYS close the glove box door after use. An open glove box door can cause seri- ous injury to the passenger in an acci- dent, even if the passenger is wearing a seat belt.
Page 247: Ashtray
Ashtray (if equipped) Cup holder OGB044045 OGB044045 OGB044046 OGB044046 To use the ashtray, open the cover. Cups or small beverages cups may be placed in the cup holders. To clean the ashtray: The plastic receptacle should be removed by lifting the plastic ashtray receptacle WARNING upward after turning the cover counter- •...
Page 248: Sliding Armrest
Convenience features NOTICE Sunvisor • Keep your drinks sealed while driving to prevent spilling your drink. If liquid spills, it may get into the vehicle’s electrical/electronic system and dam- age electrical/electronic parts. • When cleaning spilled liquids, do not dry the cup holder using hot tem- peratures.
Page 249: Power Outlet
NOTICE Power outlet (if equipped) To prevent damage to the Power Out- lets : • Use the power outlet only when the engine is running and remove the accessory plug after use. Using the accessory plug for prolonged peri- ods of time with the engine off could cause the battery to discharge.
Page 250: Usb Charger
Convenience features USB charger Wireless cellular phone charging system (if equipped) OBC3053065L OBC3053065L The USB charger is located inside the OBC3053066L OBC3053066L [A] : Charging pad USB charger into the USB port, and re- There is a wireless cellular phone charger charge a smart phone or a tablet PC.
Page 251 If your cellular phone is not charging: To charge a cellular phone - Slightly change the position of the cel- The wireless cellular phone charging sys- lular phone on the charging pad. tem charges only the Qi-enabled cellular phones ( ).
Page 252 Convenience features NOTICE • When charging some cellular phones with a self-protection feature, the • The wireless cellular phone charging wireless charging speed may decrease system may not support certain cel- and the wireless charging may stop. lular phones, which are not verified •...
Page 253: Clock
Clock WARNING WARNING Do not adjust the clock while driving. You may lose your steering control and cause severe personal injury or acci- dents. The infotainment system may change after software updates. For more infor- mation, refer to the manual provided in the infotainment system and the quick reference guide.
Page 254: Floor Mat Anchor(S)
To avoid any interference with pedal operation, HYUNDAI recommends that the HYUN- DAI floor mat designed for use in your vehicle be installed. OAC3059049TU...
Page 255: Luggage Net (Holder)
Disconnect the strap (1) from the holder If necessary, we recommend that you if you want to return the cover to the contact an authorized HYUNDAI dealer to original position.To remove the cargo obtain a luggage net. area cover completely, lift the cover to a 50-degree angle and pull it out (2).
Page 256: Convenience Features
Convenience features Roof rack WARNING • The following specification is the maximum weight that can be loaded onto the roof rack. Distribute the load as evenly as possible onto the roof rack and secure the load firmly. ROOF 70 kg (154 lbs) RACK EVENLY DISTRIBUTED Loading cargo or luggage in excess of...
Page 257: Usb Port
Antenna Information Pole antenna (if equipped) • If you install an aftermarket HID head- lamp, your vehicle’s audio and electronic device may malfunction. • Prevent chemicals such as perfume, cos- metic oil, sun cream, hand cleaner, and air freshener from contacting the interi- or parts because they may cause damage or discoloration.
Page 258: Steering Wheel Audio Control
Do not operate audio remote control buttons simultaneously. ply radio main cable. Thus if you want to insert Aftermarket audio or OEM audio to listen radio broadcasting service, we recommend to use the feeder cable avail- able with an authorized HYUNDAI dealer. 5-96...
Page 259 VOLUME (VOL + / VOL -) (1) MODE ( ) (3) • Move the VOLUME toggle switch up to Press the MODE button to select RADIO/ increase volume. MEDIA/Bluetooth Audio, etc. • Move the VOLUME toggle switch down to decrease volume. MUTE ( ) (4, if equipped) •...
Page 260: Voice Recognition
Convenience features ® Voice recognition (if equipped) Bluetooth Wireless Technology hands-free (if equipped) OBC3053043L OBC3053043L A wide range of infotainment functions OBC3053044L OBC3053044L can be commanded with voice recogni- tion (1). For more information, refer to the manual provided in the infotainment system and the quick reference guide.
Page 261: How Vehicle Radio Works
How vehicle radio works AM (MW, LW) reception FM reception OJF045309L OJF045309L AM broadcasts can be received at greater OJF045308L OJF045308L distances than FM broadcasts. This is AM and FM radio signals are broadcast because AM radio waves are transmit- from transmitter towers located around ted at low frequencies.
Page 262 Convenience features FM radio station JBM004 JBM004 • Fading - As your vehicle moves away OJF045310L OJF045310L from the radio station, the signal will FM broadcasts are transmitted at high weaken and sound will begin to fade. frequencies and do not bend to follow When this occurs, we suggest that you select another stronger station.
Page 263 Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equip- ment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.
Page 265: Driving Your Vehicle
6. Driving your vehicle Before driving ....................6-4 Before entering the vehicle ..................6-4 Before starting ......................6-4 Ignition switch ....................6-5 Key ignition switch ....................6-5 Engine Start/Stop button ..................6-8 Manual transmission ..................6-13 Manual transmission operation ................6-13 Good driving practices ..................... 6-15 Intelligent Manual Transmission (IMT) ............6-16 Intelligent Manual Transmission (IMT) operation ..........6-16 Automatic transmission ................6-19...
Page 266 Start Stop Coasting (SSC) (for 48V MHEV) ..........6-53 SSC operating conditions ..................6-53 Engine restarting conditions .................. 6-53 Drive mode integrated control system ............6-54 Active air flap ....................6-57 Malfunction ......................6-57 Special driving conditions ................6-58 Hazardous driving conditions ................6-58 Rocking the vehicle ....................
Page 267 If you hear a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the vehicle, we recommend that the exhaust system be checked as soon as possible by an authorized HYUNDAI dealer. Do not run the engine in an enclosed area.
Page 268: Before Driving
Driving your vehicle BEFORE DRIVING Before entering the vehicle WARNING • Be sure all windows, outside mirror(s), To reduce the risk of SERIOUS INJURY or and outside lights are clean and unob- DEATH, take the following precautions: structed. • ALWAYS wear your seat belt. All pas- •...
Page 269: Ignition Switch
IGNITION SWITCH Key ignition switch (if equipped) WARNING To reduce the risk of SERIOUS INJURY or DEATH, take the following precautions: • NEVER allow children or any person who is unfamiliar with the vehicle to touch the ignition switch or related parts.
Page 270 Driving your vehicle Key ignition switch positions Switch Action Notice Position The steering wheel locks to protect The ignition key can be removed in the vehicle from theft. LOCK the LOCK position. (if equipped) The steering wheel unlocks. If difficulty is experienced turning the ignition switch to the ACC Electrical accessories are usable.
Page 271 Starting the engine Information • Do not wait for the engine to warm up WARNING while the vehicle remains stationary. Start driving at moderate engine speeds. • Always wear appropriate shoes when (Steep accelerating and decelerating operating your vehicle. Unsuitable should be avoided.) shoes, such as high heels, ski boots, •...
Page 272: Engine Start/Stop Button
Driving your vehicle Engine Start/Stop button WARNING (if equipped) To turn the engine off in an emergency: Press and hold the Engine Start/ Stop button for more than two seconds OR rapidly press and release the Engine Start/Stop button three times (within 3 seconds).
Page 273: Manual Transmission
Engine Stop/Start button positions - Vehicle with manual transmission/intelligent manual transmission Action Notice Button Position • To turn off the engine, stop If the steering wheel is not locked the vehicle and then press the properly when you open the Engine Start/Stop button.
Page 274 Driving your vehicle Engine Stop/Start button positions - Vehicle with automatic transmission / dual clutch transmission Action Notice Button Position • To turn off the engine, press the If the steering wheel is not locked Engine Start/Stop button with properly when you open the shift lever in P (Park).
Page 275 Vehicle with manual transmission: Starting the engine 1. Always carry the smart key with you. 2. Make sure the parking brake is applied. WARNING 3. Make sure the shift lever is in N • Always wear appropriate shoes when (Neutral). operating your vehicle.
Page 276 Driving your vehicle NOTICE To prevent damage to the vehicle: Do not press the Engine Start/ Stop but- ton for more than 10 seconds except when the stop lamp fuse is blown. When the brake switch fuse is blown, you can’t start the engine normally. Replace the fuse with a new one.
Page 277: Manual Transmission Operation
Type A Type A WARNING Before leaving the driver’s seat, always make sure the shift lever is in in the 1st gear when the vehicle is parked on an uphill and in R (Reverse) on a downhill, set the parking brake, and place the ignition switch in the LOCK/OFF posi- tion.
Page 278 Driving your vehicle Using the clutch (if equipped) Downshifting The clutch pedal should be depressed all Downshift when you must slow down in the way to the floor before: heavy traffic or drive up a steep hill to prevent engine load. - Starting the engine Also, downshifting reduces the chance The engine will not start without...
Page 279: Good Driving Practices
Instead, slow down before pulling careful when braking, accelerating or back into the travel lanes. shifting gears. On a slippery surface, • HYUNDAI recommends you follow all an abrupt change in vehicle speed can posted speed limits. cause the drive wheels to lose traction and may cause loss of vehicle control resulting in an accident.
Page 280: Intelligent Manual Transmission (Imt)
Driving your vehicle Intelligent manual transmission system Type C Type C use E-Clutch (Electronic Clutch) and SSC (Start Stop Coasting) technology. When the vehicle is in coasting driving, auto- matically cuts off the engine power in order to reduce fuel consumption. Intelligent Manual Transmission (IMT) operation Type A...
Page 281 CAUTION WARNING • When downshifting from fifth gear • Before leaving the driver’s seat, to fourth gear, caution should be always set the parking brake fully and taken not to inadvertently press the shut the engine off. Then make sure shift lever sideways in such a man- the transmission is shifted into the ner that the second gear is engaged.
Page 282 Driving your vehicle Downshifting WARNING When you must slow down in heavy traf- • Always buckle-up! In a collision, an fic or while driving up steep hills, down- unbelted occupant is significantly shift before the engine starts to labor. more likely to be seriously injured or Downshifting reduces the chance of stall- killed than a properly belted occu- ing and gives better acceleration when...
Page 283: Automatic Transmission Operation
Depress the brake pedal and press the shift button while moving the shift lever. Depress the brake pedal and press the shift button while moving the shift lever. Press the shift button while moving the shift lever. Press the shift button while moving the shift lever. The shift lever can freely operate.
Page 284 • If the warning message continues to • If the warning message continues to appear, we recommend that you con- appear, we recommend that you con- tact an authorized HYUNDAI dealer. tact an authorized HYUNDAI dealer. 6-20...
Page 285 WARNING • Shifting into P (Park) while the vehicle is in motion may cause you to lose control of the vehicle. • After the vehicle has stopped, always make sure the shift lever is in P (Park), apply the parking brake, and turn the engine off.
Page 286 Driving your vehicle D (Drive) Information This is the normal driving position. The • Only the six forward gears can be select- transmission will automatically shift ed in Manual Shift Mode. To reverse or through a 6-gear sequence, providing park the vehicle, move the shift lever to the best fuel economy and power.
Page 287 Do not stop or park over flammable If you need to use the shift-lock release, materials, such as dry grass, paper or we recommend that the system be leaves. They may ignite and cause a fire. inspected by an authorized HYUNDAI dealer immediately. 6-23...
Page 288: Good Driving Practices
Instead, slow down before pulling possibly even brake failure. back into the travel lanes. • When driving in manual shift mode, • HYUNDAI recommends you follow all slow down before shifting to a lower posted speed limits. gear. Otherwise, the lower gear may not be engaged if the engine RPMs are outside of the allowable range.
Page 289: Dual Clutch Transmission Operation
Depress the brake pedal and press the shift button while moving the shift lever. Depress the brake pedal and press the shift button while moving the shift lever. Press the shift button while moving the shift lever. Press the shift button while moving the shift lever. The shift lever can freely operate.
Page 290 Driving your vehicle • The dual clutch transmission incorpo- • When you turn the engine on and off, rates a dry-type dual clutch mecha- you may hear clicking sounds as the nism, which allows for better accelera- system goes through a self-test. This tion performance and increased fuel is a normal sound for the dual clutch efficiency while driving.
Page 291 If the warning messages on the clus- (Reverse). ter continues to blink, we recommend • Do not put the shift lever in N (Neutral) that you contact an authorized HYUNDAI while driving. dealer. WARNING Due to transmission failure, you may...
Page 292 • Move the vehicle to a safe location contact an authorized HYUNDAI dealer. and shift the gear to P (Park) with the engine running. Wait until the trans- mission is sufficiently cooled down.
Page 293 Transmission ranges The indicator in the instrument cluster displays the shift lever position when the ignition switch is in the ON position. P (Park) Always come to a complete stop before shifting into P (Park). To shift from P (Park), you must depress firmly on the brake pedal and make sure OBC3070108TU OBC3070108TU...
Page 294 Driving your vehicle R (Reverse) Use this position to drive the vehicle backward. NOTICE + (UP) + (UP) Always come to a complete stop before shifting into or out of R (Reverse); you may damage the transmission if you shift into R (Reverse) while the vehicle - (DOWN) - (DOWN) is in motion.
Page 295 Paddle shifter (if equipped) Information • Only the seven forward gears can be selected in Manual Shift Mode. To reverse or park the vehicle, move the shift lever to the R (Reverse) or P (Park) position as required. • Downshifts are made automatically when the vehicle slows down.
Page 296: Parking
3. Press the shift-lock release button. 4. Press and hold the lock release button on the shift lever. 5. Move the shift lever. If you need to use the shift-lock release, we recommend that the system be inspected by an authorized HYUNDAI dealer immediately. 6-32...
Page 297: Good Driving Practices
Instead, slow down before pulling brakes overheating, brake wear and back into the travel lanes. possibly even brake failure. • HYUNDAI recommends you follow all • When driving in manual shift mode, posted speed limits. slow down before shifting to a lower gear.
Page 298: Braking System
Driving your vehicle BRAKING SYSTEM • When descending down a long or Power brakes steep hill, downshift to a lower gear Your vehicle has power-assisted brakes in order to control your speed with- that adjust automatically through normal out using the brake pedal excessive- usage.
Page 299: Rear Drum Brakes
(2). If the parking brake does not release or does not release all the way, we recom- mend that the system be checked by an authorized HYUNDAI dealer. OGB054006 OGB054006 WARNING Always set the parking brake before leav-...
Page 300: Anti-Lock Brake System (Abs)
Driving your vehicle Parking brake warning light Anti-lock Brake System (ABS) Check the Parking Brake Warning Light by placing the WARNING ignition switch to the ON position (do not start the An Anti-Lock Braking System (ABS) or engine). an Electronic Stability Control (ESC) sys- This light will illuminate when the parking tem will not prevent accidents due to brake is applied with the ignition switch...
