All information in this Owner's Manual is current at the time of publication.
However, Hyundai Motor India Limited reserves the right to make changes
at any time without prior notice and without obligation to incorporate such
changes so that our policy of continual product improvement may be carried
out.
This manual applies to all variants of this vehicle and includes descriptions
and explanations of optional as well as standard equipment.
As a result, you may find material in this manual that does not apply to your
specific vehicle.
This manual is provided in non-writable PDF format and can be viewable on
any computer or Device compatible with windows 7 & above and PDF read-
er. Avoid direct sunlight to CD & do not keep it in high temperature zone i.e
more than 70 degree celcius.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i20 Active 2016 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai i20 Active 2016

  • Page 1 All information in this Owner's Manual is current at the time of publication. However, Hyundai Motor India Limited reserves the right to make changes at any time without prior notice and without obligation to incorporate such changes so that our policy of continual product improvement may be carried out.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate condi- tions of the limited warranties covering the vehicle. Certain modifications may also be in vio- lation of regulations established by the Department of Transportation and other government agencies in your country.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER CAUTION DANGER indicates a hazardous situa- CAUTION indicates a hazardous situa- tion which, if not avoided, will result in tion which, if not avoided, could result in death or serious injury.
  • Page 4 Your Owner's Manual will introduce you to the features and operation of your new HYUNDAI. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
  • Page 5 We want to help you get the greatest Your safety, and the safety of others, Throughout this manual DANGER, possible driving pleasure from your is very important. This Owner's WARNING, CAUTION, NOTICE and vehicle. Your Owner’s Manual can Manual provides you with many safe- the SAFETY ALERT SYMBOL will assist you in many ways.
  • Page 6 When you are going to use leaded CAUTION petrol, we recommend that you ask an authorized HYUNDAI dealer NEVER USE LEADED FUEL. The whether leaded petrol in your vehicle use of leaded fuel is detrimental to is available or not.
  • Page 7 D D iesel engine Biodiesel NOTICE Commercially supplied Diesel blends Diesel fuel Do not let any petrol or water enter of no more than 7% biodiesel, com- Diesel engine must be operated only the tank. This would make it neces- monly known as "B7 Diesel"...
  • Page 8 No special break-in period is need- ed. By following a few simple precau- tions for the first 1,000 km (600 miles) you may add to the perform- ance, economy and life of your vehi- cle: • Do not race the engine. •...
  • Page 9 IBi Eng 1_PA RHD 1.qxd 19-01-2015 16:20 Page 1...
  • Page 10 IBi Eng 1_PA RHD 1.qxd 19-01-2015 16:20 Page 2...
  • Page 11 IBi Eng 1_PA RHD 1.qxd 19-01-2015 16:20 Page 3...
  • Page 12 IBi Eng 2_PA RHD 1.qxd 18-03-2016 16:49 Page 1...
  • Page 13: Seat

    Use of improper or insufficient each new Hyundai vehicle sold shall the owner of the Hyundai vehicle for fuel, fluids or lubricants. be free from any defects in material parts or labour. Such defective parts...
  • Page 14 1. Warranty period frequently as mentioned in this This warranty is the entire warranty Owner's Manual and Service given by HMIL for Hyundai vehicles This warranty shall exist for a period Booklet. and no dealer or its or his agent or...
  • Page 15 Hyundai Warranty Policy lated above, at no cost to the owner o Incidental or consequential dam- o Retention of the customer's copy of the Hyundai vehicle for parts or ages, including without limitation, of the original repair order and its labour.
  • Page 16 115(2) of the Central Motor Vehicle Our Authorized Dealers shall either vehicles Manufactured on or after Rules, 1989 hereinafter referred to repair or replace, any Hyundai gen- 01/06/2010). as the “In-use emission standard”, uine part listed in paragraph 3 here-...
  • Page 17 Solenoids. fuel, fluids or lubricants. • H.T. Cable Set Any repair carried out other • Ignition Coil than by Hyundai Authorized • Power Transistor 4 4 . What is not covered Dealer/ Service Centre. • Distributor and internal parts Use of parts other than 3.5 Evaporative Emission Control...
  • Page 18 This warranty is the entire warranty referred to in sub-rule (2) of Rule o In order to maintain the validity of given by HMIL for Hyundai vehicles 116 of the Central Motor Vehicles this Emission Warranty, the vehi- and no dealer or its or his agent or Rules.
  • Page 20 n Front view 1. Hood ..........5-25 2. Headlamp ........9-79 3. Fog lamp........5-71 4. Tires and wheels......9-49 5. Outside rearview mirror .....5-34 6. Front windshield wiper blades ...9-42 7. Windows ........5-20 The actual shape may differ from the illustration. OIB014001...
  • Page 21 n Rear view 1. Antenna ........6-3 2. Doors ..........5-13 3. Fuel filler door......5-27 4. Rear parking assist system*..5-80 5. High mounted stop lamp ....9-83 6. Rearview camera* ......5-79 7. Rear wiper *........9-43 8. Tailgate ........5-18 * : if equipped The actual shape may differ from the illustration. OIB014002...
  • Page 22: Table Of Contents

    1. Door lock/unlock button ....5-15 2. Outside rearview mirror folding switch*........5-36 3. Outside rearview mirror control switch*........5-35 4. Power window switches ....5-20 5. Power window lock switch ..5-23 6. Headlight leveling device*..5-72 7. Instrument panel illumination control switch*......5-38 8. Fuel filler door opener* ....5-27 9.
  • Page 23 1. Light control/Turn signals ..5-68 2. Steering wheel audio controls*..6-4 3. Instrument cluster ......5-37 4. Horn ..........5-31 5. Driver's front air bag* ....4-39 6. Wiper/Washer ......5-76 7. Trip mode switch* ......5-65 8. Engine Start/Stop button/ Key ignition switch ....7-5, 7-9 9.
  • Page 25 Front seats 1. Seat adjustment, forward/rearward 2. Seatback angle 3. Seat adjustment, height* 4. Headrest adjustment Rear seats 5. Seat folding 6. Headrest adjustment* * : if equipped The actual feature in the vehicle may differ from the illustration. OIB034001...
  • Page 26 WARNING WARNING WARNING Driver responsibility for Do not use a sitting cushion that Loose objects passengers reduces friction between the seat Loose objects in the driver’s foot and passenger. The passenger's Riding in a vehicle with seatback area could interfere with the oper- hips may slide under the lap por- reclined could lead to serious or ation of the foot pedals, possibly...
  • Page 27 WARNING (Continued) (Continued) • • In order to avoid unnecessary No passenger should ride in the and perhaps severe air bag cargo area or sit or lie on folded Driver’s seat seatbacks while the vehicle is injuries, always sit as far back as •...
  • Page 28 F F ront seats 2. Slide the seat to the position you WARNING desire. n Type A 3. Release the lever and make sure • Do not adjust the seat while wear- the seat is locked in place. ing seat belts. Moving the seat Adjust the seat before driving, and cushion forward may cause make sure the seat is locked secure-...
  • Page 29 H H eadrest WARNING (Continued) • NEVER adjust the headrest To reduce the risk of serious injury position of the driver’s seat when or death in an accident, take the the vehicle is in motion. following precautions when • Adjust the headrest as close to adjusting your headrests: the passenger’s head as possi- •...
  • Page 30 OLF034015 OIB034005 OIB034006 Adjusting the height up and down Removal/Reinstall NOTICE To raise the headrest, pull it up to the To remove the headrest: I I f you recline the seatback towards desired position (1). To lower the 1. Recline the seatback (2) with the the front with the head restraint and headrest, push and hold the release recline lever (1).
  • Page 31 S S eatback pocket (if equipped) Rear seats Headrest OIB034007 To reinstall the headrest : OIB034008 1. Put the headrest poles (2) into the OIB034038 holes while pressing the release WARNING The rear seats are equipped with button (1). headrests in all the seating positions 2.
  • Page 32 WARNING (Continued) • NEVER adjust the headrest To reduce the risk of serious injury position of the driver’s seat when or death in an accident, take the the vehicle is in motion. following precautions when • Adjust the headrest as close to adjusting your headrests: the passenger’s head as possi- •...
  • Page 33 F F olding the rear seat The rear seatbacks (or cushions) may be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING • Never allow passengers to sit on top of the folded down seatback while the vehicle is moving as OIB034010 OIB034011...
  • Page 34 To use the rear seat, lift and push up the seatback backward. Push the seatback firmly until it clicks into place. Make sure the seatback is locked in place. When returning the rear seatbacks to the upright position, remember to return the rear shoulder belts to their proper position.
  • Page 35 To use the rear seat, lift and push up WARNING the seatback backward. Push the seatback firmly until it clicks into When you return the rear seat- place. Make sure the seatback is back to its upright position after locked in place. being folded down: When returning the rear seatbacks to Be careful not to damage the seat...
  • Page 36 WARNING (Continued) WARNING • Never wear the shoulder belt • Seat belts are designed to bear For maximum restraint system under your arm or behind your upon the bony structure of the protection, the seat belts must back. An improperly positioned body, and should be worn low always be used whenever the shoulder belt can cause serious...
  • Page 37 S S eat belt warning (if equipped) Lap/shoulder belt Information If you are not able to pull out the safe- ty belt from the retractor, firmly pull the belt out and release it. After release, you will be able to pull the belt out smoothly.
  • Page 38 To adjust the height of the seat belt Front seat anchor, lower or raise the height adjuster into an appropriate position. To raise the height adjuster, pull it up (1). To lower it, push it down (3) while pressing the height adjuster button (2).
  • Page 39 L L ap belt (if equipped) Too high Correct Shorten OLMB033088 OLMB033090 With a 2-point static type seat belt, the To release the seat belt: OLMB033089 length must be adjusted manually so The seat belt is released by pressing To fasten your seat belt: it fits snugly around your body.
  • Page 40 P P re-tensioner seat belt WARNING (if equipped) For your safety, be sure that the belt webbing is not loose or twist- ed and always sit properly on your seat. When the vehicle stops suddenly, or if the occupant tries to lean forward too quickly, the seat belt retractor will 8KMB3311/H lock into position.
  • Page 41 Body work on the front area of that the system be inspected by manual. the vehicle may damage the pre- an authorized HYUNDAI dealer. tensioner seat belt system. • Do not strike the pre-tensioner Therefore, we recommend that seat belt assemblies.
  • Page 42 I I nfant or small child Larger children Information You should be aware of the specific Children who are too large for child Small children are best protected requirements in your country. Child restraint systems should always from injury in an accident when prop- and/or infant seats must be properly occupy the rear seat and use the erly restrained in the rear seat by a...
  • Page 43 If the shoulder belt portion slightly P P regnant women Injured person touches the child’s neck or face, try The use of a seat belt is recom- A seat belt should be used when an placing the child closer to the center of mended for pregnant women to injured person is being transported.
  • Page 44 This should be done even if injury. If the webbing or buckles no damage is visible. If you have are damaged, get them replaced additional questions regarding seat belt operation, we recommend that immediately. you consult an authorized HYUNDAI dealer.
  • Page 45 Children riding in the car should sit in Before buying a particular child (Continued) the rear seat and must always be restraint system, make sure it fits • When the child restraint system properly restrained to minimize the your car seat and seat belts, and fits is not in use, store it in the lug- risk of injury in an accident, sudden your child.
  • Page 46 Never let a child ride with the HYUNDAI dealer. arms and throw the child against shoulder belt under their arm or the car’s interior. • If there is not enough space to behind their back.
  • Page 47 • If the seat belt does not operate as described in this section, we recommend that the system be checked authorized HYUNDAI dealer. • Failure to observe this manual's instructions regarding child restraint system and the instruc- OIB034017...
  • Page 48 I I nstalling a child restraint system by lap/shoulder belt E2BLD310 MMSA3030 2. Fasten the lap/shoulder belt latch 3. Buckle the seat belt and allow the into the buckle. Listen for the dis- seat belt to take up any slack. After E2MS103005 installation of the child restraint tinct “click”...
  • Page 49 C C hild seat restraint suitability for seat position using the seat belt Use child safety seats that have been officially approved and are appropriate for your children. When using the child safety seats, refer to the following table. For 60:40 split rear seat Seating position Age group Co Driver...
  • Page 50: Driver's Front Air Bag*

