Getting Started

NOTE: Make sure the PowerPad
Connecting:
• Start the instrument by pressing the
• Configure the instrument to obtain the required results and type of network.
• Connect the current leads and sensors to the PowerPad
• Connect the ground and/or neutral lead to the network ground and/or neutral (when
distributed), as well as the corresponding current sensor.
• Connect the L1 phase lead to the network L1 phase, as well as the corresponding
current sensor.
• Repeat the procedure for phases L2, L3 and N.
Disconnecting:
• Proceed in the reverse order to connecting, always finishing by disconnecting the
ground and/or neutral (when distributed).
• Disconnect the leads and press the
• Recharge the battery, if necessary.

Installation of the Leads and Current Sensors

Color-coded ID markers are supplied with the PowerPad
• Detach the appropriate inserts from the color-coded marker and place them in the holes provided
under the terminals (larger inserts for current terminals, smaller inserts for voltage terminals).
• Clip the rings of the same color to the ends of the lead that will connect to the terminal.
SD-Card
SD-Cards (up to 2GB only) are supported.
To Access the SD-Card:
• Make sure that the instrument is disconnected and off.
• Use a screwdriver or coin to unscrew the two screws of the battery compartment cover.
• Remove the cover and withdraw the battery from its compartment without disconnecting it.
• Press on the SD-Card to release it then press on the protecting tab to withdraw it from
its slot.
• When replacing the SD-Card, the contacts must be on the left side, and the locator down.
• Slide it into its slot until it snaps into place. The protecting tab is at the top of the card.
• Put the battery back in its compartment and screw the cover back on.
is fully charged before use.
®
button.
button to turn the instrument off.
®
.
®
to identify the leads and input terminals.