Page 301 To reduce the risk of serious Depress your brake pedal as hard as injury or death, we recommend that you possible. contact your HYUNDAI dealer as soon When you apply your brakes under con- as possible. ditions which may lock the wheels, you...
Page 302: Electronic Stability Control (Esc)
Driving your vehicle Electronic Stability Control ESC operation (ESC) ESC ON condition When the ignition switch is in the ON position, the ESC and the ESC OFF indi- cator lights illuminate for approximately three seconds. After both lights go off, the ESC is enabled.
Page 303 ESC (engine management) and be checked by an authorized HYUNDAI the brake control function of ESC (brak- dealer as soon as possible. ing management) are disabled.
Page 304: Vehicle Stability Management (Vsm)
Driving your vehicle ESC OFF usage Vehicle Stability Management (VSM) When Driving The ESC OFF mode should only be used The Vehicle Stability Management (VSM) briefly to help free the vehicle if stuck in is a function of the Electronic Stability snow or mud, by temporarily stopping Control (ESC) system.
Page 305 This is normal and it means your the vehicle be checked by an authorized VSM is active. HYUNDAI dealer as soon as possible. Information NOTICE Driving with wheels and tires with dif- The VSM does not operate when: ferent sizes may cause the VSM system •...
Page 306: Hill-Start Assist Control (Hac)
Driving your vehicle Hill-Start Assist Control (HAC) Emergency Stop Signal (ESS) Hill-Start Assist Control helps prevent The Emergency Stop Signal system alerts the vehicle from rolling backwards when the driver behind by blinking the stop starting a vehicle from a stop on a hill. light when the vehicle is braked rapidly The system operates the brakes auto- and severely.
Page 307: Multi-Collision Brake (Mcb) (If
Multi-Collision Brake (MCB) (if System off equipped) Multi-Collision Brake is canceled in the following situations: Multi-Collision Brake controls the brake - The accelerator pedal is depressed automatically in the event of an accident over a certain level. where the air bag deploys to reduce - The vehicle stops.
Page 308: Good Braking Practices
(Neutral) position (for automatic trans- so and we recommend that you call an mission/dual clutch transmission vehi- authorized HYUNDAI dealer for assis- cle), then apply the parking brake, and tance. place the ignition switch in the LOCK/ DO NOT drive with your foot resting on OFF position.
Page 309: Activating The Isg
Your vehicle may be equipped with the Deactivating the ISG ISG system, which reduces fuel con- Type A Type A sumption by stopping and restarting the engine automatically. The engine starts automatically as soon as the starting conditions are met. NOTICE When the engine automatically starts by the ISG system, some warning lights...
Page 310 Driving your vehicle Auto stop To stop the engine in idle stop mode (for 48V MHEV) Manual transmission/intelligent manual transmission Three versions of idle stop are available for MHEV which is equipped with manual transmission or intelligent manual trans- mission. - Conventional Idle STOP •...
Page 311 Automatic transmission/dual clutch Auto start transmission To restart the engine from idle stop mode - Conventional Idle STOP (except 48V MHEV) • Decrease the vehicle speed to 0 Manual transmission/intelligent manual km/h (0 mph). transmission • Press the brake pedal. Vehicle which is equipped with manual transmission or intelligent manual trans- - Extended Idle STOP...
Page 312 Driving your vehicle NOTICE Automatic transmission/dual clutch transmission 1. Late restart function is only operated - Release the brake pedal. when it is on a level ground and the The engine will start and the green AUTO vehicle is stable. STOP indicator ( ) on the instrument 2.
Page 313: Condition Of Isg System Operation
Condition of ISG system The engine will also restart automati- cally without the driver’s any actions operation if the following occurs: The ISG system will operate under the • The brake vacuum pressure is low. following condition: • You have exceeded the maximum •...
Page 314: Isg Indication
Driving your vehicle ISG Indication Type A Type A The ISG System is indicated by lamp on the instrument cluster. If your vehicle is equipped with a supervision cluster, the notice will illuminate on the cluster display. OBC3063019L OBC3063019L Type B Type B OBC3060009 OBC3060009...
Page 315: Isg Malfunction
2nd position. If the ISG OFF button light continues to be illuminated in spite of the proce- dure, have your vehicle inspected by a professional workshop as soon as possible. We recommends to contact an authorized HYUNDAI dealer. 6-51...
Page 316 Driving your vehicle NOTICE If you want to use the ISG function, the battery sensor needs to be calibrated for approximately 4 hours with the igni- tion off and then, turn the engine on and off 2 or 3 times. WARNING When the engine is in Idle Stop mode, it’s possible to restart the engine with-...
Page 317: Ssc Operating Conditions
Start Stop Costing helps reduce fuel con- Engine restarting conditions sumption by automatically stopping the • The engine will restart manually when: engine when the vehicle is in motion. The engine is stopped when vehicle speed - The accelerator pedal is depressed can be maintained without the accelera- - The brake pedal is depressed tor pedal being depressed.
Page 318: Drive Mode Integrated Control System
Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM When NORMAL mode is selected, it is not displayed on the instrument cluster. ECO mode : ECO mode helps improve fuel efficiency for eco-friendly driving. NORMAL mode : NORMAL mode pro- vides smooth driving and comfortable riding.
Page 319 When ECO mode is activated: ECO mode (if equipped) • The acceleration response may be When the Drive Mode is set to slightly reduced as the accelerator the ECO mode, the engine pedal is depressed moderately. and transmission control log- ic are changed to maximize •...
Page 320 Driving your vehicle SPORT mode The SPORT mode manages the driving dynamics by automatically adjusting the steering effort, the engine and transmission control log- ic for enhanced driving per- formance. • When the SPORT mode is selected by pressing the DRIVE MODE button, the SPORT indicator will illuminate.
Page 321: Malfunction
10 minutes. If the pop-up remains up, we recommend that you contact an authorized HYUNDAI dealer. CAUTION • Regardless of the pop-up, if the air flaps aren’t in the same position, stop...
Page 322: Hazardous Driving Conditions
Driving your vehicle Hazardous driving conditions Rocking the vehicle When hazardous driving elements are If it is necessary to rock the vehicle to encountered such as water, snow, ice, free it from snow, sand, or mud, first turn mud and sand, take the following pre- the steering wheel right and left to clear cautions: the area around your front wheels.
Page 323: Smooth Cornering
NOTICE Driving in the rain If you are still stuck after rocking the Rain and wet roads can make driving vehicle a few times, have the vehicle dangerous. Here are a few things to con- pulled out by a tow vehicle to avoid sider when driving in the rain or on slick engine overheating, possible damage to pavement:...
Page 324: Driving In Flooded Areas
Driving your vehicle Hydroplaning Highway driving If the road is wet enough and you are Tires going fast enough, your vehicle may have Adjust the tire inflation, as specified. little or no contact with the road surface Under-inflation may overheat or damage and actually ride on the water.
Page 325: Reducing The Risk Of A Rollover
Reducing the risk of a rollover (if WARNING equipped) In a rollover crash, an unbelted person Your multi-purpose passenger vehicle is is significantly more likely to die than a defined as a Sports Utility Vehicle (SUV) person wearing a seat belt. Make sure or Crossover Utility Vehicle (CUV).
Page 326: Winter Driving
Driving your vehicle WINTER DRIVING The severe weather conditions of winter Snow tires quickly wear out tires and cause other problems. To minimize winter driving WARNING problems, you should take the following suggestions: Snow tires should be equivalent in size and type to the vehicle’s standard tires.
Page 327 If tire chains must be used, use skids. genuine HYUNDAI parts or the equivalent • Do not install studded tires without first specified for your vehicle and install the checking local and municipal regulations tire chain after reviewing the instructions for possible restrictions against their use.
Page 328: Winter Precautions
Inspect the battery and cables, as specified in the chapter 9. The battery charging level can be checked NOTICE by an authorized HYUNDAI dealer or in a service station. When using tire chains: • Wrong size chains or improperly Change to “winter weight”...
Page 329 Window washer anti-freeze solution is Putting objects or materials in the engine available from an authorized HYUNDAI compartment may cause an engine fail- dealer, and most vehicle accessory out- ure or combustion, because they may lets.
Page 330 We recommend • When a trailer is not used, detach it from that you ask an authorized HYUNDAI the vehicle so that the license plate is vis- dealer for further details before towing. ible.
Page 331: If You Decide To Pull A Trailer
It should never weigh more than the maximum trailer weight with trailer HYUNDAI dealer for further informa- tion on additional requirements such as brakes. But even that can be too heavy. a towing kit, etc.
Page 332 Driving your vehicle Tongue load WARNING Take the following precautions: • Never load a trailer with more weight in the rear than in the front. The front should be loaded with approximately 60% of the total trailer load; the rear should be loaded with approximately 40% of the total trailer load.
Page 333: Trailer Towing Equipment
Do not attach for this work. rental hitches or other bumper-type hitches to them. Use only a frame- mounted hitch that does not attach to the bumper. • A HYUNDAI trailer hitch accessory is available at an authorized HYUNDAI dealer. 6-69...
Page 334: Driving With A Trailer
We recommend that you have the sys- To move the trailer to the right, move tem checked by an authorized HYUNDAI your hand to the right. Always back up dealer as soon as possible.
Page 335 Driving on hills Parking on hills Reduce speed and shift to a lower gear Generally, if you have a trailer attached before you start down a long or steep to your vehicle, you should not park your downgrade. If you don’t shift down, you vehicle on a hill.
Page 336: Maintenance When Towing A Trailer
Driving your vehicle Ready to leave after parking on a Maintenance when towing a hill trailer 1. With the shift lever to P (Park, for Your vehicle will need service more automatic transmission/dual clutch often when you regularly pull a trailer. transmission vehicle) or neutral (for Important items to pay particular atten- manual transmission vehicle), apply...
Page 337: Vehicle Weight
VEHICLE WEIGHT Two labels on your driver’s door sill show GVW (Gross Vehicle Weight) how much weight your vehicle was This is the Base Curb Weight plus actual designed to carry: the Tire and Loading Cargo Weight plus passengers. Information Label and the Certification Label.
Page 339: Driver Assistance System
7. Driver assistance system Driving Safety Forward Collision–Avoidance Assist (FCA) (Front view camera only) ...... 7-2 Forward Collision–Avoidance Assist (FCA) (Sensor fusion type) ......7-14 Lane Keeping Assist (LKA) ..................7-31 Blind-Spot Collision Warning (BCW)................. 7-37 Blind-Spot Collision-Avoidance Assist (BCA) ............7-46 Manual Speed Limit Assist (MSLA) ................7-58 Intelligent Speed Limit Assist (ISLA) ................7-61 Driver Attention Warning (DAW) ................7-69 Driving Convenience...
Page 340 • If the detecting sensors have been replaced or repaired, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer. • Never install any accessories or stick- ers on the front windshield, or tint the front windshield.
Page 341 The driver can monitor Forward Colli- sion-Avoidance Assist ON/OFF status from the Settings menu. If the warn- ing light remains ON when Forward Col- lision-Avoidance Assist is ON, we recom- mend to have the vehicle inspected by an authorized HYUNDAI dealer.
Page 342: Driving Safety
Driver assistance system Forward Safety warning timing Warning methods OBC3073206L OBC3073206L OBC3073205L OBC3073205L • With the engine on, select User settings The Warning Methods can be set with the engine on. Select Forward Safety Warning Timing from from the the settings menu in the instrument settings menu in the instrument clus- cluster or ter or...
Page 343 Forward Collision-Avoidance Emergency Braking Assist operation Warning and control The basic function for Forward Colli- sion-Avoidance Assist is to warn and help control the vehicle depending on the col- lision risk level: • Collision Warning • Emergency Braking • Stopping vehicle and ending brake control OBC3073003L OBC3073003L...
Page 344: Forward Collision-Avoidance Assist (Fca) (Front View Camera Only)
Driver assistance system Stopping vehicle and ending brake WARNING control Take the following precautions when using Forward Collision-Avoidance Assist: • For your safety, change the Settings after parking the vehicle at a safe location. • The driver should hold the responsi- bility to control the vehicle.
Page 345: Forward Collision-Avoidance Assist (Fca) (Sensor Fusion Type)
We recommend that the vehicle • Forward Collision-Avoidance Assist be inspected by an authorized HYUNDAI will operate under certain conditions dealer. by judging the risk level based on the condition of the oncoming vehi- cle, driving direction, speed and sur- roundings.
Page 346 Driver assistance system Forward Collision-Avoidance Assist WARNING disabled • Even though the warning message or warning light does not appear on the instrument cluster, Forward Collision- Avoidance Assist may not properly operate. • Forward Collision-Avoidance Assist may not properly operate in an area (for example, open terrain), where any objects are not detected after turning ON the engine.
Page 347 • The surrounding is very dark, such as in • You are departing or returning to the a tunnel, etc. lane • The brightness changes suddenly, for • Unstable driving example when entering or exiting a • You are on a roundabout and the vehi- tunnel cle in front is not detected •...
Page 348 Driver assistance system • You are driving by a pedestrian, cyclist, WARNING traffic sign, structure, etc. near the in- tersection • Driving on a curved road • When driving in the following places - Driving through steam, smoke or shadow - Driving through a tunnel or iron bridge - Driving in vast areas where there are...
Page 349 • Driving on an inclined road OADAS006SD OADAS006SD OADAS063SD OADAS063SD OADAS005SD OADAS005SD OCN7073245L OCN7073245L Forward Collision-Avoidance Assist OADAS007SD OADAS007SD OCN7073246L OCN7073246L may detect a vehicle, a pedestrian or Forward Collision-Avoidance Assist a cyclist in the next lane or outside the may not detect other vehicle, a pedes- lane when driving on a curved road.
Page 350 Driver assistance system • Changing lanes OADAS033SD OADAS033SD [A] : Your vehicle, OADAS032SD OADAS032SD [B] : Lane changing vehicle, [A] : Your vehicle, [C] : Same lane vehicle [B] : Lane changing vehicle When a vehicle in front of you merges When a vehicle moves into your lane out of the lane, Forward Collision- from an adjacent lane, it cannot be...
Page 351 • Detecting vehicle WARNING • When you are towing a trailer or another vehicle, turn off Forward Col- lision-Avoidance Assist for safety rea- sons. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicle, a pedestrian or a cyclist are detected.
Page 352 Driver assistance system Basic function Junction Turning function OCN7060112L OCN7060112L OCN7060111 OCN7060111 Forward Collision-Avoidance Assist Junction Turning function can help avoid detects a vehicle, a powered two-wheel- a collision with an oncoming vehicle in er, a pedestrian, or a cyclist ahead on an adjacent lane when turning left at the road and may warn you of a possible a crossroad with the turn signal on by...