    1. Driver’s front air bag* 2. Passenger’s front air bag* 3. Side impact air bag* 4. Curtain air bag* * : if equipped The actual air bags in the vehicle may differ from the illustration. OIB034032...
  • Page 51 HYUNDAI dealer. collision and its direction. These pant and the vehicle structures • Keep the SRS parts and wirings...
  • Page 52 • • There are even circumstances Noise and smoke WARNING under which contact with the steer- When the air bags inflate, they make ing wheel air bag can cause fatal a loud noise and they leave smoke When the air bags deploy, the air injuries, especially if the occupant is and powder in the air inside of the bag related parts in the steering...
  • Page 53 D D o not install a child restraint on Air bag warning and indicator WARNING the front passenger’s seat. (if equipped) (if equipped) Air bag warning light • NEVER use a rearward facing child restraint on a seat protect- ed by an ACTIVE AIR BAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
  • Page 54 When the ignition switch is turned S S RS components and functions The SRSCM continuously monitors ON, the warning light should illumi- all SRS components while the igni- nate for approximately 6 seconds, tion switch is ON to determine if a then go off.
  • Page 55 If any of the following conditions occurs, this indicates a malfunc- tion of the SRS. We recommend that the system be inspected by an authorized HYUNDAI dealer. • The light does not turn on briefly when you turn the ignition ON.
  • Page 56 n Driver’s front air bag (3) n Passenger’s front air bag (Continued) • When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel surface. It may become a dangerous pro- jectile and cause injury if the pas- senger's air bag inflates.
  • Page 57 D D river's and passenger's front air WARNING (Continued) bag (if equipped) • The SRS can function only n Driver’s front air bag • If an air bag deploys, there may when the ignition switch is in the be a loud noise followed by a ON position.
  • Page 58 The indications of the system's pres- WARNING (Continued) ence are the letters "AIR BAG" • Front and side impact air bags engraved on the air bag pad cover in Always use seat belts and child can injure occupants improperly the steering wheel and the passen- restraints –...
  • Page 59 Never allow chil- panel, and the front passenger's ized HYUNDAI dealer. dren to ride in the front passen- panel above the glove box, ger seat. If a child over 12 must •...
  • Page 60 S S ide impact air bag The purpose of the air bag is to pro- (Continued) (if equipped) vide the vehicle's driver and/or the • Sitting improperly or out of posi- front passenger with additional pro- tion can result in serious or fatal tection than that offered by the seat injury in a crash.
  • Page 61 • Use of seat covers could reduce passenger's seat belt systems authorized HYUNDAI dealer. or prevent the effectiveness of and is not a substitute for them. the system. Inform the dealer that your vehi-...
  • Page 62 The actual air bags in the vehicle may differ authorized HYUNDAI dealer. from the illustration. Importantly, children should sit in Failure to follow the above men-...
  • Page 63 W W hy didn’t my air bag go off in a col- Air bag collision sensors lision? (Inflation and non-inflation conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional pro- tection.
  • Page 64 This may cause unexpected air sors are installed. We recom- bag deployment, which could mend that the system be serv- result in serious personal injury iced by an authorized HYUNDAI or death. dealer. • If the installation location or •...
  • Page 65 OSA038121 OBH038060 OPA037043 • Front air bags may not inflate in • In a slant or angled collision, the • Just before impact, drivers often side impact collisions, because force of impact may direct the brake heavily. Such heavy braking occupants move to the direction of occupants in a direction where the lowers the front portion of the vehi-...
  • Page 66 However, side and/or curtain air be performed by an authorized the collision energy is absorbed by bags may inflate when the vehicle HYUNDAI dealer. Improper handling the vehicle structure. is rolled over after side impact col- of the SRS system may result in seri- lision.
  • Page 67 • mend that the system be replaced soaked carpeting or water on Modification to SRS compo- by an authorized HYUNDAI deal- the flooring, you shouldn't try to nents or wiring, including the start the engine; we recommend addition of any kind of badges to...
  • Page 68 A A dditional safety precautions • Passengers should not place hard • Do not place items under the front or sharp objects between them- seats. Placing items under the • Never let passengers ride in the selves and the air bags. Carrying front seats could interfere with the cargo area or on top of a folded- hard or sharp objects on your lap...
  • Page 69 A A dding equipment to or modifying Air bag warning label your air bag-equipped vehicle (if equipped) If you modify your vehicle by chang- ing your vehicle's frame, bumper sys- tem, front end or side sheet metal or ride height, this may affect the opera- tion of your vehicle's air bag system.
  • Page 72: Tailgate

    OIB034040 WARNING Your HYUNDAI uses a remote key, which you can use to lock or unlock Do not leave the keys in your vehi- a door (and tailgate) and even start cle with unsupervised children.
  • Page 73: Switch*

    T T ailgate unlocking Start-up Mechanical key To unlock: For detailed information refer to “Key ■ Type A ■ Type B Ignition Switch” in chapter 4. 1. Press the Tailgate Unlock button (3) on the remote key for more than one second. NOTICE 2.
  • Page 74 When the remote key does not work correctly, open and close the door with the mechanical key. If you have a problem with the remote key, it is recommended that you contact an authorized HYUNDAI dealer. (Continue)
  • Page 75 HYUNDAI authority to operate the equipment. If dealer. the keyless entry system is inoperative due to changes or modifications not...
  • Page 76 0.7~1 m (28~40 in.) from the outside door handle. OIB044179 OIB044041 To lock : Your HYUNDAI uses a Smart Key, which you can use to lock or unlock 1. Close all doors, engine hood and a door (and tailgate) and even start tailgate.
  • Page 77 Even though you press the outside U U nlocking Information door handle button, the doors will not • The door handle button will only lock and the chime will sound for operate when the smart key is with- three seconds if any of the following in 0.7~1 m (28~40 in.) from the out- occur: side door handle.
  • Page 78 This is especially important when the diately take the vehicle and remaining or an airport which can interfere key to your authorized HYUNDAI phone is active such as making and with normal operation of the trans- dealer or tow the vehicle, if necessary.
  • Page 79 Immobilizer system malfunction transmitting normally. could occur. If the system repeatedly does not recognize the coding of the key, it is recommended that you contact your HYUNDAI dealer.
  • Page 80 O O perating door locks from out- Remote key Information side the vehicle • In cold and wet climates, door lock Mechanical key and door mechanisms may not work properly due to freezing conditions. • If the door is locked/unlocked multi- ple times in rapid succession with either the vehicle key or door lock switch, the system may stop operat-...
  • Page 81 S S mart key To lock the doors, press the button on Information the outside door handle while carry- • In cold and wet climates, door lock ing the smart key with you or press and door mechanisms may not work the door lock button on the smart key.
  • Page 82 O O perating door locks from inside • If the inner door handle of the dri- Information the vehicle ver’s door is pulled when the door If a power door lock ever fails to func- lock button is in the lock position, With the door lock button tion while you are in the vehicle try the button is unlocked and door...
  • Page 83 A A uto door lock/unlock features Child-protector rear door locks To lock the child safety lock, insert a key (or screwdriver) into the hole (1) Impact sensing door unlock sys- and turn it to the lock ( ) position. tem (if equipped) To allow a rear door to be opened All doors will be automatically from inside the vehicle, unlock the...
  • Page 84 O O pening the tailgate • The tailgate is locked or unlocked Closing the tailgate when all doors are locked or To close the tailgate, lower and push ■ Type A unlocked with the key, remote key, down the tailgate firmly. Make sure smart key or central door lock/ that the tailgate is securely latched.
  • Page 85 Emergency tailgate safety WARNING WARNING release Rear cargo area • For emergencies, be fully aware of the location of the emergency Occupants should never ride in the tailgate safety release lever in rear cargo area where the vehicle and how to open the restraints are available.
  • Page 86 P P ower windows (if equipped) (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door power window switch (Right)* (4) Rear door power window switch (Left)* (5) Window opening and closing (6) Automatic power window* (7) Power window lock switch * : if equipped OIB044048...
  • Page 87 The ignition switch must be in the ON Window opening and closing I I nformation position to be able to raise or lower • In cold and wet climates, power win- the windows. Each door has a Power dows may not work properly due to Window switch to control that door's freezing conditions.
  • Page 88: Power Window Switches

    Power window lock switch NOTICE I I nformation (if equipped) • To prevent possible damage to the The automatic reverse feature is only power window system, do not active when the “auto up” feature is open or close two windows or used by fully pulling up the switch to more at the same time.
  • Page 89 O O pening the hood OIB044050 OIB044052 3. Go to the front of the vehicle, raise 4. Pull out the support rod. OIB044047 the hood slightly, push the second- 5. Hold the hood opened with the 1. Make sure the shift lever is in first ary latch up (1) inside of the hood support rod.
  • Page 90 C C losing the hood WARNING WARNING 1. Before closing the hood, check the following: • • Grasp the support rod in the Before closing the hood, ensure • All filler caps in engine compart- area wrapped in rubber. The that obstructions ment must be correctly installed.
  • Page 91 O O pening the fuel filler door Information If the fuel filler door does not open because ice has formed around it, tap lightly or push on the door to break the ice and release the door. Do not pry on the door.
  • Page 92: Steering Wheel

    Take your vehicle This happens as the system per- Should you notice any change in the to an authorized HYUNDAI dealer forms the EPS system diagnostics. effort required to steer during normal and have the system checked as...
  • Page 93 T T ilt steering / Telescope steering Horn (if equipped) WARNING Never adjust the steering wheel while driving. You may lose steer- ing control and cause severe per- sonal injury, death or accidents. OIB044055 Pull down the lock-release lever (1) on OIB044056 the steering wheel column and adjust To sound the horn, press the area...
  • Page 94 I I nside rearview mirror Day/night rearview mirror WARNING Before you start driving, adjust the rearview mirror to the center on the To prevent serious injury during view through the rear window. an accident or deployment of the air bag, do not modify the rearview WARNING mirror and do not install a wide Night...
  • Page 95 O O utside rearview mirror WARNING Your vehicle is equipped with both left-hand and right-hand outside Do not adjust or fold the outside rearview mirrors. rearview mirrors while the vehicle is moving. This could result in loss of WARNING control, and an accident which could cause death, serious injury or property damage.
  • Page 96 NOTICE T T he electric type outside rearview mirror operates even though the igni- tion switch is in the OFF position. However, to prevent unnecessary battery discharge, do not adjust the mirrors longer than necessary while the engine is not running. NOTICE OIB044062 Do not fold the electric type outside...
  • Page 97 ■ Type A 1. Tachometer 2. Speedometer 3. Fuel gauge 4. Engine coolant temperature gauge 5. Warning and indicator lights 6. Odometer/Trip computer ■ Type B 7. LCD display (including trip computer) ❈ The actual cluster in the vehicle may differ from the illustration.
  • Page 98: Instrument Cluster

    I I nstrument Cluster Control Adjusting Instrument Cluster ■ Type A ■ Type B Illumination (if equipped) WARNING Never adjust the instrument cluster while driving. This could result in loss of control and lead to an acci- dent that may cause death, serious injury, or property damage.
  • Page 99 L L CD display control Gauges Tachometer (if equipped) Speedometer ■ Petrol ■ Diesel OIB044102/OIB044103 OIB044157 OIB044104 tachometer indicates approximate number of engine revo- The LCD display modes can be The speedometer indicates the lutions per minute (rpm). changed by using the control buttons. speed of the vehicle and is calibrated in kilometers per hour (km/h).
  • Page 100 E E ngine Coolant Temperature Fuel Gauge NOTICE Gauge ■ Type A If the gauge pointer moves beyond ■ the normal range area toward the “H” Type A position, it indicates overheating that may damage the engine. Do not continue driving with an over- heated engine.
  • Page 101 Outside Temperature Gauge - User Settings Mode in the Cluster : I I nformation You can change the temperature ■ Type A ■ Type B It is forbidden to alter the odometer of unit in the “Other Features - all vehicles with the intent to change Temperature unit”...
  • Page 102 T T ransaxle Shift Indicator For example : Indicates that shifting up to the Manual Transaxle Shift Indicator 3rd gear is desired (currently (if equipped) the shift lever is in the 2nd or 1st ■ Type A ■ Type B gear).
  • Page 103 I I nformation mode For the setting of the service interval, refer to "User Settings Mode" of the Service Interval LCD display. OIB044166 Service required If you do not have your vehicle serv- OIB044165 iced according to the already inputted Service in service interval, "Service required"...
  • Page 104 Warning Message If one of followings occurs, warning messages will be displayed on the information mode for several seconds. - Low fuel etc. OIB044167 Service in OFF If the service interval is not set, "Service interval OFF" message is displayed on the LCD display. I I nformation If any of the following conditions occurs, the mileage and days may be...
  • Page 105 Start the engine by pressing the light will blink. Engine Start/ Stop button once more. If the warning illuminates each time you press the Engine Start/Stop but- ton, we recommend that you have the vehicle inspected by an author- ized HYUNDAI dealer.
  • Page 106 D D oor Open Tailgate Open Hood Open OIB044144 OIB044145 OIB044146 This indicator displays which door is This indicator displays when the tail- This indicator displays when the open. gate is open. hood is open.
  • Page 107 A A lign steering wheel (if equipped) Low Fuel Engine has overheated OIB044150 OIB044148 OIB044149 This warning message illuminates if This warning message illuminates if This warning message illuminates you start the engine when the steer- the fuel tank is nearly empty. when the engine coolant tempera- ing wheel is turned 90 degrees to the ture is above 120°C (248°F).
  • Page 108 - It illuminates for approximately 6 Belts” in chapter 4. seconds and then goes off. • When there is a malfunction with the SRS. In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.
  • Page 109 - If the warning light illuminates with authorized HYUNDAI dealer and cle as soon as it is safe to do so. the parking brake released, it indi- inspected.
  • Page 110 - at more than 2nd gear with 1500 ~ - It remains on until the engine is authorized HYUNDAI dealer as soon 2000 engine rpm for a certain time started. as possible. (for about 25 minutes).
  • Page 111 In this case, we we recommend that you have the recommend that you have the vehicle inspected by an authorized vehicle inspected by an author- HYUNDAI dealer as soon as possi- ized HYUNDAI dealer. ble.
  • Page 112 • When water has accumulated This warning light illuminates: have the vehicle inspected by an inside the fuel filter. authorized HYUNDAI dealer as When the tailgate is not close In this case, remove the water from soon as possible. securely.
  • Page 113 HYUNDAI dealer. • When there is a malfunction with - At this time, you can not start the the immobilizer system. engine. In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.
  • Page 114 In this case, we recommend that you have the vehicle inspected by Light ON Indicator Light This indicator light illuminates : an authorized HYUNDAI dealer. • When the remaining mileage or - The indicator light does not blink This indicator light illu- time is 0 on the “Service Interval”...
  • Page 115 - The indicator will go off while the system. vehicle is moving. In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer.
  • Page 116 ■ Type A ■ Type B ■ Type A Press the TRIP button for less than 1 To change the trip mode, rotate the MOVE switch “▲, ▼” on the steering second to select any mode as follows: wheel. Tripmeter A TRIP A Tripmeter B •...
  • Page 117 T T rip A/B Average Vehicle Speed (2) Elapsed Time (3) (km or mile, km/h or MPH) • The average vehicle speed is cal- • The elapsed time is the total driv- culated by the total driving dis- ing time since the last elapsed time ■...
  • Page 118 Exterior lights Lighting control OLF044084R OLF044086R Parking light position ( Headlight position ( When the light switch is in the park- When the light switch is in the head OLF044084R ing light position, the parking (posi- light position, the headlights, license To operate the lights, turn the knob at tion) light, license plate light and plate light and instrument panel lights...
  • Page 119: Headlamp