Page 353 Forward Collision-Avoidance Assist may not properly operate even though a warning message does not appear on the instrument cluster. We recommend that the vehicle be inspected by an authorized HYUNDAI dealer. OBC3073001L OBC3073001L • Never install any accessories or stick- ers on the front windshield, or tint the front windshield.
Page 354 Driver assistance system Forward Collision-Avoidance WARNING Assist settings When the engine is restarted, Forward Forward Safety Collision-Avoidance Assist maintains its last setting. If Forward safety is dese- lected, the driver should always be aware of the surroundings and drive safely. CAUTION •...
Page 355 Forward Safety Warning Timing Warning Methods OBC3073206L OBC3073206L OBC3073205L OBC3073205L With the engine on, select The Warning Methods can be set with the engine on. Select ward Safety Warning Timing from the s from the settings menu in the instrument cluster settings menu in the instrument clus- from the set- ing Timing from the settings menu in the...
Page 356 Driver assistance system Forward Collision-Avoidance Emergency Braking Assist operation Basic function The basic function for Forward Collision- Avoidance Assist is to warn and help control the vehicle depending on the col- lision risk level: • Collision Warning • Emergency Braking •...
Page 357 Stopping vehicle and ending brake Junction Turning function control Junction Turning function will warn and help control the vehicle depending on the collision risk level: • Collision Warning • Emergency Braking • Stopping vehicle and ending brake control Collision Warning Left-hand drive Left-hand drive Right-hand drive...
Page 358 Driver assistance system Emergency Braking Stopping vehicle and ending brake control Left-hand drive Left-hand drive Right-hand drive Right-hand drive OBC3073010L OBC3073010L OBC3073009L OBC3073009L To warn the driver that emergency brak- OBC3073004L OBC3073004L ing will be assisted, Forward Safety war- • When the vehicle is stopped due to ing light blinking, the 'Emergency emergency braking, the ‘Drive care-...
Page 359 Direct Oncoming function Emergency Braking Direct Oncoming function will warn and control the vehicle depending on the col- lision risk level: • Collision Warning • Emergency Braking • Stopping vehicle and ending brake control Collision Warning OBC3073003L OBC3073003L To warn the driver that emergency brak- ing will be assisted, Forward Safety war- ing light blinking, the 'Emergency...
Page 360 Driver assistance system Stopping vehicle and ending brake con- WARNING trol Take the following precautions when using Forward Collision-Avoidance Assist: • For your safety, change the Settings after parking the vehicle at a safe location. • The driver should hold the responsi- bility to control the vehicle.
Page 361 Avoidance Assist may only warn the lights will illuminate on the instrument driver, or it may not operate. cluster. We recommend that the vehicle be inspected by an authorized HYUNDAI • Forward Collision-Avoidance Assist dealer. will operate under certain conditions...
Page 362 Forward Collision-Avoidance Assist will operate properly when snow, rain or for- eign matter is removed. If the function does not operate properly after it is removed, we recommend that the vehicle be inspected by an authorized HYUNDAI dealer. 7-24...
Page 363 • The brightness changes suddenly, for Limitations of Forward Collision example when entering or exiting a Avoidance Assist tunnel Forward Collision-Avoidance Assist may • The brightness outside is low, and the not operate properly, or it may operate headlights are not on or are not bright unexpectedly under the following cir- cumstances: •...
Page 364 Driver assistance system • Driving in vast areas where there are • The pedestrian or cyclist in front is few vehicles or structures (for example, not fully detected, for example, if the desert, meadow, suburb, etc.) pedestrian is leaning over or is not fully walking upright •...
Page 365 • You are driving by a pedestrian, cyclist, WARNING traffic sign, structure, etc., near the intersection • Driving on a curved road • When driving in the following places - Driving through steam, smoke or shadow - Driving through a tunnel or iron bridge - Driving in vast areas where there are few vehicles or structures (for exam-...
Page 366 Driver assistance system • Driving on an inclined road OADAS015SD OADAS015SD OCN7073203 OCN7073203 OADAS012SD OADAS012SD OCN7073204 OCN7073204 OADAS017SD OADAS017SD OADAS019SD OADAS019SD Forward Collision-Avoidance Assist OADAS010SD OADAS010SD OADAS011SD OADAS011SD may detect a vehicle, powered two- Forward Collision-Avoidance Assist wheeler, pedestrian or cyclist in the may not detect other vehicles, pow- next lane or outside the lane when driv- ered two-wheelers, pedestrians or...
Page 367 • Changing lanes OADAS031SD OADAS031SD [A] : Your vehicle, [B] : Lane changing vehicle, OADAS030SD OADAS030SD [C] : Same lane vehicle [A] : Your vehicle, [B] : Lane changing vehicle When a vehicle in front of you merges When a vehicle moves into your lane out of the lane, Forward Collision- from an adjacent lane, it cannot be Avoidance Assist may not immedi-...
Page 368 Driver assistance system • Detecting vehicle WARNING • When you are towing a trailer or another vehicle, we recommend that Forward Collision-Avoidance Assist is turned off due to safety reasons. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles, powered two-wheelers, pedestrians and cyclists are detected.
Page 369 While driving over a certain speed, Lane Lane Keeping Assist settings Keeping Assist detects lane markings (or Lane Safety road edges) and may warn you if your vehicle leaves the lane without using the turn signal and may assist with steering to prevent your vehicle departing from its travel lane.
Page 370 Driver assistance system Warning Methods Lane Keeping Assist Operation Turning Lane Keeping Assist ON/ OBC3073205L OBC3073205L The Warning Methods can be set with the engine on. Select OBC3073012L OBC3073012L Whenever the vehicle is turned on, Lane from the settings menu in the instrument Keeping Assist will always turn on.
Page 371: Lane Keeping Assist (Lka)
Warning and control WARNING Lane Keeping Assist will warn and help • The steering wheel may not be assist- control the vehicle with Lane Keeping ed if the steering wheel is held very Assist. tight or the steering wheel is steered over a certain degree.
Page 372 If this occurs, we recommend that the vehicle be inspect- OBC3073017L OBC3073017L ed by an authorized HYUNDAI dealer. Lane detected Lane detected OBC3073016L OBC3073016L • The images and colors in the instrument...
Page 373 HYUNDAI dealer. • There are road markings, such as zig- zag lanes, crosswalk markings and road WARNING signs •...
Page 374 Driver assistance system • You may not hear the warning sound Information of Lane Keeping Assist if the sur- rounding is noisy. For more information on the limitations of the front view camera, refer to “Forward • If you attach objects to the steering Collision-Avoidance Assist (FCA)”...
Page 375 Blind-Spot Collision Warning detects approaching vehicles in the driver’s blind spot areas and warn you of a possible collision with a warning light and a warn- ing sound. OJX1079026 OJX1079026 Blind-Spot Collision Warning helps detect and informs the driver that a vehicle is approaching at high speed from the blind spot area.
Page 376 Blind-Spot Collision Warning may not operate properly. We recom- mend that vehicle be inspected by an authorized HYUNDAI dealer. • If the rear corner radars have been replaced or repaired, we recommend that the vehicle be inspected by an authorized HYUNDAI dealer.
Page 377: Blind-Spot Collision Warning (Bcw)
Blind-Spot Collision Warning settings Blind-spot safety OTM070097L OTM070097L When the engine is restarted with Blind- Spot Collision Warning off, the ‘Blind- Spot Safety System is Off’ message will appear on the instrument cluster. OBC3073211L OBC3073211L If you select Blind-spot safety, warning With the engine on, select User settings light on the outside rearview mirror will blink for three seconds.
Page 378 Driver assistance system Warning Methods Blind-Spot Collision Warning operation Blind-Spot Collision Warning warns you by the following actions: • Blind-Spot vehicle warning • Collision warning Blind-Spot vehicle warning OBC3073205L OBC3073205L The Warning Methods can be set with the engine on. Select from the settings menu in the instrument cluster or from the...
Page 379 Collision Warning Information Collision warning will operate when the • If the driver's seat is on the left side, the turn signal is turned on in the direction of collision warning may occur when you the detected vehicle in blind spot area. turn left.
Page 380 If this tems disabled. Radar blocked’ warning occurs, we recommend that the vehicle message will appear on the cluster. be inspected by an authorized HYUNDAI Blind-Spot Collision Warning will oper- dealer. ate properly when such foreign material or trailer, etc., is removed, and then the...
Page 381 Limitations of Blind-Spot Collision WARNING Warning • Even though the warning message Blind-Spot Collision Warning may not does not appear on the cluster, Blind- operate properly, or it may operate unex- Spot Collision Warning may not prop- pectedly under the following circum- erly operate.
Page 382 Driver assistance system • Your vehicle changes lane WARNING • Your vehicle has started at the same • Driving on a curved road time as the vehicle next to you and has accelerated • The vehicle in the next lane moves two lanes away from you, or when the vehicle two lanes away moves to the next lane from you...
Page 383 • • Driving where the heights of the lanes dividing are different OJX1079059 OJX1079059 OBC3073020L OBC3073020L Blind-Spot Collision Warning may not Blind-Spot Collision Warning may not operate properly when driving where operate properly when driving where the road merges or divides. The func- the heights of the lanes are differ- tion may not detect the vehicle in the ent.
Page 384: Blind-Spot Collision-Avoidance Assist (Bca)
Driver assistance system Blind-Spot Collision-Avoidance Assist detects approaching vehicles in the driv- er’s blind spot areas and warn you of a possible collision with a warning light and a warning sound. If there is a collision risk when exiting a parallel space, Blind-Spot Collision- Avoidance Assist may assist with braking your vehicle to help avoid a collision.
Page 385 Blind-Spot Colli- sion-Avoidance Assist may not oper- ate properly. We recommend that the vehicle be inspected by an authorized HYUNDAI dealer. 7-47...
Page 386 Assist settings that the vehicle be inspected by an Blind-Spot Safety authorized HYUNDAI dealer. • Blind-Spot Collision-Avoidance Assist may not work properly if the bum- per has been replaced, or the sur- roundings of the rear corner radar have been damaged or paint has been applied.
Page 387 Warning Methods OTM070097L OTM070097L When the engine is restarted with Blind- OBC3073205L OBC3073205L Spot Collision-Avoidance Assist off, the The Warning Methods can be set with ‘Blind spot safety system is Off’ message the engine on. Select will appear on the instrument cluster. If you select Blind-spot safety, warning from the settings menu in the instrument light on the outside rearview mirror will...
Page 388 Driver assistance system Collision warning may warn you under the Blind-Spot Collision-Avoidance following conditions: Assist operation • Your vehicle speed is above 40 km/h Blind-Spot Collision-Avoidance Assist (25 mph). warns and control you by the following • The speed of the vehicle in your blind actions: spot area is above 10 km/h (7 mph).
Page 389 Collision-avoidance assist (while departing) OBC3073004L OBC3073004L • When the vehicle is stopped due to emergency braking, the ‘Drive care- OBC3073297L OBC3073297L fully’ warning message will appear on • To warn the driver of a collision, the the instrument cluster. warning light on the outside rearview For your safety, the driver should mirror will blink and a warning mes- depress the brake pedal immediately...
Page 390 Driver assistance system • Blind-Spot Collision-Avoidance Assist WARNING does not operate in all situations or cannot avoid all collisions. Take the following precautions when using Blind-Spot Collision-Avoidance • Blind-Spot Collision-Avoidance Assist Assist: may warn the driver late or may not warn the driver depending on the •...
Page 391 If this When Blind-Spot Collision-Avoidance occurs, we recommend that the vehicle Assist is not working properly, the ‘Check be inspected by an authorized HYUNDAI blind-spot safety systems’ warning mes- dealer. sage will appear on the instrument clus-...
Page 392 Driver assistance system Blind-Spot Collision-Avoidance WARNING Assist disabled • Even though the warning message does not appear on the instrument cluster, Blind-Spot Collision-Avoid- ance Assist may not properly operate. • Blind-Spot Collision-Avoidance Assist may not properly operate in an area (for example, open terrain) where any objects are not detected right after the engine is turned on, or when the...
Page 393 • The speed of the other vehicle is very Limitations of the Blind-Spot fast that it passes by your vehicle in a Collision-Avoidance Assist short time Blind-Spot Collision-Avoidance Assist • Your vehicle passes by the other vehi- may not operate properly, or it may oper- ate unexpectedly under the following circumstances: •...
Page 394 Driver assistance system Braking control may not work, driver’s WARNING attention is required in the following cir- cumstances: • Driving on a curved road • The vehicle severely vibrates while driving over a bumpy road, uneven road or concrete patch •...
Page 395 • Driving on an inclined road • Driving where the heights of the lanes are different OBC3073019L OBC3073019L Blind-Spot Collision-Avoidance Assist OBC3073020L OBC3073020L may not operate properly when driv- Blind-Spot Collision-Avoidance Assist ing on a slope. The function may not may not operate properly when driv- detect the vehicle in the next lane or ing where the heights of the lanes are...
Page 396 Driver assistance system Settings Warning Methods OBC3073217L OBC3073217L (1) Manual Speed Limit Assist enabled indicator (2) Set speed OBC3073205L OBC3073205L You can set the speed limit when you do The Warning Methods can be set with not want to drive over a specific speed. the engine on.
Page 397 The speed will increase or decrease to the nearest multiple of 10 in km/h operation (multiple of 5 in mph) at first, and then Setting speed limit increase or decrease by 10 km/h (5 mph). OBC3073022L OBC3073022L 1. Press and hold Driving Assist ( ) but- OBC3073220L OBC3073220L...
Page 398 Driver assistance system Temporarily pausing Manual Speed Turning off Manual Speed Limit Limit Assist Assist OBC3073021L OBC3073021L OBC3073022L OBC3073022L Press the switch to temporarily pause Press the Driving Assist ( ) button to the set speed limit. The set speed limit turn Manual Speed Limit Assist off.
Page 399 Intelligent Speed Limit Assist uses infor- Detecting sensor mation from the detected road signs and uses the navigation system data to inform you of the speed limit and to help maintain within the speed limit on the road. CAUTION • Intelligent Speed Limit Assist may not operate properly if the function is used in other countries.
Page 400 Driver assistance system • If Speed limit warning is selected, Intelligent Speed Limit Assist Intelligent Speed Limit Assist will settings inform the driver of speed limit. In Speed Limit addition, Intelligent Speed Limit Assist will warn the driver when the vehicle is driven faster than the speed limit.
Page 401 Warning methods Intelligent Speed Limit Assist operation Warning and control Intelligent Speed Limit Assist will warn and control the vehicle by 'Displaying speed limit', 'Warning overspeed' and 'Changing set speed'. OBC3073205L OBC3073205L The Warning Methods can be set with the engine on. Select from the settings menu in the instrument cluster or from the...