    High beam operation NOTICE • • Do not cover or spill anything on the sensor (1) located on the instrument panel. • Do not clean the sensor using a win- dow cleaner, the cleanser may leave a light film which could inter- fere with sensor operation.
  • Page 120 T T urn signals and lane change sig- One-touch lane change function nals (if equipped) To activate an One-Touch Lane Change function, move the turn sig- nal lever slightly and then release it. The lane change signals will blink 3, 5 or 7 times.
  • Page 121 F F ront fog light (if equipped) Battery saver function NOTICE The purpose of this feature is to pre- When in operation, the fog lights vent the battery from being dis- consume large amounts of vehicle charged. The system automatically electrical power.
  • Page 122 H H eadlamp delay function Headlight leveling device NOTICE (if equipped) (if equipped) If the driver gets out of the vehicle If the key is removed from the ignition through other doors (except driver's switch or placed in the ACC or door), the battery saver function LOCK/OFF position with the head- does not operate and the headlamp...
  • Page 123 F F ront lamps Front Room Lamp: : With the Front Room Lamp in this position, the front and The Front Room Lamp Switch acti- rear room lamps remain on vates the front and rear room lamps at all times. when the switch is pressed in either of the three positions indicated below: : With the Front Room Lamp in...
  • Page 124 R R oom lamp Luggage room lamp (if equipped) OIB044016 OIB044017 The luggage room lamp comes on Rear Door Lamp Switch: when the tailgate is opened. Press this switch to turn the room lamp on and off. NOTICE NOTICE The luggage room lamp comes on as long as the tailgate is open.
  • Page 125 ■ ■ Front Rear • Type A • Type B D : Rear wiper/washer control A : Wiper speed control B : Intermittent wipe time (if equipped) adjustment · MIST – Single wipe · HI – High wiper speed · OFF – Off ·...
  • Page 126 W W indshield wipers Windshield washers If the washer does not work, check (if equipped) the washer fluid level. If the fluid level Operates as follows when the igni- is not sufficient, you will need to add tion switch is in the ON position. appropriate non-abrasive windshield MIST : For a single wiping cycle, washer fluid to the washer reservoir.
  • Page 127 R R ear view camera (if equipped) Whenever the vehicle ignition is WARNING cycled off and on, the rear view cam- era will turn on when the shift lever is • Never rely solely on the Rear put into R (Reverse). View Camera when backing up.
  • Page 128 R R ear parking assist system This is a supplemental system that Operation of the rear parking (if equipped) senses objects within the range and assist system location of the sensors, it cannot Operation condition ■ Type A detect objects in other areas where •...
  • Page 129: Horn,

    • Heavy rain or water spray is present. the system be checked by an • Wireless transmitters or mobile authorized HYUNDAI dealer. phones are present near the sensor. • The sensor is covered with snow. • Any non-factory equipment or...
  • Page 130 D D efroster Rear window defroster activate rear window defroster, press the rear window (if equipped ) defroster button located in the NOTICE ■ Manual Climate Control System Climate system. The indicator on the To prevent damage to the conduc- rear window defroster button illumi- tors bonded to the inside surface of nates when the defroster is ON.
  • Page 131 Manual climate control system (if equipped) (1) Temperature control knob (2) Fan speed control knob (3) Mode selection knob (4) Air intake control button (5) A/C (Air conditioning) button (if equipped) (6) Rear window defroster button (if equipped) OIB044066...
  • Page 132 H H eating and air conditioning 1. Start the engine. 2. Set the mode to the desired posi- tion. To improve the effectiveness of heating and cooling : - Heating: - Cooling: 3. Set the temperature control to the desired position. 4.
  • Page 133 M M ode selection Face-Level (B, D, E) Floor/Defrost-Level (A, C, D) Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each floor and the windshield with a small outlet can be controlled to direct the amount directed to the side window air discharged from the outlet.
  • Page 134 ■ Front T T emperature control Air intake control OIB044094 ■ Rear OIB044068 OIB044070 The temperature will increase by This button is used to select the out- turning the knob to the right. side (fresh) air position or recirculat- ed air position. The temperature will decrease by turning the knob to the left.
  • Page 135 F F an speed control Air conditioning (A/C) System operation (if equipped) Ventilation 1. Select the Face Level mode. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4.
  • Page 136 Operation Tips Air conditioning (if equipped) NOTICE • To keep dust or unpleasant fumes HYUNDAI Air Conditioning Systems W W hen using the air conditioning sys- from entering the car through the are filled with a R-134a refrigerant. tem, monitor the temperature gauge ventilation system, temporarily set 1.
  • Page 137 • If you operate air conditioner S S ystem maintenance Air conditioning system operation tips excessively, the difference between the temperature of the outside air • If the vehicle has been parked in Outside air and that of the windshield could direct sunlight during hot weather, cause the outer surface of the open the windows for a short time...
  • Page 138 Automatic climate control system (if equipped) (1) Fan speed control knob (2) Temperature control knob (3) AUTO (automatic control) button (4) OFF button (5) Mode selection button (6) Air intake control button (7) Rear window defroster button (8) Front windshield defroster button (9) A/C (Air conditioning) button (10) LCD display OIB044078...
  • Page 139 A A utomatic heating and air condi- To turn the automatic operation off, tioning select any button of the following: - Mode selection button The Automatic Climate Control System is controlled by setting the - Front windshield defrost button desired temperature. - Fan speed control button The selected function will be con- trolled manually while other functions...
  • Page 140 Manual heating and air condition- 3. Set the temperature control to the desired position. 4. Set the air intake control to the The heating and cooling system can outside (fresh) air position. be controlled manually by pressing buttons other than the AUTO button. 5.
  • Page 141 Face-Level (B, D, E) Defrost-Level (A, D) Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each windshield. outlet can be controlled to direct the air discharged from the outlet. Also you may select 2~3 modes at the same time for desired air flow.
  • Page 142 ■ Front T T emperature control Air intake control OIB044094 ■ Rear OIB044086 OIB044084 The temperature will increase to the This button is used to select the out- maximum (HI) by turning the knob to side (fresh) air position or recirculat- the right.
  • Page 143 Recirculated air position I I nformation WARNING The indicator light on the Prolonged use of the air conditioning button illuminates when • Continued use of the climate with the recirculated air position the recirculated air posi- control system operation in the selected will result in excessively dry tion is selected.
  • Page 144 S S ystem operation Operation Tips Air conditioning (if equipped) • To keep dust or unpleasant fumes HYUNDAI Air Conditioning Systems Ventilation from entering the car through the are filled with a R-134a refrigerant. 1. Select the Face Level mode.
  • Page 145 • If you operate air conditioner Air conditioning system operation NOTICE tips excessively, the difference between W W hen using the air conditioning sys- the temperature of the outside air • If the vehicle has been parked in tem, monitor the temperature gauge and that of the windshield could direct sunlight during hot weather, closely while driving up hills or in...
  • Page 146 S S ystem maintenance If the air flow rate suddenly decreas- Checking the amount of air es, we recommend the system be conditioner refrigerant and com- checked at an authorized HYUNDAI pressor lubricant Outside air dealer. When the amount of refrigerant is...
  • Page 147 M M anual climate control system Automatic climate control system To defog inside windshield OIB044077 To defrost outside windshield OIB044076 1. Set the fan speed to the highest OIB044089 To defog inside windshield (extreme right) position. 1. Select desired fan speed. 1.
  • Page 148 If the air-conditioning, outside (fresh) T T o defrost outside windshield Clean air (if equipped) air position and higher fan speed are not selected automatically, adjust the corresponding button or knob manu- ally. If the position is selected, lower fan speed is adjusted to higher fan speed.
  • Page 149 Center console storage WARNING WARNING Flammable materials ALWAYS keep the storage com- partment covers closed securely Do not store cigarette lighters, while driving. Items inside your propane cylinders, or other flam- vehicle are moving as fast as the mable/explosive materials in the vehicle.
  • Page 150 G G love box Cool box (if equipped) WARNING Do not put perishable food in the cool box because it may not main- tain the necessary consistent tem- perature to keep the food fresh. Information • If the vent is blocked by items in the coolbox, cooling will be reduced.
  • Page 151 S S unglass holder (if equipped) WARNING • Do not keep objects except sun- glasses inside the sunglass holder. Such objects can be thrown from the holder in the event of a sudden stop or an accident, possibly injuring the passengers in the vehicle.
  • Page 152 Clock (if equipped) Digital clock (if equipped) WARNING Do not adjust the clock while driv- ing. You may lose your steering control and cause severe personal injury or accidents. OIB044039 To set the time: OIB044038 The ignition switch must be in the ACC position or the ON position.
  • Page 153 Sunvisor NOTICE WARNING ■ • • Keep your drinks sealed while driv- Driver’s side For your safety, do not block your ing to prevent spilling your drink. If view when using the sunvisor. liquid spills, it may get into the vehicle's electrical/electronic sys- tem and damage electrical/elec- tronic parts.
  • Page 154: Power Outlet

    P P ower outlet (if equipped) (Continued) NOTICE • Push the plug in as far as it will go. To prevent damage to the Power If good contact is not made, the outlet: plug may overheat or the internal • Use the power outlet only when the temperature fuse may open.
  • Page 155 C C lothes hanger (if equipped) Shopping bag holder Floor mat anchor(s) (if equipped) (if equipped) OIB044031 OFS040126 OIB044032 These hangers are not designed to hold large or heavy items. ALWAYS use the Floor Mat Anchors NOTICE to attach the front floor mats to the vehicle.
  • Page 156 To avoid any interference with pedal operation, HYUNDAI recommends that the HYUNDAI floor mat designed for use in your vehicle be installed.
  • Page 157 R R oof rack (if equipped) NOTICE (Continued) • • When carrying cargo on the roof The vehicle centre of gravity will rack, take the necessary precau- be higher when items are loaded tions to make sure the cargo does onto the roof rack.
  • Page 159: Aux, Usb And Ipod ® Port

    ® AUX, USB and iPod port NOTICE Information • • If you install an aftermarket HID When using a portable audio device head lamp, your vehicle’s audio connected to the power outlet, noise and electronic device may mal- may occur during playback. If this function.
  • Page 160: Antenna

    HYUNDAI dealer. OIB045191 Your car uses a roof antenna to receive both AM and FM broadcast signals. This antenna is a removable...
  • Page 161: Steering Wheel Audio Controls*

    S S teering wheel audio control RADIO mode NOTICE (if equipped) It will function as the PRESET STA- Do not operate audio remote control TION select buttons. n Type A buttons simultaneously. CDP mode VOLUME (VOL +/-) (1) It will function as the TRACK •...
  • Page 162 H H ow vehicle audio works This can be due to factors, such as AM reception the distance from the radio station, FM reception closeness of other strong radio sta- tions or the presence of buildings, bridges or other large obstructions in the area.
  • Page 163 FM radio station JBM003 JBM004 JBM005 FM broadcasts are transmitted at • Fading - As your vehicle moves • Station Swapping - As an FM signal high frequencies and do not bend to away from the radio station, the weakens, another more powerful follow the earth's surface.
  • Page 164 • • Support for Compressed Files • For MP3/WMA compression files, • Language Support differences in sound quality will (Unicode Support) 1. Supported Bitrates (Kbps) occur depending on the bitrate. 1. English: 94 characters (Higher sound quality can be expe- MPEG1 MPEG2 MPEG2.5 2.
  • Page 165 • • Compatibility by Disc Type • Precautions upon Writing CDs 5. Prolonged use of CD-R/CD-RW discs that do not satisfy related 1. Playing MIXED CDs: First plays 1. In all cases except when creating standards and/or specifications the audio CD, then plays the com- multisession discs, check the could result in product malfunc- pressed file(s).
  • Page 166 (Continued) N N OTICE WARNING • Do not place beverages close to O O perating the device while driving the audio system. Spilling bever- • Do not stare at the screen while could lead to accidents due to a lack ages may lead to system malfunc- driving.
  • Page 167 (Continued) (Continued) I I nformation • Clean fingerprints and dust off the • Do not use abnormally shaped discs Using the discs (8cm, heart-shaped, octagon- disc surface (coated side) with a soft • This device has been manufactured cloth. shaped) as such discs could lead to to be compatible with software malfunctions.
  • Page 168 (Continued) (Continued) I I nformation • Only products formatted with • The amount of time required to rec- Using the USB device ognize the USB device may differ byte/sectors under 64Kbyte will be • Connect the USB device after turn- recognized.
  • Page 169 (Continued) (Continued) I I nformation • When the EQ features of an exter- • If your iPhone ® is connected to both ® Using the iPod device the Bluetooth ® ® nal device, such as the iPod , and Wireless Technology ®...
  • Page 170 (Continued) I I nformation Information • Some iPod ® s may not sync with the ® Using the AUX device Before using the Bluetooth System depending on its version. If handsfree • If an external device connector is the Media is removed before the What is Bluetooth ®...
  • Page 171 (Continued) I I nformation Information • Park the vehicle when connecting Precautions for safe driving When connecting a the head unit with the mobile phone. ® Bluetooth phone • Bluetooth ® Handsfree is a feature • Bluetooth ® connection may become that enables drivers to practice safe •...
  • Page 172 h Display and settings may differ depending on the Name Description selected audio. • CD, USB, My Music mode - Shortly press the key (under 0.8 seconds): Audio Head Unit Previews each song (file) for 10 seconds each. SCAN h Press the SCAN key again to continue listen- ing to the current song (file).
  • Page 173 Name Description • Each time the key is pressed, the mode is changed in order of CD, USB, iPod ® , AUX, My Music modes. h In Setup>Display, the media pop up screen will be displayed when [Mode Pop up] is turned MEDIA When the pop up screen is displayed, use the TUNE knob or keys...
  • Page 174 Name Description A A udio Head Unit • USB, My Music mode - Shortly press the key (under 0.8 seconds): Previews each song (file) for 10 seconds each. SCAN h Press the SCAN key again to continue listen- ing to the current song (file). •...
  • Page 175 Name Description • Each time the key is pressed, the mode is changed in order of USB, iPod ® , AUX, My Music modes. h In Setup>Display, the media pop up screen will be displayed when [Mode Pop up] is turned MEDIA When the pop up screen is displayed, use the TUNE knob or keys...
  • Page 176 A A udio Settings Speed Dependent Volume Clock Settings This menu allows you to set the Control ‘Bass, Middle, Treble’ and the Sound SETUP This feature is used to automatically Press the key Select [Clock] CLOCK Fader and Balance. control the volume level according to through TUNE knob or Select [Audio Settings] Select menu...
  • Page 177 C C lock Settings Calendar Settings Clock Display when Power is This menu is used to set the time. This menu is used to set the date Select [Clock Disp.(Pwr Off)] Set Select [Clock Settings] Set through (MM/DD/YYYY). through TUNE knob TUNE knob Press TUNE knob Select...
  • Page 178 ˘ Connect the selected mobile P P hone List • Changing connection sequence phone. (Priority) The names of up to 5 paired phones ˜ Connection completion is dis- This is used to change the order (pri- will be displayed. played. ority) of automatic connection for the A [ ] is displayed in front of the cur- paired mobile phones.
  • Page 179 - The connected phone will automat- Contacts Download Audio Streaming ically be changed to No. 1 priority. This feature is used to download Songs (files) saved your contacts and call histories into the Bluetooth Wireless Technology ® Delete audio system. enabled mobile phone can be played •...
  • Page 180 S S ystem Settings Memory Information Displays currently used memory and total system memory. SETUP Press key Select CLOCK Select [Memory Information] OK [System] through tune knob or The currently used memory is dis- played on the left side while the total system memory is displayed on the right side.
  • Page 181 Preset SEEK Selecting through manual search Turn the TUNE knob left/right to Press the adjust the frequency. • Shortly pressing the key : Plays the • FM : Changes by 200KHz frequency saved in the correspon- ding key. • AM : Changes by 10KHz •...
  • Page 182 Repeat MENU : MP3 CD / USB In MP3 CD / USB mode, press Set [ RPT] through the TUNE key. knob or key to repeat the cur- MENU MENU : Audio CD rent song. In CD mode, press key. MENU h Press RPT again to turn off.
  • Page 183 I I nformation MENU : My Music Mode Information Set [ Info] through the TUNE In My Music mode, press key. MENU Set [ Info] through the TUNE knob knob or key. key. Displays information of the current Displays information of the current song.
  • Page 184 D D elete All Delete Selection AUX is used to play external MEDIA Set [ Del.All] through the TUNE Press the key Set [ Del.Sel] MENU currently connected with the AUX knob or key. through the TUNE knob or key. terminal.
  • Page 185 h The actual feature in the vehicle may differ from the illustration. Name Description ¤ VOLUME Raises or lowers speaker volume. button ˘ Mute the microphone during a call. MUTE button ˜ button Places and transfers calls. ‹ button Raises or lowers speaker volume.
  • Page 186 Contacts Phone Setup Press key Set Press the key Set [ Setup] PHONE PHONE Contacts] through the TUNE knob or through the TUNE knob or Press the key to display three PHONE key. key. menus (Call History, Contacts, ® The Contacts are displayed and can The Bluetooth Wireless Technology Phone Setup).
  • Page 187 Name Description Phone does not support Phone does not support Phone Phone book download book download No connected There are phone in the connec- Bluetooth device tion list Phone does not support But it was actually not connected Bluetooth audio BT pairing Downloading stopped Downloading stopped...
  • Page 189 HYUNDAI dealer.
  • Page 190 B B efore entering the vehicle Before starting • Check the gauges and indicators in the instrument panel and the mes- • Be sure all windows, outside mir- • Make sure the hood, the tailgate, sages on the instrument display ror(s), and outside lights are clean and the doors are securely closed when the ignition switch is in the...
  • Page 191 WARNING WARNING (Continued) You are much more likely to have a To reduce the risk of SERIOUS NEVER drink or take drugs and serious accident if you drink or take INJURY or DEATH, take the fol- drive. drugs and drive. If you are drinking lowing precautions: or taking drugs, don’t drive.
  • Page 192 K K ey ignition switch WARNING (Continued) (if equipped) This may lead to loss of direc- To reduce the risk of SERIOUS tional control and braking func- INJURY or DEATH, take the fol- tion, which could cause an acci- lowing precautions: dent.
  • Page 193 K K ey ignition switch positions Switch Action Notice Position The ignition key can be removed in the LOCK position. The steering wheel locks to protect the vehi- LOCK cle from theft. (if equipped) Electrical accessories are usable. The steering wheel unlocks. If difficulty is experienced turning the ignition switch to the ACC position, turn the key while turning the steering wheel right and...
  • Page 194 S S tarting the engine Starting the petrol engine Information Vehicle with manual transaxle: • Do not wait for the engine to warm WARNING 1. Make sure the parking brake is up while the vehicle remains station- applied. ary. • Always wear appropriate shoes 2.
  • Page 195 Starting the diesel engine Starting and stopping the engine I I nformation for turbocharger intercooler To start the diesel engine when the If the engine does not start within 10 engine is cold, it has to be pre-heat- 1.Do not race or accelerate the seconds after preheating is completed, ed before starting the engine and engine immediately after starting...
  • Page 196 Engine Start/Stop button N N OTICE WARNING (if equipped) T T o prevent damage to the vehicle: To reduce risk of serious injury or • Do not hold the ignition key in the death, NEVER allow children or START position for more than 10 any person who is unfamiliar with seconds.
  • Page 197: Clutch Pedal