Page 402 Driver assistance system Information • If speed limit information of the road cannot be recognized, ‘---’ sign will be displayed. Please refer to “Limitations of Intelligent Speed Limit Assist” if the road signs are difficult to recognize. • Intelligent Speed Limit Assist provides additional road sign information in ad- dition to speed limit.
Page 403: Manual Speed Limit Assist (Msla)
WARNING • Even after changing the set speed according to the speed limit of the road, the vehicle can still be driven over the speed limit. If necessary, depress the brake pedal to reduce your driving speed. • If the speed limit of the road is under speed function will not work.
Page 404: Intelligent Speed Limit Assist (Isla)
If this occurs, we Intelligent Speed Limit Assist will oper- recommend that you have the vehicle ate properly when snow, rain or foreign inspected by an authorized HYUNDAI material is removed. dealer. If Intelligent Speed Limit Assist does not...
Page 405 • A road sign near the road you are driv- Limitations of Intelligent Speed ing is detected Limit Assist • The other traffic sign or signboards are Intelligent Speed Limit Assist may not alongside the road sign operate properly, or it may operate unex- pectedly under the following circum- •...
Page 406 Driver assistance system WARNING • Intelligent Speed Limit Assist is a supplemental function that helps the driver to comply with the speed limit on the road, and may not display the correct speed limit or control the driv- ing speed properly. •...
Page 407: Driver Attention Warning (Daw)
Basic function Driver Attention Warning settings Driver Attention Warning monitors your driving pattern while driving. When the Leading Vehicle Departure Alert driver's attention level is below a certain level, Driver Attention Warning recom- mends a break to help with safe driving. Leading vehicle departure alert function Leading Vehicle Departure Alert function will inform the driver when a detected...
Page 408 Driver assistance system Driver Attention Warning WARNING operation For your safety, change the Settings Basic function after parking the vehicle at a safe loca- tion. The basic function of Driver Attention Warning is to warn the driver ‘Consider taking a break’. CAUTION Taking a break •...
Page 409 • If any other system’s warning mes- instrument cluster. If this occurs, we rec- sage is displayed or audible warning is ommend that the vehicle be inspected by an authorized HYUNDAI dealer. Alert's warning message may not be displayed and audible warning may not be generated.
Page 410 Driver Atten- tion Warning will operate properly when snow, rain or foreign material is removed. If Driver Attention Warning does not operate properly after it is removed, we recommend to have the vehicle inspect- ed by an authorized HYUNDAI dealer. 7-72...
Page 411 • When the vehicle ahead sharply steers Leading Vehicle Departure Alert function • When the vehicle cuts in OADAS034SD OADAS034SD [A] : Your vehicle, [B] : Front vehicle If the vehicle in front makes a sharp OADAS021SD OADAS021SD turn, such as to turn left or right or make a Uturn, etc., Leading Vehicle Departure Alert may not operate prop- erly.
Page 412 Driver assistance system • When a pedestrian or bicycle is • When driving at a tollgate or intersec- between you and the vehicle ahead tion, etc. OADAS025SD OADAS025SD OADAS026SD OADAS026SD If there is a pedestrian(s) or bicycle(s) If you pass a tollgate or intersection in between you and the vehicle in front, with lots of vehicles or you drive where Leading Vehicle Departure Alert may...
Page 413 Cruise Control operation Setting set speed 1. Accelerate to the desired speed, which must be more than 30 km/h (20 mph). OBC3073226L OBC3073226L (1) Cruise indicator (2) Set speed Cruise Control allows you to drive at speeds above 30 km/h (20 mph) without OBC3073022L OBC3073022L depressing the accelerator pedal.
Page 414 Driver assistance system Increasing set speed Decreasing set speed OBC3073241L OBC3073241L OBC3073242L OBC3073242L • Push the + switch up and release it • Push the - switch down and release immediately. The set speed will it immediately. The set speed will increase by 1 km/h (1 mph) each time decrease by 1 km/h (1 mph) each time the switch is operated in this manner.
Page 415: Cruise Control (Cc)
Driving speed may sharply increase or decrease when NOTICE you press the button. If Cruise Control pauses during a situa- tion that is not mentioned, we recom- mend that the vehicle be inspected by an authorized HYUNDAI dealer. 7-77...
Page 416 Driver assistance system Turning off Cruise Control WARNING Take the following precautions when using Cruise Control: • Always set the vehicle speed under the speed limit in your country. • Keep Cruise Control off when the function is not in use, to avoid inad- vertently setting a speed.
Page 417 Basic function Detecting senor Smart Cruise Control detects a vehicle ahead and helps maintain the distance from the vehicle ahead and the set speed. Overtaking Acceleration Assist When Smart Cruise Control judges you are attempting to overtake a vehicle in front, Smart Cruise Control help with accelerating.
Page 418: Smart Cruise Control (Scc)
Driver assistance system Warning Methods CAUTION • Always keep the front view camera and front radar in good condition to maintain optimal performance of Smart Cruise Control. • For more information on the precau- tions of the front view camera and front radar, refer to “Forward Colli- sion-Avoidance Assist (FCA)”...
Page 419 Smart Cruise Control operation Operating conditions for Acceleration Assist Operating conditions Overtaking Acceleration Assist operates Basic function when the turn signal indicator is turned on to the right while Smart Cruise Control Smart Cruise Control operates when the is operating, and the following conditions following conditions are satisfied.
Page 420 Driver assistance system Turning on Smart Cruise Control Setting Vehicle Distance OBC3073022L OBC3073022L OBC3073031L OBC3073031L • Press the Driving Assist ( ) button Each time the Vehicle Distance button to turn on Smart Cruise Control. The is pressed, the headway changes as fol- speed will be set to the current speed lows: on the instrument cluster.
Page 421 Increasing set speed Decreasing set speed OBC3073218L OBC3073218L OBC3073219L OBC3073219L • Push the + switch up and release it • Push the - switch down and release immediately. The set speed will it immediately. The set speed will increase by 1 km/h (1 mph) each time decrease by 1 km/h (1 mph) each time the switch is operated in this manner.
Page 422 Driver assistance system Temporarily cancelling Smart Cruise Turning off the Smart Cruise Control Control OBC3073022L OBC3073022L Press the Driving Assist ( ) button to OBC3073029L OBC3073029L turn Smart Cruise Control off. Press the switch or depress the brake pedal to temporarily cancel Smart Cruise Control.
Page 423 • When operating Display and Control (1) Whether there is a vehicle ahead and You can see the status of the Smart the selected distance level. Cruise Control operation in the Driving Assist view on the instrument cluster. (2) Set speed. Refer to “Cluster display modes”...
Page 424 Driver assistance system Accelerating temporarily Temporarily cancelling Smart Cruise Control OBC3073033L OBC3073033L If you want to speed up temporarily when OBC3073228L OBC3073228L Smart Cruise Control is on, depress the Smart Cruise Control will be temporarily accelerator pedal. While the speed is cancelled automatically when: increasing, the set speed, distance lev- •...
Page 425 Smart Cruise Control conditions not In traffic situation satisfied OBC3073269L OBC3073269L In traffic, your vehicle will stop if the vehi- OBC3073229L OBC3073229L cle ahead of you stops. Also, if the vehicle If the Driving Assist ( ) button, + switch, ahead of you starts moving, your vehicle - switch or switch is pushed when...
Page 426 Driver assistance system Warning road conditions ahead Collision Warning OBC3073036L OBC3073036L OBC3073002L OBC3073002L In the following situation, the ‘Watch for While Smart Cruise Control is operating, surrounding vehicles’ warning message when the collision risk with the vehicle will appear on the instrument cluster, and ahead is high, the ‘Collision warning!’...
Page 427 • When you are towing a trailer or WARNING another vehicle, we recommend that Smart Cruise Control is turned off due Take the following precautions when to safety reasons. using Smart Cruise Control: • Turn off Smart Cruise Control when •...
Page 428 We rec- dar is initialized. ommend that the vehicle be inspected by • You may hear a sound when the brake is an authorized HYUNDAI dealer. controlled by Smart Cruise Control. 7-90...
Page 429 Smart Cruise Control disabled Limitations of the Smart Cruise Control Smart Cruise Control may not operate properly, or it may operate unexpectedly under the following circumstances: • The detecting sensor or the surround- ings are contaminated or damaged • Washer fluid is continuously sprayed, or the wiper is on •...
Page 430 Driver assistance system • Only part of the vehicle is detected • The vehicle in front is covered with snow • The vehicle in front has no tail lights, tail lights are located unusually, etc. • Unstable driving • The brightness outside is low, and the •...
Page 431 • Driving on a curved road • Driving on an inclined road OADAS014SD OADAS014SD OADAS012SD OADAS012SD On curves, Smart Cruise Control During uphill or downhill driving, the may not detect a vehicle in the same Smart Cruise Control may not detect a lane, and may accelerate to the set moving vehicle in your lane, and cause speed.
Page 432 Driver assistance system • Changing lanes • Situations when detecting are limited OCN7071130L OCN7071130L OADAS030SD OADAS030SD OBC3073011L OBC3073011L [A] : Your vehicle, [B] : Lane changing vehicle In the following cases, some vehicles, pedestrians or animals in your lane When a vehicle moves into your lane cannot be detected by the sensor: from an adjacent lane, it cannot be - Vehicles offset to one side...
Page 433 - Narrow vehicles, such as motorcy- cles or bicycles - Special vehicles - Animals and pedestrians Adjust your vehicle speed by depress- ing the brake pedal according to the road and driving conditions ahead. In the following cases, the vehicle in front cannot be detected by the sensor: - You are steering your vehicle OBC3073250L...
Page 434 Driver assistance system OHI058308L OHI058308L OHI058323L OHI058323L • When a vehicle in front of you merges • Always look out for pedestrians when out of the lane, Smart Cruise Control your vehicle is maintaining a distance may not immediately detect the new with the vehicle ahead.
Page 435: Navigation-Based Smart Cruise Control (Nscc)
Navigation-based Smart Cruise Control Navigation-based Smart Cruise helps maintain safe speed depending on Control settings the road conditions by using information Motorway way Auto Speed Change from the navigation system when driving on highways while Smart Cruise Control is operating. Information •...
Page 436 Driver assistance system Navigation-based Smart Cruise Navigation-based Smart Cruise Control display and control Control operation When Navigation-based Smart Cruise Operating conditions Control operates, it will be displayed on Navigation-based Smart Cruise Control the cluster as follows: is ready to operate if all of the following conditions are satisfied: •...
Page 437 Information The images and colors in the instrument cluster may differ depending on the cluster type or theme selected from the settings menu. Information Highway Curve Zone Auto Slowdown and Highway Set Speed Auto Change function uses the same symbol. OBC3073039L OBC3073039L Navigation-based Smart Cruise...
Page 438 Driver assistance system Limitations of Navigation-based Smart Cruise Control Navigation-based Smart Cruise Control may not operate properly under the fol- lowing circumstances: • The navigation is not working properly • Map information is not transmitted due to infotainment system’s abnormal operation •...
Page 439 OJX1070281L OJX1070281L OJX1070282L OJX1070282L [1] : Set route, [2] : Branch line, [3] : Driving route, [1] : Driving route, [2] : Branch line, [4] : Main road, [5] : Curved road section [3] : Curved road section, [4] : Main road •...
Page 440 Driver assistance system • The vehicle will accelerate if the driv- WARNING er depresses the accelerator pedal while Navigation-based Smart Cruise • Navigation-based Smart Cruise Con- Control is operating, and the func- trol is not a substitute for safe driving tion will not decelerate the vehicle.
Page 441 Lane Following Assist detects lane mark- Lane Following Assist settings ings and/or a vehicle ahead on the road, Warning Methods and center your vehicle in the lane. Detecting sensor OBC3073205L OBC3073205L The Warning Methods can be set with the engine on. Select OBC3073001L OBC3073001L [1]: Front view camera...
Page 442: Lane Following Assist (Lfa)
Driver assistance system Lane Following Assist Operation Lane Following Assist Turning Lane Following Assist On/ OBC3073041L OBC3073041L If the vehicle ahead and/or both lane markings are detected and your vehicle OBC3073012L OBC3073012L speed is below180 km/h (110 mph), the With the engine on, shortly press the green indicator light will illuminate Lane Driving Assist button located on the...
Page 443 Hands-off warning WARNING • The steering wheel may not be assist- ed if the steering wheel is held very tight or the steering wheel is steered over a certain degree. • Lane Following Assist does not oper- ate at all times. It is the responsibility of the driver to safely steer the vehicle and to maintain the vehicle in its lane.
Page 444 If this occurs, we recommend that the vehicle be inspected by an authorized OBC3073041L OBC3073041L HYUNDAI dealer. • The images and colors in the instru- ment cluster may differ depending on the instrument cluster type or theme Limitations of Lane Following Assist selected from the settings menu.
Page 445 Rear View Monitor displays the area behind your vehicle to help with safe Warning Methods parking or driving. Detecting sensor OBC3073276L OBC3073276L The Warning Methods can be set with the engine on. Select OBC3073043L OBC3073043L [1] : Wide-rear view camera from the settings menu in the infotain- Refer to the illustration above for the ment system to change the following...
Page 446: Parking Safety
Driver assistance system Camera settings (if equipped) Information • The horizontal guideline of the Rear View Parking Guidance shows the dis- tance of 0.5 m (1.6 ft.), 1 m (3.3 ft.) and 2.3 m (7.6 ft.) from the vehicle. • The horizontal guideline of the Rear Top View Parking Guidance shows the dis- tance 0.5 m (1.6 ft.) and 1.5 m (4.9 ft.) from the vehicle.
Page 447: Rear View Monitor (Rvm)
Rear View Rear top view (if equipped) OBC3073246L OBC3073246L OBC3073245L OBC3073245L When you touch the icon, the top view Operating conditions is displayed on the screen and shows the • Shift the gear to R (Reverse), the rear distance from the vehicle in the back of view will appear on the screen.
Page 448 When Rear View Monitor is not working properly, or the screen flickers, or the camera image does not display prop- erly, we recommend that the vehicle be inspected by an authorized HYUNDAI dealer. Limitations of Rear View Monitor When the vehicle is stopped for a long...
Page 449: Rear Cross-Traffic Collision Warning (Rccw)
Rear Cross-Traffic Collision Warning Detecting sensor Assist is designed to help detect vehicles approaching from the rear left and right side while your vehicle is reversing, and warn the driver that a collision is immi- nent with a warning message and an audible warning.
Page 450 Driver assistance system Rear Cross-Traffic Collision Warning Methods Warning Rear Cross-Traffic Safety OBC3073205L OBC3073205L The Warning Methods can be set with the engine on. Select OBC3073235L OBC3073235L With the engine on, select User settings from the settings menu in the instrument cluster or Rear Cross-Traffic Safety from the set- from the...
Page 451 • Rear Cross-Traffic Collision Warning Rear Cross-Traffic Collision will operate when all the following con- Warning operation ditions are satisfied: Rear Cross-Traffic Collision Warning will - The gear is shifted to R (Reverse) warn the driver when a collision is immi- - The vehicle speed is below 8 km/h nent.
Page 452 ( ) warning light will illuminate on the cluster. If this occurs, we recom- mend that the vehicle be inspected by an authorized HYUNDAI dealer. 7-114...
Page 453 • Speed of the approaching vehicle is it is removed, we recommend that the fast or slow vehicle be inspected by an authorized HYUNDAI dealer. Information For more details on the limitations of the rear corner radar, refer to “Blind-Spot Collision-Avoidance Assist (BCA)”...
Page 454 Driver assistance system • When the vehicle is in a complex park- WARNING ing environment • Driving near a vehicle or structure OJX1079112 OJX1079112 Rear Cross-Traffic Collision Warning OJX1079111 OJX1079111 may detect vehicles which are park- [A] : Structure ing or pulling out near your vehicle Rear Cross-Traffic Collision Warning (for example, a vehicle leaving beside may be limited when driving near...
Page 455 • When the vehicle is parked diagonally • Pulling into the parking space where there is a structure OJX1079113 OJX1079113 OJX1079115 OJX1079115 [A] : Vehicle [A] : Structure, [B] : Wall Rear Cross-Traffic Collision Warn- ing may be limited when backing up Rear Cross-Traffic Collision Warning diagonally, and may not detect the may detect vehicles passing by in...
Page 456 Driver assistance system • When the vehicle is parked rearward OJX1079116 OJX1079116 Rear Cross-Traffic Collision Warn- ing may detect vehicles passing by behind you when parking in reverse into a parking space. If this occurs, the function may unnecessarily warn the driver.
Page 457 Rear Cross-Traffic Collision-Avoidance Detecting sensor Assist detects vehicles approaching from the rear left or right while your vehicle is reversing and warns you of a possible collision with a warning message and a warning sound. Also, Rear Cross-Traffic Collision-Avoidance Assist may assist with braking your vehicle to help avoid a collision.
Page 458 Driver assistance system Rear Cross-Traffic Collision- Warning Methods Avoidance Assist settings Rear Cross-Traffic Safety OBC3073205L OBC3073205L The Warning Methods can be set with the engine on. Select OBC3073235L OBC3073235L With the engine on, select User settings from the settings menu in the instrument cluster or Rear Cross-Traffic Safety from the set- from the...
Page 459 Rear Cross-Traffic Collision-Avoidance Rear Cross-Traffic Collision- Assist will operate when all the following Avoidance Assist operation conditions are satisfied: Rear Cross-Traffic Collision-Avoidance • The gear is shifted to R (Reverse) and Assist will warn and control the vehicle your vehicle speed is below 8 km/h (5 depending on collision level: ‘Collision mph).
Page 460 Driver assistance system Emergency braking will be assisted to Emergency Braking help prevent collision with approaching vehicles from the left and right. Rear Cross-Traffic Collision-Avoidance Assist will operate when all the following conditions are satisfied: • The gear is shifted to R (Reverse) and your vehicle speed is below 8 km/h (5 mph).
Page 461 Stopping vehicle and ending brake WARNING control Take the following precautions when using Rear Cross-Traffic Collision- Avoidance Assist: • For your safety, only change the Set- tings after parking the vehicle at a safe location. • If any other function’s warning mes- sage is displayed or audible warn- ing is generated, Rear Cross-Traffic Collision-Avoidance Assist warning...
Page 462 - ESC (Electronic Stability Control) is minate on the instrument cluster. If this engaged in a different function occurs, we recommend that the vehicle be inspected by an authorized HYUNDAI Information dealer. • If braking is assisted by Rear Cross-Traf-...
Page 463 • Departing from where roads are wet vehicle be inspected by an authorized • Speed of the approaching vehicle is HYUNDAI dealer. fast or slow Braking control may not work, driver’s attention is required in the following cir- cumstances: •...
Page 464 Driver assistance system • When the vehicle is in a complex park- Information ing environment For more information on the limitations of the rear corner radar, refer to the “Blind- Spot Collision-Avoidance Assist (BCA)” section in this chapter. WARNING • Driving near a vehicle or structure OHY059018 OHY059018 Rear Cross-Traffic Collision-Avoid-...
Page 465 • When the vehicle is parked • When the vehicle is on or near a diagonally slope OHY059019 OHY059019 OBC3073047L OBC3073047L Rear Cross-Traffic Collision-Avoid- [A] : Vehicle ance Assist may be limited when the Rear Cross-Traffic Collision-Avoid- vehicle is on a uphill or downhill slope, ance Assist may be limited when or near it, and may not detect the backing up diagonally, and may not...
Page 466 Driver assistance system • Pulling into the parking space where • When the vehicle is parked rearward there is a structure OHY059020 OHY059020 Rear Cross-Traffic Collision-Avoid- OHY059022 OHY059022 ance Assist may detect vehicles pass- [A] : Structure, [B] : Wall ing by behind you when parking in Rear Cross-Traffic Collision-Avoid- reverse into a parking space.
Page 467 Reverse Parking Distance Warning uses Reverse Parking Distance the rear ultrasonic sensors to detect and Warning settings warns you if a person, animal, or object is Warning Methods within a certain distance when your vehi- cle is stopped or driving at low speed. Detecting sensor OBC3073205L OBC3073205L...
Page 468: Reverse Parking Distance Warning (Pdw)
10 km/h (6 mph). foreign material. If it still does not work properly, we recommend that the vehicle Warning be inspected by an authorized HYUNDAI indicator Distance Warning dealer. when driv-...
Page 469 • Reverse Parking Distance Warning may mend that the vehicle be inspected by an authorized HYUNDAI dealer. malfunction when: - Heavy rain or water spray is present - Water flows on the surface of the sensor - Affected by another vehicle’s sensors...
Page 470 HYUNDAI dealer. WARNING • Parking Distance Warning is a sup- plemental function. The operation of Parking Distance Warning can be affected by several factors (including environmental conditions).
Page 471 Forward/Reverse Parking Distance Warn- ing uses the front and rear ultrasonic Distance Warning settings sensors to detect and warns you if a per- Warning Methods son, animal, or object is within a certain distance when your vehicle is stopped or driving at low speed.
Page 472 Driver assistance system Parking Distance Warning Auto on Distance Warning operation To use Parking Distance Warning Auto On function, select Parking Safety button Distance Warning Auto on from the Set- tings menu in the instrument cluster or on from the Settings menu in the info- tainment system.
Page 473 Forward Parking Distance Warning Warning indica- • Forward Parking Distance Warning will Distance Warning tor when operate when one of the condition is from object sound driving satisfied. forward - The gear is shifted from R (Reverse) to D (Drive) with Reverse Parking Dis- tance Warning on 60~100 cm Buzzer beeps...
Page 474 If it still does not work properly, we recommend that the vehicle ward be inspected by an authorized HYUNDAI 60~120 cm Buzzer beeps dealer. (24~48 in.) intermittently • The audible warning does not sound.
Page 475: Forward/Reverse Parking Distance Warning (Pdw)
• Forward/Reverse Parking Distance authorized HYUNDAI dealer. Warning may malfunction when: - Heavy rain or water spray is present - Water flows on the surface of the sensor - Affected by another vehicle’s sensors...
Page 476 It varies depending on the speed of the vehicle or the shape of a person, animal, or object. • If the Parking Distance Warning does not operate properly, we recommend that the vehicle be inspected by an authorized HYUNDAI dealer. 7-138...
Page 477 Reverse Parking Collision-Avoidance Reverse Parking Collision- Assist detects pedestrians or objects Avoidance Assist settings behind the vehicle and may warn you or Warning Methods assist you with braking to help avoid a collision while your vehicle is reversing. Detecting sensor OBC3073278L OBC3073278L The Warning Methods can be set with...
Page 478 Driver assistance system Parking Safety Reverse Parking Collision- Avoidance Assist operation With the engine on, select Turning Reverse Parking Collision- safety from the settings menu in the Avoidance Assist On/Off infotainment system to set whether to use each function. • If Rear Safety is selected, Reverse Parking Collision-Avoidance Assist will warn the driver and assist with braking when a collision with a pedestrian or an...
Page 479 Operating conditions Off conditions Select from If collision is imminent, Reverse Parking the settings menu in the infotainment Collision-Avoidance Assist will assist you system. Reverse Parking Collision-Avoid- with braking. Braking assist is released ance Assistis enabled when the following after 2 seconds. Immediately depress the conditionsare satisfied: brake pedal and check vehicle surround- ings.
Page 480 Reverse Parking Collision-Avoidance Assist will turn off automatically. We recommend that the vehicle be inspected by an authorized HYUNDAI dealer. OBC3073060L OBC3073060L The rear ultrasonic sensors are located inside the rear bumper to detect objects in the rear area.
Page 481: Reverse Parking Collision-Avoidance Assist (Pca)
Limitations of Reverse Parking Wide-rear view Wide-rear view Rear ultrasonic Rear ultrasonic camera camera sensor sensor Collision-Avoidance Assist Reverse Parking Collision-Avoidance Assist may not assist braking or warn the driver even if there are pedestrians or objects under the following circum- stances: •...
Page 482 Driver assistance system • Problems with pedestrian or object Reverse Parking Collision-Avoidance Assist may unnecessarily warn the driver - The pedestrians are difficult to detect or assist with braking even if there are no - There is ground height difference be- pedestrians or objects under the follow- tween the vehicle and the pedestrian ing circumstances:...
Page 483 • Problems with pedestrian or object CAUTION - Pedestrians or objects are around the • Noise may be heard when sudden path of the vehicle braking occurs to avoid a collision. - The pedestrian or the object is mov- • If any other warning sound such as the seat belt warning chime is already •...
Page 484 Reverse Parking Collision-Avoidance Assist may not operate properly if the wide-rear view camera or the rear ultrasonic sensor(s) is forcibly moved out of proper alignment. We recommend that the vehicle be inspected by an authorized HYUNDAI dealer. 7-146...
Page 485 Parking Assist uses the front, front side, • Parking Assist helps the driver with per- rear side, and rear ultrasonic sensors to pendicular reverse parking and parallel detect parking spaces and control vehicle reverse parking, and when leaving the steering and help enter and exit parking parking space, parallel forward exit is spaces from outside your vehicle.
Page 486 • If the detecting sensor needs to be replaced or repaired, we recommend that you have your vehicle inspected by an authorized HYUNDAI dealer. • Parking Assist may malfunction if the vehicle bumper height or ultrasonic OBC3073278L...
Page 487 Parking Assist operation Parking mode Perpendicular reverse parking Perpendicular reverse parking Parking Assist button • Right side • Right side • • Left side Left side OTM048444L OTM048444L Parallel reverse parking Parallel reverse parking OBC3073044L OBC3073044L • Right side • Right side •...
Page 488 Driver assistance system • If the engine is turned on when the Operating order gear is in N (Neutral), Exit mode will be Parking mode operates in the following selected. Parking mode will be select- order: ed automatically after the vehicle has 1.
Page 489 Perpendicular reverse parking Perpendicular reverse parking Perpendicular reverse parking Perpendicular reverse parking OBC3073095L OBC3073095L OBC3073280L OBC3073280L Parallel reverse parking Parallel reverse parking Parallel reverse parking Parallel reverse parking OBC3073096L OBC3073096L OBC3073279L OBC3073279L (1) Slowly drive forward maintaining the (1) When a parking space is found, a blank distance of approximately 100 cm (40 space will appear on the cluster like in.) from the parked vehicles.
Page 490 Driver assistance system Perpendicular reverse parking Perpendicular reverse parking ORG3070089 ORG3070089 OBC3073097L OBC3073097L Parallel reverse parking Parallel reverse parking • If the distance is below 50 cm (20 in.) or above 150 cm (59 in.), Parking Assist may not be able to search for a parking space.
Page 491 OBC3073099L OBC3073099L 6. Steering wheel control OBC3073100L/OBC3073101L OBC3073100L/OBC3073101L (1) Shift the gear to R (Reverse). (2) Parking Assist will provide instructions on the cluster and the steering wheel will be controlled. - If the steering wheel is held tight, Parking Assist will be cancelled. (3) Take your foot off the brake pedal and drive in reverse.
Page 492 Driver assistance system Parking mode will cancel in the fol- lowing conditions: • When searching for parking space - Shifting the gear to R (Reverse) - The vehicle is above 30 km/h (18 mph) - The parking space is narrow - The steering wheel, gearshift, brak- ing, and drive controls are not work- ing normally...
Page 493: Parking Assist (Pa)
Exit mode Parallel exit Parallel exit • Left side • Left side • Right side • Right side OTM048445L OTM048445L OBC3073104L/OBC3073105L OBC3073104L/OBC3073105L Use Exit mode when the following condi- Additional instructions (messages) tions are satisfied. When Parking Assist is operating, a mes- •...
Page 494 Driver assistance system OBC3073044L OBC3073044L OBC3073281L/OBC3073106L OBC3073281L/OBC3073106L 1. Getting ready for exit 2. Selecting exit mode and type (1) With the engine turned on, depress (1) Select exit mode pressing the brake pedal and shift the gear to P Parking/View button (Park) or N (Neutral).
Page 495 OBC3073118L OBC3073118L OBC3073099L/OBC3073100L OBC3073099L/OBC3073100L (1) When the vehicle is parked parallel, the vehicle sensors will detect the dis- tance from nearby objects and check for space to exit. • If the front or rear vehicle (or object) is too near, the function will not be able to search for space, and will turn off.
Page 496 Driver assistance system How to turn off Exit mode while wheel control operating (1) Depending on the parking environ- Press the Parking/View ( ) button or ments, shift request messages (Shift Parking Safety ( ) button. to 1st gear, Shift to R, Shift to D) will appear on the cluster along with a Exit mode will cancel in the following beep sound.
Page 497 If the message appears, stop using Remote Smart Parking Assist, and we recommend that the vehicle be WARNING inspected by an authorized HYUNDAI dealer. • Always check surroundings for pedes- trians, animals or objects before tak- ing your foot off the brake pedal.
Page 498 Driver assistance system • There is a person, animal or object Parking Assist may not operate normally above or below the ultrasonic sensor under the following circumstances: when Parking Assist is activated • Parking on inclines • The parking space is curved or diagonal •...
Page 499 • Parking on uneven road • Parking near a pillar OBC3073084L OBC3073084L OBC3073086L OBC3073086L Parking Assist may cancel when the Parking Assist performance vehicle slips, or the vehicle cannot reduce when there is a pillar or pillar move due to road conditions such as surrounded by objects such as a fire pebbles or fragmented stones.
Page 500 We recommend that the vehicle be checked by an autho- rized HYUNDAI dealer. • Use Remote Smart Parking Assist only in a parking space that is large enough for the vehicle to move safely.