    Engine Stop/Start button positions - Vehicle with manual transaxle B B utton Position Action Notice • To turn off the engine, stop the vehicle and If the steering wheel is not locked properly then press the Engine Start/Stop button. when you open the driver's door, the warning chime will sound.
  • Page 198 - Vehicle with manual transaxle B B utton Position Action Notice • Press the Engine Start/Stop button while it Do not leave the Engine Start/Stop button in is in the ACC position without depressing the ON position when the engine is not run- the clutch pedal.
  • Page 199 E E ngine Stop/Start button positions - Vehicle with automatic transaxle Button Position Action Notice To turn off the engine, press the Engine If the steering wheel is not locked properly Start/Stop button with shift lever in P (Park). when you open the driver's door, the warning chime will sound.
  • Page 200: Brake Pedal

    - - Vehicle with automatic transaxle Button Position Action Notice Press the Engine Start/Stop button while it Do not leave the Engine Start/Stop button in is in the ACC position without depressing the ON position when the engine is not run- the brake pedal.
  • Page 201: Manual Transaxle

    S S tarting the engine Starting the petrol engine Information Vehicle with manual transaxle: • The engine will start by pressing the WARNING 1. Always carry the smart key with Engine Start/Stop button, only when you. the smart key is in the vehicle. •...
  • Page 202 Starting the diesel engine I I nformation Information To start the diesel engine when the • Do not wait for the engine to warm If the Engine Start/Stop button is engine is cold, it has to be pre-heat- up while the vehicle remains station- pressed while the engine is pre-heat- ed before starting the engine and ary.
  • Page 203 Starting and stopping the engine NOTICE NOTICE for turbocharger intercooler To prevent damage to the vehicle: To prevent damage to the vehicle: 1.Do not race or accelerate the • If traffic and road conditions per- When the stop lamp fuse is blown, engine immediately after starting mit, you may put the shift lever in you can't start the engine normally.
  • Page 204 OIB054007 I I nformation If the smart key battery is weak or the smart key does not work correctly, you can start the engine by pressing the Engine Start/Stop button with the smart key in the direction of the pic- ture above.
  • Page 205 n Type A M M anual transaxle operation To shift to R (Reverse), make sure the vehicle has completely stopped, The manual transaxle has 5 (or 6) and then move the shift lever to neu- forward gears. The transaxle is fully tral before moving into R (Reverse).
  • Page 206 Good driving practices • Exercise extreme caution when NOTICE driving on a slippery surface. Be • Never take the vehicle out of gear T T o prevent damage to the engine, especially careful when braking, and coast down a hill. This is clutch and transaxle: accelerating or shifting gears.
  • Page 207 To reduce the risk of SERIOUS el lanes. INJURY or DEATH: • HYUNDAI recommends you fol- • ALWAYS wear your seatbelt. In low all posted speed limits. a collision, an unbelted occu- pant is significantly more likely to be seriously injured or killed than a properly belted occupant.
  • Page 208 A A utomatic transaxle operation The automatic transaxle has 4 for- ward speeds and one reverse speed. The individual speeds are selected automatically in the D (Drive) posi- tion. Depress the brake pedal, press the shift button, and then move shift lever. Press the shift button, then move shift lever.
  • Page 209 The indicator in the instrument clus- WARNING WARNING ter displays the shift lever position when the ignition switch is in the ON To reduce the risk of serious injury • Shifting into P (Park) while the position. or death: vehicle is in motion may cause you to lose control of the vehi- •...
  • Page 210 R R (Reverse) N (Neutral) D (Drive) Use this position to drive the vehicle The wheels and transaxle are not This is the normal driving position. backward. engaged. The transaxle will automatically shift through a 4-gear sequence, provid- Use N (Neutral) if you need to restart ing the best fuel economy and NOTICE a stalled engine, or if it is necessary...
  • Page 211 S S ports mode + (Up) : Push the lever forward once (Continued) to shift up one gear. • If the driver presses the lever to - (Down) : Pull the lever backwards + (Up) or - (Down) position, the once to shift down one transaxle may not make the request- gear.
  • Page 212 OIB054003 3.Move the shift lever. 1. Press the shift-lock release but- ton. 2. Press and hold the lock release button on the shift lever. 3. Move the shift lever. 4. Have your vehicle inspected by an authorized HYUNDAI dealer immediately...
  • Page 213 P P ower brakes WARNING • Wet brakes may impair the vehi- Your vehicle has power-assisted cle’s ability to safely slow down; brakes that adjust automatically the vehicle may also pull to one Take the following precautions: through normal usage. side when the brakes are •...
  • Page 214 D D isc brakes wear indicator Rear drum brakes Parking brake (if equipped) When your brake pads are worn and new pads are required, you will hear Your rear drum brakes do not have a high pitched warning sound from wear indicators.Therefore, have the your front or rear brakes.
  • Page 215 HYUNDAI • Only release the parking brake dealer. when you are seated inside the vehicle with your foot firmly on the brake pedal.
  • Page 216 Check Parking If the Parking Brake Warning Light A A nti-lock Brake System (ABS) (if Brake Warning Light by remains on after the parking brake is equipped) placing ignition released while engine is running, switch to the ON posi- there may be a malfunction in the WARNING tion (do not start the brake system.
  • Page 217 Restart the engine. If the ABS warning light is off, then your ABS system is normal. Otherwise, you may have a problem with your ABS system. We recommend that contact authorized HYUNDAI dealer as soon as pos- sible.
  • Page 218 Hazardous driving conditions Rocking the vehicle NOTICE When hazardous driving conditions If it is necessary to rock the vehicle If the tires spin at high speed the are encountered such as water, to free it from snow, sand, or mud, tires can explode, and you or others snow, ice, mud or sand: first turn the steering wheel right and...
  • Page 219 S S mooth cornering Driving at night Driving in the rain Avoid braking or gear changing in Night driving presents more hazards Rain and wet roads can make driving corners, especially when roads are than driving in the daylight. Here are dangerous.
  • Page 220 S S now or icy conditions Snow tires Information You need to keep sufficient distance Do not install studded tires without WARNING between your vehicle and the vehicle first checking local and municipal reg- in front of you. ulations for possible restrictions Snow tires should be equivalent in Apply the brakes gently.
  • Page 221 HYUNDAI parts and install the prevent side skids. tire chain after reviewing the instruc- tions provided with the tire chains.
  • Page 222 • Use SAE “S” class or wire chains. should use, we recommend that you it helps prevent corrosion in the cool- consult with an authorized HYUNDAI • If you hear noise caused by chains ing system, lubricates the water dealer.
  • Page 223 GAW (Gross Axle Weight) Overloading Two labels on your driver’s door sill show how much weight your vehicle This is the total weight placed on was designed to carry: the Tire and WARNING each axle (front and rear) - including Loading Information Label and the vehicle curb weight and all payload.
  • Page 225 All turn signal lights will flash simul- taneously. • The hazard warning flasher oper- ates whether your vehicle is run- ning or not. • The turn signals do not work when the hazard flasher is on. OIB064001 The hazard warning flasher serves as a warning to other drivers to exer- cise extreme...
  • Page 226 HYUNDAI dealer. control resulting in an accident. When the vehicle has slowed to If the engine stalls at a cross-...
  • Page 227 HYUNDAI dealer for assistance. Do not push or pull the vehicle to start it. This could cause damage to your vehicle.
  • Page 228 Jump starting can be dangerous if WARNING (Continued) done incorrectly. Follow the jump Batteries contain sulfuric starting procedure in this section to To prevent SERIOUS INJURY or acid which is highly corro- avoid serious injury or damage to DEATH to you or bystanders, sive.
  • Page 229 Jump starting procedure NOTICE (Continued) 1.Position the vehicles close enough • NEVER attempt to recharge the T T o prevent damage to your vehicle: that the jumper cables will reach, battery when the vehicle’s bat- • Only use a 12-volt power supply but do not allow the vehicles to tery cables are connected to the (battery or jumper system) to jump...
  • Page 230 (+) battery/jumper terminal of the your battery discharging is not assisting vehicle (2). apparent, we recommend that your vehicle be checked by an authorized 6.Connect the second jumper cable HYUNDAI dealer. black, negative battery/chassis ground of the assisting vehicle (3).
  • Page 231 If we recommend that you call an towel, and continue turning coun- the fan is not running, turn the authorized HYUNDAI dealer for terclockwise to remove it. assistance. engine off.
  • Page 232 If overheating happens again, cracks in the engine. To prevent we recommend that you call an damage, add engine coolant slow- authorized HYUNDAI dealer for ly in small quantities. assistance.
  • Page 233 J J ack and tools Removing and storing the spare WARNING tire Changing a tire can be dangerous. Follow the instructions in this sec- tion when changing a tire to reduce the risk of serious injury or death. OIB064016 OIB064019 ➀...
  • Page 234 C C hanging tires Follow these steps to change your (Continued) vehicle’s tire: • ALWAYS place the jack on the WARNING 1.Park on a level, firm surface. designated jacking positions on 2.Move the shift lever into neutral the vehicle and NEVER on the A vehicle can slip or roll off of a position, apply the parking brake, bumpers or any other part of the...
  • Page 235 OIB064005 OIB064006 OIB064007 6.Loosen the wheel lug nuts counter- 7.Place the jack at the designated 8.Insert the jack handle into the jack clockwise one turn each in the jacking position under the frame and turn it clockwise, raising the order shown above, but do not closest to the tire you are chang- vehicle until the tire clears the remove any lug nuts until the tire...
  • Page 236: Tires And Wheels