Page 501 The radio frequency components com- - For Ukraine plies: Front radar - For Europe and CE certified countries - For Europe and CE certified countries OBC3073282L OBC3073282L OBC3073283L OBC3073283L 7-163...
Page 502 Driver assistance system - For Moldavia - For Israel OBC3073284L OBC3073284L - For Morocco OBC3073285L OBC3073285L - For Paraguay OBC3073287L OBC3073287L - For United Kingdom OBC3073286L OBC3073286L OBC3073288L OBC3073288L 7-164...
Page 503 - For Serbia Rear corner radar - For Ukraine OANATEL121 OANATEL121 - For Paraguay OANATEL118 OANATEL118 - For Ghana OANATEL122 OANATEL122 OANATEL119 OANATEL119 - For Republic of South Africa OANATEL120 OANATEL120 7-165...
Page 504 Driver assistance system - For Malaysia - For Europe and CE certified countries OANATEL057 OANATEL057 - For Singapore OANATEL116 OANATEL116 OANATEL058 OANATEL058 7-166...
Page 505 8. Emergency situations Hazard warning flasher .................. 8-3 In case of an emergency while driving ............8-4 If the engine stalls while driving ................8-4 If the engine stalls at a crossroad or crossing ............8-4 If you have a flat tire while driving ................8-4 If the engine will not start ................8-5 If the engine doesn’t turn over or turns over slowly ..........
Page 506 Towing ......................8-31 Towing service ......................8-31 Removable towing hook ..................8-32 Emergency towing ....................8-33 Emergency commodity ................8-35 Fire extinguisher ..................... 8-35 First aid kit ....................... 8-35 Triangle reflector ..................... 8-35 Tire pressure gauge ....................8-35 Pan-european ecall system ................8-36 Information on data processing ................
Page 507: Hazard Warning Flasher
HAZARD WARNING FLASHER OBC3083002L OBC3083002L The hazard warning flasher serves as a warning to other drivers to exercise extreme caution when approaching, overtaking, or passing your vehicle. It should be used whenever emergen- cy repairs are being made or when the vehicle is stopped near the edge of a roadway.
Page 508: In Case Of An Emergency While Driving
HYUNDAI dealer. When the vehicle has slowed to such a speed that it is safe to do so, brake If the engine stalls at a carefully and pull off the road.
Page 509: If The Engine Will Not Start
The engine starts only when the recommend that you call an authorized shift lever is in N (Neutral) or P (Park). HYUNDAI dealer for assistance. • Check the battery connections to be sure they are clean and tight. • Turn on the interior light. If the light dims or goes out when you operate the starter, the battery is drained.
Page 510: Jump Starting
Emergency situations JUMP STARTING Jump starting can be dangerous if done If acid gets into your eyes, flush your incorrectly. Follow the jump starting pro- eyes with clean water for at least 15 cedure in this section to avoid serious minutes and get immediate medical injury or damage to your vehicle.
Page 511 Information An inappropriately disposed battery can be harmful to the environment human health. Dispose of the battery according to your local law(s) or regulations. Jump starting procedure 1. Position the vehicles close enough 1VQA4001 1VQA4001 that the jumper cables will reach, but 4.
Page 512 (4). that you have your vehicle checked by an 2. Disconnect the other end of the jump- authorized HYUNDAI dealer. er cable from the black, negative (-) battery/chassis ground of the assisting vehicle (3).
Page 513: If The Engine Overheats
2. Place the shift lever in P (Park, for HYUNDAI dealer for assistance. automatic transmission/dual clutch transmission vehicle) or neutral (for manual transmission vehicle) and set WARNING the parking brake.
Page 514 7. Proceed with caution, keeping alert for further signs of overheating. If overheating happens again, we rec- ommend that you call an authorized HYUNDAI dealer for assistance. NOTICE • Serious loss of coolant indicates a leak in the cooling system and we recom- mend the system be checked by an authorized HYUNDAI dealer.
Page 515: Resetting Tpms
Resetting TPMS To reset TPMS: 1. Adjust all tire pressure to the recom- mended tire inflation pressures. OBC3083003L OBC3083003L OBC3083033L OBC3083033L 2. Press the TPMS Reset button on the driver’s side center pillar outer panel for 3 seconds with the vehicle parked and engine running.
Page 516 Emergency situations Information CAUTION • Be sure to reset after the inflation • If the “Tire pressures stored” mes- pressure of all four tires are set to the sage on the instrument cluster does not recommended inflation pressure. If appear or the warning light does not you reset without adjusting the infla- blink, try again from Step 2.
Page 517: Low Tire Pressure Light
When an authorized HYUNDAI dealer is Check the tire inflation pressure and not nearby, stop at a safe place and adjust the tires to the recommended tire check the condition and inflation pres- inflation pressure.
Page 518: Tpms Malfunction Indicator
HYUNDAI dealer as soon as braking distance, and other tire fail- possible. ures that result in loss of vehicle con- If there is a malfunction with the TPMS, trol.
Page 519: Jack And Tools
WARNING Changing a tire can be dangerous. Follow the instructions in this section when changing a tire to reduce the risk of serious injury or death. CAUTION Be careful as you use the jack handle to stay clear of the flat end. The flat end OBC3083038L OBC3083038L has sharp edges that could cause cuts.
Page 520: Changing Tires
Emergency situations Changing tires WARNING A vehicle can slip or roll off of a jack causing serious injury or death to you or those nearby. Take the following safety precautions: • Do not get under a vehicle that is sup- ported by a jack.
Page 521 13. Use the wheel lug nut wrench to tight- en the lug nuts in the order shown. Double-check each lug nut until they are tight. After changing tires, we rec- ommend that an authorized HYUNDAI OBC3083008L OBC3083008L dealer tighten the lug nuts to their 8.
Page 522 We rec- ommend that you consult an authorized HYUNDAI dealer for assistance. If any of the equipment such as the jack, lug nuts, studs, or other equipment is...
Page 523 When driving with the compact spare tire CAUTION mounted to your vehicle: To prevent damaging the compact • Check the tire pressure after installing spare tire and your vehicle: the compact spare tire. The compact spare tire should be inflated to 420 kPa •...
Page 524: Jack Label
Emergency situations Jack label Type A Type A Type B Type B OHYK065011/OAC3N070038TU OHYK065011/OAC3N070038TU The actual Jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack. 1. Model Name 2.
Page 525: Ec Declaration Of Conformity For Jack
EC Declaration of conformity for Jack Type A OBC3080031TU OBC3080031TU 8-21...
Page 526 Emergency situations OBC3080032TU OBC3080032TU 8-22...
Page 527 Type B OBC3080029 OBC3080029 8-23...
Page 528 Emergency situations OBC3080030 OBC3080030 8-24...
Page 529: Introduction
The Tire Mobility Kit is a temporary fix to sidewall, cannot be sealed completely. the tire and we recommend that the tire Air pressure loss in the tire may adversely inspected by an authorized HYUNDAI affects tire performance. dealer. For this reason, you should avoid abrupt...
Page 530: Notes On The Safe Use Of The Tire Mobility Kit
Tire Mobility Kit, we recom- flush your eyes for at least 15 minutes. mend that you contact an authorized If the irritation persists, seek medical HYUNDAI dealer. attention. • In case of swallowing the sealant, rinse the mouth and drink plenty of water.
Page 531: Components Of The Tire Mobility Kit
Components of the Tire Mobility Kit OIA0630007/Q OIA0630007/Q 1. Speed restriction label 2. Sealant bottle and label with speed restriction 3. Filling hose to wheel 4. Connectors and cable for the power outlet direct connection 5. Holder for the sealant bottle 6.
Page 532: Using The Tire Mobility Kit When A Tire Is Flat
Emergency situations WARNING Sealant • Keep out of reach of children. • Avoid contact with eyes. • Do not swallow. Using the Tire Mobility Kit When a tire is flat OBC3083041L OBC3083041L 1. Shake the sealant bottle. CAUTION ODN8079019 ODN8079019 OBC3083044L OBC3083044L 2.
Page 533 OBC3083025L OBC3083025L ODN8079020 ODN8079020 5. Insert the sealant bottle into the hous- 7. Connect between compressor and the ing (5) of the compressor so that the vehicle power outlet using the cable bottle is upright. and connectors (4). 6. Ensure that the compressor is switched 8.
Page 534: Distributing The Sealant
HYUNDAI dealer. We recommend that you use the sealant of Tire Mobility Kit from an authorized HYUNDAI dealer. The sealant on the tire pressure valve and wheel should be removed when you replace the tire with a new one and we recommend that the tire pressure valve be inspected by an authorized HYUNDAI dealer.
Page 535: Towing
OBC3083014L OBC3083014L [A] : Dolly If emergency towing is necessary, we recommend having it done by an autho- rized HYUNDAI dealer or a commercial tow-truck service. OBC3083016L OBC3083016L Proper lifting and towing procedures are necessary to prevent damage to the vehi- •...
Page 536: Removable Towing Hook
Emergency situations When towing your vehicle in an emer- Type A Type A gency without wheel dollies: 1. Place the ignition switch in the ACC position. 2. Place the shift lever in N (Neutral). 3. Release the parking brake. CAUTION Failure to place the shift lever in N (Neutral) may cause internal damage to OBC3083018L...
Page 537: Emergency Towing
If towing is necessary, we recommend communicate with each other fre- you have it done by an authorized quently. HYUNDAI dealer or a commercial tow • Before emergency towing, check that truck service. the hook is not broken or damaged.
Page 538 Emergency situations NOTICE To avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull a vehicle out of mud, sand or other con- ditions from which the vehicle cannot be driven out under its own power.
Page 539: Emergency Situations
Your vehicle is equipped with emergen- Tire pressure gauge cy commodities to help you respond to Tires normally lose some air in day-to- emergency situation. day use, and you may have to add a air periodically and usually it is not a sign of Fire extinguisher a leaking tire, but of normal wear.
Page 540 Emergency situations The vehicle is equipped with a device* connected with the Pan-European eCall system for making emergency call to response teams. The Pan-European eCall system is an automatic emergency call service made in the event of a traffic accident or other** accidents on the roads of Europe.
Page 541 Once the data which is stored in the Pan-European eCall system is delivered to the res- cue center to assist the driver and passengers with proper rescue operations, the data will be deleted after rescue operation is completed. Description of the eCall in-vehicle system Antenna SOS Button Emergency...
Page 542 Emergency situations Information on data processing Types of data and its recipients The 112-based eCall in-vehicle system Any processing of personal data through may collect and process only the follow- the 112-based eCall in-vehicle system ing data: shall comply with the personal data pro- - Vehicle Identification Number tection rules provided for in Directives 95/46/EC (1) and 2002/58/EC (2) of the...
Page 543 (1) Directive 95/46/EC of the European Arrangements for data processing Parliament and of the Council of 24 The 112-based eCall in-vehicle system is October 1995 on the protection of designed in such a way as to ensure that individuals with regard to the pro- the data contained in the system memory cessing of personal data and on the is not available outside the system before...
Page 544: Pan-European Ecall System
Emergency situations Modalities for exercising data Pan-European eCall System subject’s rights The data subject (the vehicle’s owner) has a right of access to data and as appropri- ate to request the rectification, erasure or blocking of data, concerning him or her, the processing of which does not comply with the provisions of Directive 95/46/ EC.
Page 545 Automatic accident reporting System operation in the System operation in the Connection with the Connection with the Emergency services Emergency services event of a traffic accident event of a traffic accident Public Safety Answering Public Safety Answering Point (PSAP) Point (PSAP) OBC3083024L OBC3083024L The Pan-European eCall device automatically makes an emergency call to the Public...
Page 546 Emergency situations Manual accident reporting OBC3083026L OBC3083026L The driver or passenger manually can make an emergency call in the Public Safety Answering Point (PSAP), by pressing SOS button to call the necessary emergency ser- vices. A call to the emergency services through the Pan-European eCall system can be can- celled by pressing the SOS button again only before the call connection.
Page 547: Pan-European Ecall System
Pan-European eCall system. We recommend that the Pan-european eCall system checked at an authorized HYUNDAI dealer immediately. Otherwise correct operation of the Pan- European eCall system device, installed in your vehicle is not guaranteed.owner...
Page 549 9. Maintenance Engine compartment overview ..............9-3 Maintenance services ..................9-6 Owner’s responsibility ....................9-6 Owner maintenance precautions................9-6 Owner maintenance ..................9-7 Owner maintenance schedule ..................9-7 Scheduled maintenance services ..............9-9 Normal Maintenance Schedule (For Europe) ............9-10 Maintenance Under Severe Usage and Low Mileage Conditions (For Europe) ...9-13 Normal Maintenance Schedule (Except Europe) ...........
Page 550 Battery ......................9-40 For best battery service ...................9-41 Battery capacity label .................... 9-42 Battery recharging ....................9-42 Reset items ......................9-43 Tires and wheels ..................9-44 Tire care ........................9-44 Recommended cold tire inflation pressures ............9-45 Check tire inflation pressure .................. 9-45 Tire rotation ......................9-46 Wheel alignment and tire balance .................
Page 551: Engine Compartment Overview
ENGINE COMPARTMENT OVERVIEW Smartstream G 1.0 T-GDi/Smartstream G1.0 T-GDi (48V) MHEV Smartstream G 1.0 T-GDi/Smartstream G1.0 T-GDi (48V) MHEV - Left-hand drive - Left-hand drive - Right-hand drive - Right-hand drive The actual engine room in the vehicle may differ from the illustration. OBC3090001/OBC3090001R OBC3090001/OBC3090001R 1.
Page 552 Maintenance Smartstream G1.2 Smartstream G1.2 - Left-hand drive - Left-hand drive - Right-hand drive - Right-hand drive The actual engine room in the vehicle may differ from the illustration. OBC3090003/OBC3090003R OBC3090003/OBC3090003R 1. Engine coolant reservoir 4. Air cleaner 5. Fuse box 6.
Page 553 Gasoline 1.4 Gasoline 1.4 - Left-hand drive - Left-hand drive - Right-hand drive - Right-hand drive The actual engine room in the vehicle may differ from the illustration. OBC3090004/OBC3090004R OBC3090004/OBC3090004R 1. Engine coolant reservoir 4. Air cleaner 5. Fuse box 6.
Page 554: Maintenance Services
HYUNDAI in order Your vehicle should not be modified to provide you with a high level of service in any way. Such modifications may satisfaction.
Page 555: Owner Maintenance
OWNER MAINTENANCE The following lists are vehicle checks and WARNING inspections that should be performed by the owner or an authorized HYUNDAI Performing maintenance work on a dealer at the frequencies indicated to vehicle can be dangerous. If you lack...
Page 556 Maintenance While operating your vehicle: At least twice a year: (for example, every Spring and • Note any changes in the sound of the Autumn) exhaust or any smell of exhaust fumes in the vehicle. • Check radiator, heater and air condi- tioning hoses for leaks or damage.