    Information that an authorized HYUNDAI dealer tighten the lug nuts to their Check the tire pressure as soon as pos- proper torque as soon as possi- sible after installing a spare tire.
  • Page 237 OIB064010 OIB064012 If emergency towing is necessary, we recommend having it done by an NOTICE authorized HYUNDAI dealer or a • Do not tow the vehicle with the commercial tow-truck service. front wheels on the ground as this Proper lifting and towing procedures may cause damage to the vehicle.
  • Page 238 When towing your vehicle in an Removable towing hook 2.Remove the hole cover pressing emergency without wheel dollies: the lower part of the cover on the ■ Type A front bumper. 1.Place the ignition switch in the ACC position. 3.Install the towing hook by turning it clockwise into the hole until it is 2.Place the shift lever in N (Neutral).
  • Page 239 If towing is necessary, we recom- • Do not jerk the hook. Apply steady steering and brakes must all be in mend you have it done by an author- and even force. good condition. ized HYUNDAI dealer or a commer- cial tow truck service.
  • Page 240 NOTICE T T o avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull a vehicle out of mud, sand or other conditions from which the vehicle cannot be driven out under its own...
  • Page 243 n Petrol engine 1. Engine oil filler cap 2. Engine oil dipstick 3. Brake/clutch fluid reservoir 4. Positive battery terminal 5. Negative battery terminal 6. Engine room junction block 7. Air cleaner 8. Radiator cap 9. Engine coolant reservoir 10. Windshield washer fluid reservoir h The actual engine room in the vehicle may differ from the illustration.
  • Page 244 n n Diesel engine 1. Engine oil filler cap 2. Brake/clutch fluid reservoir 3. Positive battery terminal 4. Negative battery terminal 5. Engine room junction block 6. Air cleaner 7. Radiator cap 8. Engine coolant reservoir 9. Engine oil dipstick 10.
  • Page 245 Improper owner maintenance during al injury. authorized HYUNDAI dealer. the warranty period may affect war- ranty coverage. For details, read the You should retain documents that separate Service Passport provided show proper maintenance has been with the vehicle.
  • Page 246 If you lack ing before getting near the contact an authorized HYUNDAI sufficient knowledge and experi- engine or cooling fans. dealer. ence or the proper tools and equipment to do the work, we •...
  • Page 247 (Continued) Engine compartment precautions WARNING (Diesel engine) • When you remove the interior trim cover with a flat head (-) driver, be • The injector operates at high volt- Diesel Engine careful not to damage the cover. age (maximum 200v). Therefore, Never work on injection system •...
  • Page 248 • If any slipping or changes in the that you contact an authorized operation of your transaxle occurs, HYUNDAI dealer. check the transaxle fluid level. WARNING • Check the parking brake. • Check for fluid leaks under your...
  • Page 249 A A t least monthly: At least twice a year At least once a year: (i.e., every Spring and Fall): • Check the coolant level in the • Clean the body and door drain engine coolant reservoir. • Check the radiator, heater and air holes.
  • Page 250 Additives are available from your authorised HYUNDAI dealer along with : The engine oil level should be checked regularly and main- information on how to use them. Do not mix other additives.
  • Page 251 NORMAL MAINTENANCE SCHEDULE - PETROL ENGINE (CONT.) MAINTENANCE N N umber of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE ITEM Years ENGINE BAY Engine oil & filter* Drive belts Air cleaner filter Battery condition & specific gravity Throttle body Clean every 10,000 km or 12 months.
  • Page 252 NORMAL MAINTENANCE SCHEDULE - PETROL ENGINE (CONT.) MAINTENANCE N N umber of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE ITEM Years VEHICLE ON FLOOR Wiper (wiper blade , washer fluid) Brake/Clutch (Pedal free play/Pipes/Hoses/Connectors) Fuel filler cap Climate control air filter Check AC system (refrigerant/Compressor) Cooling system (water pump,hoses) &...
  • Page 253 NORMAL MAINTENANCE SCHEDULE - PETROL ENGINE (CONT.) MAINTENANCE N N umber of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE Years ITEM Fuel lines, hoses and connections Driveshafts & boots Fluid leakages Front and rear wheel bearings & bushes Inspect if required Front and rear disc/drum brakes &...
  • Page 254 NORMAL MAINTENANCE SCHEDULE - PETROL ENGINE (CONT.) MAINTENANCE N N umber of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE Years ITEM Power window / Sunroof operation (if equipped) All seat belt operation Road test Inspect if required I : Inspect and if necessary adjust, top-up, clean or replace A : Add L : Lubricate...
  • Page 255 M M AINTENANCE UNDER SEVERE USAGE CONDITIONS - PETROL ENGINE The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. I : Inspect and if necessary, adjust, correct, clean or replace R : Replace or change Maintenance Maintenance item...
  • Page 256 Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Front suspension ball joints C, D, E, F, G depending on the condition Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Drum brakes and linlings (if equipped) C, D, E, G, H...
  • Page 257 Additives are available from your authorised HYUNDAI dealer along with : The engine oil level should be checked regularly and main- information on how to use them. Do not mix other additives tained properly.
  • Page 258 N N ORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE Years ITEM ENGINE BAY Engine oil & filter * Drive belts Air cleaner filter Battery condition & specific gravity Valve clearance * Inspect if required (if applicable)
  • Page 259 N N ORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE (CONT.) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE ITEM Years VEHICLE ON FLOOR Wiper (wiper blade , washer fluid) Brake/Clutch (pedal free play/pipes/hoses/connectors) Fuel filler cap Climate control air filter Check AC system (refrigerant/compressor) Cooling system (water pump,hoses) &...
  • Page 260 N N ORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE (CONT.) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE Years ITEM Fuel lines, hoses and connections Driveshafts & boots Fluid leakages Front and rear wheel bearings & bushes Inspect if required Front and rear disc/drum brakes &...
  • Page 261 NORMAL MAINTENANCE SCHEDULE - DIESEL ENGINE (CONT.) MAINTENANCE N N umber of months or driving distance, whichever comes first INTERVALS Kms×1,000 Months MAINTENANCE Years ITEM Power window / Sunroof operation (if equipped) All seat belt operation Road test Inspect if required I : Inspect and if necessary adjust, top-up, clean or replace A:Add L : Lubricate...
  • Page 262 M M AINTENANCE UNDER SEVERE USAGE CONDITIONS - DIESEL ENGINE The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance intervals MAINTENANCE ITEM...
  • Page 263 Maintenance Maintenance intervals MAINTENANCE ITEM Driving condition operation Inspect more frequently Front suspension ball joints C, D, E, F, G depending on the condition Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake C, D, G, H...
  • Page 264 If an excessive amount of lines, fuel hoses and connections be are required. foreign matter accumulates in the replaced by an authoized HYUNDAI fuel tank, the filter may require dealer. replacement more frequently. Drive belts...
  • Page 265 C C ooling system Brake hoses and lines Parking brake Check cooling system components, Visually check for proper installation, Inspect the parking brake system such as radiator, coolant reservoir, chafing, cracks, deterioration and including the parking brake pedal hoses and connections for leakage any leakage.
  • Page 266 S S uspension mounting bolts Drive shafts and boots Check the suspension connections Check the drive shafts, boots and for looseness or damage. Retighten clamps for cracks, deterioration, or to the specified torque. damage. Replace any damaged parts and, if necessary, repack the Steering gear box,...
  • Page 267 Checking the engine oil level 3.Turn the engine off and wait for a n Petrol engine few minutes (about 5 minutes) for n Petrol engine the oil to return to the oil pan. 4.Pull the dipstick out, wipe it clean, and reinsert it fully.
  • Page 268 Replace tires that are worn, show uneven wear, or are dam- aged. • Remember to check the pres- sure your spare tire. HYUNDAI recommends that you check the spare every time you check the pressure of the other tires on your vehicle.
  • Page 269 Refer to “Tire and wheels” in chapter • Remember to check the pres- sure your spare tire. HYUNDAI recommends that you check the spare every time you check the pressure of the other tires on your vehicle. CBGQ0707A...