Page 557: Scheduled Maintenance Services
SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. • Repeated driving short distance of less than 8 km (5 miles) in normal temperature or less than 16 km (10 miles) in freezing temperature •...
Page 558 Maintenance 9-10...
Page 559 9-11...
Page 560 Maintenance 9-12...
Page 561 9-13...
Page 562 Maintenance 9-14...
Page 563 9-15...
Page 564 Maintenance 9-16...
Page 565 9-17...
Page 566 Maintenance 9-18...
Page 567 9-19...
Page 568 Maintenance 9-20...
Page 569: Explanation Of Scheduled Maintenance Items
ACC position. es and connections be replaced by an authorized HYUNDAI dealer. Fuel filter (Except Europe) A clogged filter can limit the speed at Vapor hose and fuel filler cap...
Page 570 Air cleaner filter Automatic transmission fluid (if equipped) We recommend that the air cleaner filter be replaced by an authorized HYUNDAI Automatic transmission fluid should not dealer. be checked under normal usage condi- tions. Spark plugs We recommend that the automatic trans-...
Page 571 Brake pads, calipers and rotors Check the pads for excessive wear, discs for run out and wear, and calipers for fluid leakage. For more information on checking the pads or lining wear limit, refer to the HYUNDAI web site. (http://service.hyundai-motor.com) 9-23...
Page 572: Engine Oil
Maintenance ENGINE OIL Engine oil is used for lubricating, cooling, 1. Follow all of the oil manufacturer’s and operating various hydraulic compo- precautions. nents in the engine. Engine oil consump- 2. Be sure the vehicle is on the level tion while driving is normal, and it is ground in P (Park) with the parking necessary to check and refill the engine brake set and the wheels blocked.
Page 573 NOTICE Smartstream G 1.0 T-GDi/ Smartstream G 1.0 T-GDi/ Smartstream G1.0 T-GDi (48V) MHEV Smartstream G1.0 T-GDi (48V) MHEV To prevent damage to your engine: • Do not spill engine oil when adding or changing engine oil. Wipe off spilled oil immediately.
Page 574: Checking The Engine Oil And Filter
• We recommend that the engine oil and filter be replaced by an authorized The engine oil is very hot immediately HYUNDAI dealer. after the vehicle has been driven and • If the maintenance schedule to replace can cause burns during replacement.
Page 575: Engine Coolant
If the coolant level is low, add enough distilled (deionized) water. Bring the level to [F(Full)], but do not overfill. If frequent additions are required, we recommend that the system be inspected by an authorized HYUNDAI dealer. 9-27...
Page 576 Maintenance • When you are sure all the pressure Type A Type A has been released, press down on the cap, using a thick towel, and continue turning counterclockwise to remove • Even if the engine is not operating, do not remove the radiator cap/engine coolant reservoir cap or the drain plug while the engine and radiator are hot.
Page 577 Recommended engine coolant WARNING • When adding coolant, use only distilled (deionized) water for your vehicle and never mix hard water in the coolant filled at the factory. An incorrect cool- ant mixture can result in serious mal- function or engine damage. •...
Page 578: Changing The Engine Coolant
Maintenance Changing the engine coolant We recommend that coolant be changed by an authorized HYUNDAI according to the Maintenance Schedule at the begin- ning of this chapter. NOTICE Put a thick cloth or fabric around the radiator cap before refilling the coolant...
Page 579: Brake/Clutch Fluid
If the brake/clutch system requires frequent additions of fluid, this could indicate a leak in the brake/clutch sys- tem. We recommend that the vehicle be inspected by an authorized HYUNDAI dealer. OBC3090016R OBC3090016R Check the fluid level in the reservoir periodically.
Page 580 Maintenance WARNING Do not allow brake/clutch fluid to come in contact with your eyes. If brake/ clutch fluid comes in contact with your eyes, flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. NOTICE •...
Page 581: Checking The Intelligent Manual Transmission System Actuator Fluid Level
If the oil level is below the MIN mark, have the vehicle checked by a profes- sional workshop. We recommend that CAUTION you contact an authorized HYUNDAI dealer/service partner. Do not allow intelligent manual trans- mission system actuator fluid to con- Use only the specified intelligent man- ual transmission system actuator fluid.
Page 582: Washer Fluid
WARNING HYUNDAI dealer. To prevent serious injury or death, take Stroke : 5~7 “clicks’’ at a force of 20 kg the following safety precautions when (44 lbs, 196 N).
Page 583: Air Cleaner
AIR CLEANER Filter replacement OBC3090019 OBC3090019 OBC3090018 OBC3090018 The air cleaner filter can be cleaned for inspection using compressed air. Do not attempt to wash or to rinse it, as water will damage the filter. If soiled, the air cleaner filter must be replaced.
Page 584 • When removing the air cleaner filter, be careful that dust or dirt does not enter the air intake, or damage may result. • Use HYUNDAI genuine parts or the equivalent specified one for your vehicle. Use of non-genuine parts could damage the air flow sensor.
Page 585: Climate Control Air Filter
CLIMATE CONTROL AIR FILTER Filter inspection The climate control air filter should be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
Page 586: Wiper Blades
Maintenance WIPER BLADES Blade inspection Blade replacement Contamination of either the windshield When the wipers no longer clean the or the wiper blades with foreign matter windshield adequately, the blades may can reduce the effectiveness of the wind- be worn or cracked, and require replace- shield wipers.
Page 587 4. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, we recommend that the wiper blade be replaced by an autho- rized HYUNDAI dealer. 9-39...
Page 588: Battery
Maintenance • Do not allow the (+) and (-) jumper WARNING cables to touch. It may cause sparks. To prevent SERIOUS INJURY or DEATH • The battery may rupture or explode to you or bystanders, always follow when you jump start with a low or these precautions when working near frozen battery.
Page 589: For Best Battery Service
Also, do not overfill the battery cells. If not, it may corrode the battery or other components. Finally, securely close the cell cap. However, we recommend you to con- tact an authorized HYUNDAI dealer for better battery service. 9-41...
Page 590: Battery Capacity Label
(boil- ing) violently or if the temperature 1. AGM50L-DIN: The HYUNDAI model of the electrolyte of any cell exceeds name of battery 49°C (120°F).
Page 591: Reset Items
The vehicle may not recommend that the AGM battery be restart if you shut it off before the battery serviced by an authorized HYUNDAI had a chance to adequately recharge. dealer. For charging your AGM bat- See “Jump Starting”...
Page 592: Tires And Wheels
Maintenance TIRES AND WHEELS Tire care WARNING For proper maintenance, safety, and Tire failure may cause loss of vehicle maximum fuel economy, you must control resulting in an accident. To always maintain recommended tire infla- reduce risk of SERIOUS INJURY or tion pressures and stay within the load DEATH, take the following precautions: limits and weight distribution recom-...
Page 593: Recommended Cold Tire Inflation Pressures
1.6 km (one mile). mend that the system be checked by Warm tires normally exceed recom- an authorized HYUNDAI dealer. mended cold tire pressures by 28 to 41 • Overinflation produces a harsh ride, kPa (4 to 6 psi). Do not release air from...
Page 594: Tire Rotation
If a valve cap is missing, install a new one as soon as possible. Tire rotation CBGQ0707 CBGQ0707 To equalize tread wear, HYUNDAI recom- Directional tires (if equipped) Directional tires (if equipped) mends that the tires be rotated depend- ing on the maintenance schedule or sooner if irregular wear develops.
Page 595: Wheel Alignment And Tire Balance
Tire replacement Information The outside and inside of the unsymmetri- Tread wear indicator Tread wear indicator cal tire is distinguishable. When installing an unsymmetrical tire, be sure to install the side marked “outside” face the outside. If the side marked “inside” is installed on the outside, it will have a negative effect on vehicle performance.
Page 596 Do not operate your vehicle over they are not being used. Regardless 80 km/h (50 mph) when using the com- of the remaining tread, HYUNDAI rec- pact spare tire. ommends that tires be replaced after six (6) years of normal service.
Page 597: Wheel Replacement
Wheel replacement When replacing the metal wheels for any reason, make sure the new wheels are equivalent to the original factory units in diameter, rim width and offset. Tire traction Tire traction can be reduced if you drive on worn tires, tires that are improperly inflated or on slippery road surfaces.
Page 598 Maintenance 3. Checking tire life (TIN : Tire Wheel size designation Identification Number) Wheels are also marked with impor- tant information that you need if you Any tires that are over six years old, based ever have to replace one. The following on the manufacturing date, (including explains what the letters and numbers in the spare tire) should be replaced by...
Page 599 The relative performance of tires depends 5. Maximum permissible inflation upon the actual conditions of their use, pressure however, and may depart significantly This number is the greatest amount of air from the norm due to variations in driving pressure that should be put in the tire. habits, service practices and differences Do not exceed the maximum permis- in road characteristics and climate.
Page 600: Low Aspect Ratio Tires
Excessive rized HYUNDAI dealer. speed, under-inflation, over-inflation, • Inspect the tire condition and pres- or excessive loading, either separately...
Page 601: Fuses
Normal the same rating. Cartridge type Cartridge type If the replacement fuse blows, this indi- cates an electrical problem. Avoid using the system involved and we recommend that all inspect an authorized HYUNDAI dealer. Normal Normal Blown Blown Information Multi fuse...
Page 602: Instrument Panel Fuse Replacement
Maintenance Instrument panel fuse replacement OBC3090026 OBC3090026 5. Pull the suspected fuse straight out. Use the removal tool provided in the OBC3093025L OBC3093025L engine compartment fuses panel. 1. Turn the vehicle off. 6. Check the removed fuse; replace it if 2.
Page 603: Engine Compartment Panel Fuse Replacement
HYUN- DAI dealer. If the multi fuse is blown, we recom- mend that you consult with an authorized HYUNDAI dealer. NOTICE After checking the fuse panel in the engine compartment, securely install the fuse panel cover. You may hear a clicking sound if the cover is securely latched.
Page 604: Fuse/Relay Panel Description
Maintenance Fuse/relay panel description Information Driver’s side fuse panel Not all fuse panel descriptions in this man- ual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label.
Page 605 Driver’s side fuse panel Fuse Name Symbol Circuit Protected A/C Control Module, HEATED MIRROR Driver/Passenger Power Outside Mirror SAFETY Driver Safety Power Window Module P/WINDOW FRONT Front Seat Warmer Control Module SEAT WARMER Power Window Main Switch, P/WINDOW RH [LHD] Passenger Power Window Switch [G3LE] Sport Mode Switch, TCM, Transmission TCU2 Range Switch, Electronic Clutch Module,...
Page 606 Maintenance Driver’s side fuse panel Fuse Name Symbol Circuit Protected E-Call Unit, A/T Shift Lever Indicator, Display audio, A/V & Navigation Head Unit, Wireless Charger, Electro Chromic Mirror, MODULE 5 Front Seat Warmer Control Module, Rear Seat Warmer Control Module, Low DC-DC Converter (ISG*NON 48V), AMP, A/C Control Module, Data Link Connector, Head lamp leveling device ABS 3...
Page 607 Engine compartment fuse panel Information Not all fuse panel descriptions in this man- ual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. OBC3090026 OBC3090026 Inside the fuse/relay box covers, you can...
Page 608 Maintenance Smartstream G1.2 Smartstream G1.2 Gasoline 1.4 Gasoline 1.4 OBC3093033L OBC3093033L OBC3093032L OBC3093032L 9-60...
Page 609 Smartstream G1.0 T-GDi/Smartstream G1.0 T-GDi (48 HEV) Fuse Name Symbol Relay Name Type RLY.1 Main Relay MINI RLY.2 Cooling Fan Relay MINI RLY.3 Wiper (High) Relay MICRO RLY.4 Wiper (Low) Relay MICRO RLY.5 Fuel Pump Relay MICRO RLY.6 Start Relay MICRO RLY.7 RR WIPER Relay...
Page 610 Maintenance Smartstream G1.0 T-GDi/Smartstream G1.0 T-GDi (48 HEV) Fuse Name Symbol Circuit Protected (180A) Alternator, Multi Fuse - F2, Fuse - F28/F29/F30/ [150A] F31/F32/F33 MDPS 1 MDPS Unit DCT1 E-CLUTCH1 Electronic Clutch Module DCT2 ECU1 E/R Junction Block (RLY.1) [With Smart Key] PDM Relay Box (IG1, ACC Relay) [W/O Smart Key] Ignition Switch FUEL PUMP E/R Junction Block (RLY.5)
Page 611 Smartstream G1.0 T-GDi/Smartstream G1.0 T-GDi (48 HEV) Fuse Name Symbol Circuit Protected IGN COIL Ignition Coil #1/#2/#3 ECU5 ECU6 E/R Junction Block (RLY.2), Oil Control Valve #1/#2 (Intake/Exhaust), SENSOR 1 Purge Control Solenoid Valve, RCV Control, V_Oil Pump, Recirculation valve control SENSOR 2 Oxygen Sensor (Up/Down) RR DEFOG...
Page 612 Maintenance Smartstream G1.2 Fuse Name Symbol Relay Name Type RLY.1 Main Relay MINI RLY.3 Wiper (High) Relay MICRO RLY.4 Wiper (Low) Relay MICRO RLY.5 Fuel Pump Relay MICRO RLY.6 Start Relay MICRO RLY.7 RR WIPER Relay MICRO RLY.8 A/CON Relay MICRO RLY.9 Cooling Fan High Relay...
Page 613 Smartstream G1.2 Fuse Name Symbol Circuit Protected (125A) Alternator, Multi Fuse - F2, Fuse - F22/F23/F24/F25/ [150A] F26/F27 MDPS 1 MDPS Unit ECU1 E/R Junction Block (RLY.1) [With Smart Key] PDM Relay Box (IG1, ACC Relay) [W/O Smart Key] Ignition Switch FUEL PUMP E/R Junction Block (RLY.5) ECU3...
Page 614 Maintenance Smartstream G1.2 Fuse Name Symbol Circuit Protected RR DEFOG ICU Junction Block (Rear Defogger Relay) ABS 1 ESC Control Module BLOWER E/R Junction Block (RLY.13) E/R Junction Block (RLY.14) HEATER ABS 2 ESC Control Module POWER ICU Junction Block (Power Outlet Relay) OUTLET WIPER 2 E/R Junction Block (RLY.
Page 615 Gasoline 1.4 Fuse Name Symbol Relay Name Type RLY.1 Main Relay MINI RLY.3 Wiper (High) Relay MICRO RLY.4 Wiper (Low) Relay MICRO RLY.5 Fuel Pump Relay MICRO RLY.6 Start Relay MICRO RLY.7 RR WIPER Relay MICRO RLY.9 Cooling Fan High Relay MICRO RLY.10 Cooling Fan Low Relay...