  • Page 270 Disc brake pads should be inspected Wheel alignment and tire bal- Tire replacement for wear whenever tires are rotated. ance The wheels on your vehicle were Tread wear indicator I I nformation aligned and balanced carefully at the factory to give you the longest tire life Rotate radial tires that have an asym- and best overall performance.
  • Page 271 • Replace tires that are worn, mend that you contact an authorized HYUNDAI's specifications may show uneven wear, or are dam- HYUNDAI dealer. fit poorly and result in damage to aged. Worn tires can cause loss the vehicle or unusual handling of braking effectiveness, steer- and poor vehicle control.
  • Page 272 W W heel replacement Tire traction Tire sidewall labeling When replacing the metal wheels for Tire traction can be reduced if you any reason, make sure the new drive on worn tires, tires that are wheels are equivalent to the original improperly inflated or on slippery factory units in diameter, rim width road surfaces.
  • Page 273 2 2 . Tire size designation 94 - Load Index, a numerical code Tire speed ratings associated with the maximum A tire’s sidewall is marked with a tire The chart below lists many of the dif- load the tire can carry. size designation.
  • Page 274 3 3 . Checking tire life (TIN : Tire 4. Tire ply composition and materi- WARNING Identification Number) Any tires that are over 6 years old, The number of layers or plies of rub- Tire age based on the manufacturing date, ber-coated fabric in the tire.
  • Page 275 L L ow aspect ratio tire Temperature -A, B & C WARNING (if equipped) The temperature grades are A (the highest), B, and C, representing the Low aspect ratio tires, whose aspect Tire temperature tire’s resistance to the generation of ratio is lower than 50, are provided The temperature grade for this tire heat and its ability to dissipate heat...
  • Page 276 - If the tire is impacted, we recom- mend that you inspect the tire con- dition or contact an authorized HYUNDAI dealer. - To prevent damage to the tire, inspect the tire condition and pres- sure every 3,000km.
  • Page 277 HYUNDAI dealer. Information Three kinds of fuses are used: blade type for lower amperage rating, car- The actual fuse/relay panel label may tridge type and multi fuse for higher differ from equipped items.
  • Page 278 If it fits loosely, we recommend that charge if your vehicle is parked with- you consult an authorized HYUNDAI out being operated for prolonged dealer. periods. Use the following proce- dures before parking the vehicle for If you do not have a spare, use a prolonged periods.
  • Page 279 If the main fuse is blown, we rec- ommend that you consult an OIB074031 authorized HYUNDAI dealer. OIB074032 If the main fuse is blown, it must be removed as follows: 1. Disconnect the negative battery cable.
  • Page 280 F F use/relay panel description Inner fuse panel OIB074033 Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing.
  • Page 281 F F use Name Symbol Fuse rating Circuit Protected SAFETY P/WDW Driver Safety Power Window Module P/WDW LH Power Window Main Switch, Passenger Power Window Switch HTD MIRR ECM, A/C Control Module FOG LP FRT Front Fog Lamp Relay RR HTD RR HTD Relay P/WDW RH Driver Power Window Switch...
  • Page 282 F F use Name Symbol Fuse rating Circuit Protected PDM1 Smart Key Control Module PDM2 Smart Key Control Module, Start/Stop Button Switch Rear Parking Assist Sensor Buzzer, Rear Parking Assist Sensor LH/RH, Rear Parking MODULE2 Assist Sensor LH/RH (Center) M/T : Vehicle Speed Sensor, I/P Junction Block (F26) TAIL LP RH Rear Combination Lamp (In/Out) RH, Head Lamp RH, ILL.
  • Page 283 E E ngine compartment fuse panel TYPE-A (Petrol) OIB074031 OIB074043A...
  • Page 284 TYPE-B (Diesel) OIB074043B...
  • Page 285 F F use Name Symbol Fuse rating Circuit Protected MDPS MDPS Unit [125A] Alternator Fuse - F8/ F9 / F10 / F11, Alternator Fuse : Gasoline - 125A, Diesel - 150A (150A) G4LA, ECU 4 ECM/PCM I/P Junction Block (Power Connector (Fuse - F45, F46), Fuse - F5, F9, F34) W/O Button Start : Ignition Switch With Button Start : PDM Relay Box (IG1 / ACC Relay) I/P Junction Block (Fuse - F11, F20, F23, F24)
  • Page 286 PCB Block (1.2 Petrol engine) F F use Name Symbol Fuse rating Circuit Protected ECU 1 PCB Block (Engine Control Relay) HORN Horn Relay, B/Alarm Horn Relay F/PUMP F/Pump Relay WIPER FRT Wiper Lo Relay H/LAMP LO H/Lamp Lo Relay H/LAMP HI [20A] (10A) H/Lamp Hi Relay...
  • Page 287 PCB Block (1.4 Diesel engine) F F use Name Symbol Fuse rating Circuit Protected ECU 1 PCB Block (Engine Control Relay) HORN Horn Relay, B/Alarm Horn Relay WIPER FRT Wiper Lo Relay H/LAMP LO H/Lamp Lo Relay H/LAMP HI [20A] (10A) H/Lamp Hi Relay C/FAN C/Fan Lo Relay, C/Fan Hi Relay...
  • Page 288 F F use Name Symbol Fuse rating Circuit Protected ECU 4 E/R Junction Block (RLY. 1), Electrical EGR Control Valve, WGT Control Solenoid Valve, Cam ECU 2 Shaft Position Sensor, Immobilizer Module ECU 5 Fuel Pressure Regulator Valve...
  • Page 289 Be aware the bulbs may be hot checked by an authorized HYUNDAI and may burn your fingers. dealer. Be sure to replace the burned-out bulb with one of the same wattage rating.
  • Page 290 H H eadlight, position light, turn sig- n Type B nal light, and front fog light bulb replacement n Type A OIB074060 OLMB073042L (1) Headlight(Low/High BI_Function) WARNING (2) Static Bending Light (SBL) (3) Front turn signal light OIB074034 Halogen bulbs (4) Front fog light (if equipped) (1) Headlight (Low/High) •...
  • Page 291 So, the moving sound may be OIB075061 is reinstalled, consult an authorized heard when the headlamp switches HYUNDAI dealer. the low beam to high or the high beam 1. Open the hood. to low and it does not indicate mal- 2.
  • Page 292 T T urn signal light Static bending light 8. Connect the headlight bulb socket connector. 1. Remove the turn signal light bulb 9. Install the headlight bulb cover by cover by turning it counterclock- turning it clockwise. wise. 2. Remove the socket from the 10.
  • Page 293 3. Disconnect the power connector by an authorized HYUNDAI dealer. 5. Install the new bulb-socket into the from the socket. housing by aligning the tabs on the socket with the slots in the housing.
  • Page 294 If the light does not operate, we rec- 1. Using a flat-blade screwdriver, ommend that the vehicle be checked remove the light assembly from by an authorized HYUNDAI dealer. the body of the vehicle by prying the housing and pulling the assembly out.
  • Page 295 Module (ECM); when the engine car inspected and maintained by an coolant temperature is low during authorized HYUNDAI dealer in idling, the PCSV closes so that evap- accordance with the maintenance orated fuel is not taken into the schedule in this manual.
  • Page 296 3 3 . Exhaust emission control Engine exhaust gas precautions • Do not operate the engine in con- system (carbon monoxide) fined or closed areas (such as garages) any more than what is • Carbon monoxide can be present Exhaust Emission Control necessary to move the vehicle in or...
  • Page 297 All inspections and bottom of the vehicle or do not adjustments must be made by an coat the vehicle for corrosion authorized HYUNDAI dealer. control. It may present a fire risk under certain conditions.
  • Page 299 Item 5 Door Cross Light Bulb Wattage (W) Overall length 3,985 (156.9) 3,995 (157.3) Type A 60/55 Headlights (High/Low) Overall width 1,734 (68.3) 1,760 (69.3) Type B 1,525 (60) Front turn signal Overall height 1,505 (59.2) (1,555 (61.2))* Type A 1,519 (59.8)* 1,504 (59.2)* Position lights...
  • Page 300 tIrES aND whEElS Inflation pressure (psi) Wheel lug nut Item Tire size Wheel size torque Normal load * Maximum load kg•m (lb•ft, N•m) Front Rear Front Rear 185/70R14 5.5J x 14 230 (33) 215(31) 230(33) 230(33) 9~11 Full size tire 185/65R15 5.5J x 15 230 (33)
  • Page 301 : We recommend that you use the engine oils approved by HYUNDAI Motor India Ltd. We recommend that you consult an autho- rized HYUNDAI dealer for details.
  • Page 302 R R ECOMMENDED FREQUENCY FOR VALUE ADDED SERVICES The Value Added Services (VAS) are not part of the Maintenance Schedule mentioned in section 9 and are not mandatory for maintaining the validity of the Basic Warranty of the vehicle. Owner may choose to avail these services to further enhance the per- formance of the vehicle.
  • Page 303 ■ Petrol engine OIB084001 ■ Diesel Engine OHC081001 A compressor label informs you the type of compressor your vehicle is equipped with such as model, suppli- er part number, production number, refrigerant (1) and refrigerant oil (2). OIB084002 The engine number is stamped on the engine block as shown in the drawing.

Table of Contents

Save PDF