Page 616 Maintenance Gasoline 1.4 Fuse Name Symbol Circuit Protected (125A) Alternator, Multi Fuse - F2, Fuse - F22/F23/F24/F25/ [150A] F26/F27 MDPS 1 MDPS Unit ECU1 E/R Junction Block (RLY.1) [With Smart Key] PDM Relay Box (IG1, ACC Relay) [W/O Smart Key] Ignition Switch FUEL PUMP E/R Junction Block (RLY.5) TCU1...
Page 617 Gasoline 1.4 Fuse Name Symbol Circuit Protected SENSOR 2 Oxygen Sensor (Up/Down) RR DEFOG ICU Junction Block (Rear Defogger Relay) ABS 1 ESC Control Module BLOWER E/R Junction Block (RLY.13) E/R Junction Block (RLY.14) HEATER ABS 2 ESC Control Module POWER ICU Junction Block (Power Outlet Relay) OUTLET...
Page 618: Light Bulbs
Maintenance LIGHT BULBS We recommend that you consult with an Information authorized HYUNDAI dealer to replace most vehicle light bulbs. It is difficult to The headlight and tail lamp lenses could replace vehicle light bulbs because other appear frosty if the vehicle is washed after...
Page 619: Headlight, Position Light, Turn Signal Light Bulb Replacement
Headlight, Position Light, Type C - CUV Turn signal Light bulb replacement Type A OBC3V091001 OBC3V091001 (1) Headlight(Low/High) (2) Turn signal light (3) Daytime running light & Position light OBC3093064L OBC3093064L (1) Headlight(Low/High) : MFR (Multi Focus Reflector) Headlight (2) Turn signal light (3) Position light(if equipped) (4) Daytime running light Type B -N line...
Page 620 Maintenance • Always handle them carefully, and Headlight (Low/High) avoid scratches and abrasions. If the 1. Turn the front wheel at inwards. bulbs are lit, avoid contact with liquids. • Never touch the glass with bare hands. Residual oil may cause the bulb to overheat and burst when lit.
Page 621 5DR, N-line 5DR, N-line 5DR, N-line 5DR, N-line OBC3090039 OBC3090039 OBC3090038 OBC3090038 OBC3TN091005 OBC3TN091005 OBC3TN091006 OBC3TN091006 4. Disconnect the headlight bulb socket- Turn signal light connector. 1. Open the hood. 5. Unsnap the headlight bulb retaining 2. Remove the turn signal light or low wire by depressing the end and push- beam assist-static light bulb cover by ing it upward.
Page 622 (LED type) If the LED lamp does not operate, we rec- ommend that the system be inspected by an authorized HYUNDAI dealer. The LED lamps cannot be replaced as a single unit because it is an integrated unit. The LED lamp has to be replaced with the unit.
Page 623 HYUNDAI dealer. The LED Push the socket into the housing and lamps cannot be replaced as a single unit turn the socket clockwise.
Page 624: Headlight Aiming (For Europe)
Maintenance 3. Draw vertical lines (Vertical lines pass- Headlight aiming (For Europe, if ing through respective head light cen- equipped) ters) and a horizontal line (Horizontal Headlight aiming line passing through center of head lamps) on the screen. Type A Type A 4.
Page 625 Aiming point <Ground Height> <Ground Height> <Distance between lamps> <Distance between lamps> H1 : Lighting center Ground clearance of Headlight Low & High Beam H1 : Lighting center Ground clearance of Headlight Low & High Beam H3 : Lighting center Ground clearance of Front fog light H3 : Lighting center Ground clearance of Front fog light W1 : Lighting center Distance between Headlight Low &...
Page 626 Maintenance Head lamp low beam (LHD side) Based on 10m screen Based on 10m screen OBC3090058 OBC3090058 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3.
Page 627 Head lamp low beam (RHD side) Based on 10m screen Based on 10m screen OBC3090059 OBC3090059 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3.
Page 628 Maintenance Front fog light Based on 10m screen Based on 10m screen OBC3090060 OBC3090060 1. Turn the front fog lamp on with the driver (75 kg) aboard. 2. The cut-off line should be projected in the allowable range (shaded region). 9-80...
Page 629: Side Repeater Light Replacement
If the LED lamp does not operate, we rec- the assembly out. ommend you to have the vehicle checked 2. Disconnect the bulb electrical connec- by an authorized HYUNDAI dealer. tor. 3. Separate the socket and the lens parts by turning the socket counterclock- wise until the tabs on the socket align with the slots on the lens part.
Page 630: Rear Combination Light Bulb Replacement
Maintenance Rear combination light bulb replacement Type A OIB074037 OIB074037 OBC3093045L OBC3093045L (1) Turn signal light (2) Tail/Stop light (3) Tail light (4) Rear fog light /Rear reflection light (5) Back-up light /Rear reflection light OIB074038A OIB074038A 1. Open the tailgate 2.
Page 631 OBC3090047 OBC3090047 OBC3093050L OBC3093050L [1] : Turn Signal Light, [2] : Tail/Stop Light, [1] : Rear Fog Light, [2] : Back-up Light [3] : Tail light Rear fog light, Back-up Light Turn signal light, Tail/stop light 1. Remove the rear tire and wheel cover. 4.
Page 632 Maintenance Type B OIB074037 OIB074037 OBC3093046L OBC3093046L (1) Tail light (2) Stop light (3) Turn signal lamp (4) Tail light (5) Rear fog light /Rear reflection light (6) Back-up light OIB074038 OIB074038 1. Open the tailgate 2. Loosen the light assembly retaining screws with a cross-tip screwdriver.
Page 633 HYUNDAI dealer. The LED 4. Take the light assembly out. lamps cannot be replaced as a single unit because it is an integrated unit. The LED lamp has to be replaced with the unit.
Page 634 Maintenance Type C OIB074037 OIB074037 OBC3V093002L OBC3V093002L (1) Turn signal lamp (2) Tail/Stop light (3) Tail light (4) Rear fog light/Rear reflection light (5) Back-up light/Rear reflection light OIB074038 OIB074038 1. Open the tailgate 2. Loosen the light assembly retaining screws with a cross-tip screwdriver.
Page 635 OBC3V091003 OBC3V091003 OBC3V091004 OBC3V091004 [1] : Turn Signal Light, [2] : Tail/Stop Light, [1] : Rear Fog Light [3] : Tail light Rear fog light, Rear reflection light Turn signal light, Tail/stop light, Tail 1. Remove the rear tire and wheel cover. light 2.
Page 636 Pull an authorized HYUNDAI dealer. The LED the bulb out of the socket. lamps cannot be replaced as a single unit 4.
Page 637: High Mounted Stop Light Replacement
High mounted stop light License plate light bulb replacement replacement OAI3089029 OAI3089029 OBC3093051L OBC3093051L 1. Open the tailgate. 1. Using a flat-blade screwdriver gently pry the lens cover from the lamp hous- 2. Remove the socket by turning it coun- ing.
Page 638: Interior Light Bulb Replacement
Maintenance 1. Using a flat-head screwdriver, gently Interior light bulb replacement pry the lens from the interior light Map lamp Map lamp housing. 2. Remove the bulb by pulling it straight out. 3. Install a new bulb into the socket. 4.
Page 639: Appearance Care
APPEARANCE CARE NOTICE NOTICE If you park your vehicle near a stainless • Do not use strong soap, chemical steel sign or glass facade building, the detergents or hot water, and do not vehicle’s exterior plastic parts such as wash the vehicle in direct sunlight or a bumper, spoiler, garnish, lamp or out- when the body of the vehicle is warm.
Page 640 Maintenance Waxing Wax the vehicle when water will no lon- ger bead on the paint. Always wash and dry the vehicle before waxing. Use a good quality liquid or paste wax, and follow the manufacturer’s instructions. Wax all metal trim to protect it and to maintain its luster.
Page 641 Finish damage repair Bright-metal maintenance Deep scratches or stone chips in the • To remove road tar and insects, use painted surface must be repaired a tar remover, not a scraper or other promptly. Exposed metal will quickly rust sharp object. and may develop into a major repair •...
Page 642 Maintenance Corrosion protection WARNING Protecting your vehicle from corro- After washing the vehicle, test the sion brakes while driving slowly to see if they By using the most advanced design and have been affected by water. If braking construction practices to combat corro- performance is impaired, dry the brakes sion, we produces vehicles of the highest by applying them lightly while maintain-...
Page 643 Keep your vehicle clean Moisture breeds corrosion The best way to prevent corrosion is to Moisture creates the conditions in which keep your vehicle clean and free of corro- corrosion is most likely to occur. For sive materials. Attention to the underside example, corrosion is accelerated by high of the vehicle is particularly important.
Page 644: Interior Care
Maintenance Keep your garage dry Interior care Don’t park your vehicle in a damp, poorly Interior general precautions ventilated garage. This creates a favor- Prevent chemicals such as perfume, cos- able environment for corrosion. This is metic oil, sun cream, hand cleaner and particularly true if you wash your vehicle air freshener from contacting the interior in the garage or drive it into the garage...
Page 645 Cleaning the upholstery and interior Leather (if equipped) trim • Features of Seat Leather Vehicle interior surfaces (if equipped) - Leather is made from the outer skin of an animal, which goes through a Remove dust and loose dirt from interior special process to be available for surfaces with a whisk broom or a vacuum use.
Page 646 Maintenance • Caring for the leather seats Cleaning the lap/shoulder belt webbing - Vacuum the seat periodically to remove dust and sand on the seat. Clean the belt webbing with any mild It will prevent abrasion or damage of soap solution recommended for cleaning the leather and maintain its quality.
Page 647: Crankcase Emission Control System
The emission control system of your 1. Crankcase emission control vehicle is covered by a written limited system warranty. Please see the warranty infor- The positive crankcase ventilation sys- mation contained in the Service Passport tem is employed to prevent air pollution in your vehicle.
Page 648: Exhaust Emission Control System
• Do not modify or tamper with any part sion control system. of the engine or emission control sys- tem. We recommend that all inspec- tions and adjustments are made by an authorized HYUNDAI dealer. 9-100...
Page 649 GPF sys- tem checked by an authorized HYUNDAI Failure to observe these precautions dealer. could result in damage to the catalytic converter and to your vehicle.
Page 651 Index...
Page 652 Index Accessing your vehicle ..................5-4 Immobilizer system ..................5-12 Remote key ......................5-4 Smart key ......................5-7 Active air flap ...................... 6-57 Malfunction ..................... 6-57 Air bag - supplemental restraint system ............. 3-41 Additional safety precautions ................3-58 Air bag warning labels ..................3-58 Do not install a Child Restraint System on the front passenger seat ....
Page 653 Battery ......................... 9-40 Battery capacity label ..................9-42 Battery recharging .................... 9-42 For best battery service ..................9-41 Reset items ....................... 9-43 Before driving ....................... 6-4 Before entering the vehicle ................6-4 Before starting ....................6-4 Blind-Spot Collision Warning (BCW) ..............7-37 Blind-Spot Collision Warning malfunction and limitations ......
Page 654 Index Center console overview (left-hand drive) ............2-14 Center console overview (right-hand drive) ............2-16 Child restraint system (CRS) ................3-30 Installing a Child Restraint System (CRS) ............3-33 Our recommendation:Children always in the rear ........... 3-30 Selecting a Child Restraint System (CRS) ............3-31 Climate control air filter ..................
Page 655 Driver Attention Warning (DAW) ............... 7-69 Driver Attention Warning malfunction and limitations ........7-71 Driver Attention Warning operation ..............7-70 Driver Attention Warning settings ..............7-69 Dual clutch transmission ..................6-25 Dual clutch transmission operation ..............6-25 Good driving practices ..................6-33 Parking ......................
Page 656 High Beam Assist operation ................5-51 High Beam Assist settings ................5-50 Hood ........................5-37 Emergency tailgate safety release ..............5-40 Fuel filler door ....................5-40 Hood ......................... 5-37 Tailgate ......................5-38 How to use this manual ..................1-3 Hyundai motor company ..................1-2...
Page 657 Idle stop and go (ISG) system ................6-45 Activating the ISG .................... 6-45 Condition of ISG system operation ..............6-49 Deactivating the ISG ..................6-45 ISG Indication ....................6-50 ISG malfunction ....................6-51 If the engine overheats ................... 8-9 If the engine will not start ..................8-5 If the engine doesn’t turn over or turns over slowly .........
Page 658 Index Infotainment system..................... 5-95 Antenna ......................5-95 Bluetooth® Wireless Technology hands-free ..........5-98 How vehicle radio works .................. 5-99 Steering wheel audio control ................5-96 USB port ......................5-95 Voice recognition ..................... 5-98 Instrument cluster ....................4-2 Cluster display messages ................. 4-22 Gauges and meters .....................
Page 659 Lane Following Assist (LFA) ................7-103 Lane Following Assist malfunction and limitations ........7-106 Lane Following Assist Operation ..............7-104 Lane Following Assist settings ............... 7-103 Lane Keeping Assist (LKA) ................7-31 Lane Keeping Assist malfunction and limitations ..........7-34 Lane Keeping Assist Operation ................
Page 660 Index Navigation-Based Smart Cruise Control (NSCC) ..........7-97 Limitations of Navigation-based Smart Cruise Control ........ 7-100 Navigation-based Smart Cruise Control operation .......... 7-98 Navigation-based Smart Cruise Control settings ..........7-97 Open source software notice ................2-34 Owner maintenance ....................9-7 Owner maintenance schedule ................
Page 661 Returning used vehicles ..................1-9 Reverse Parking Collision-Avoidance Assist (PCA) ......... 7-139 Reverse Parking Collision-Avoidance Assist malfunction and limitations ..7-142 Reverse Parking Collision-Avoidance Assist operation ......... 7-140 Reverse Parking Collision-Avoidance Assist settings ........7-139 Reverse Parking Distance Warning (PDW) ............7-129 Reverse Parking Distance Warning malfunction and limitations ....
Page 662 Index Hazardous driving conditions ................6-58 Highway driving ....................6-60 Reducing the risk of a rollover ................. 6-61 Rocking the vehicle ..................6-58 Smooth cornering ..................... 6-59 Start stop coasting (SSC) (for 48V MHEV) ............6-53 Engine restarting conditions ................6-53 SSC operating conditions ................
Page 663 Towing ........................ 8-31 Emergency towing ................... 8-33 Removable towing hook .................. 8-32 Towing service ....................8-31 Trailer towing ...................... 6-66 Driving with a trailer ..................6-70 If you decide to pull a trailer? ................6-67 Maintenance when towing a trailer ..............6-72 Trailer towing equipment .................

Hyundai Yeni i20 2023 Owner's Manual

Table of Contents

3. Safety System

4. Instrument Cluster

5. Convenience Features

6. Driving Your Vehicle

7. Driver Assistance System

8. Emergency Situations

9. Maintenance

Quick Links

Chapters

Related Manuals for Hyundai Yeni i20 2023

Summary of Contents for Hyundai Yeni i20 2023
