Control Features
1
2
3
4
5
1.
Over molded protective housing
2.
LCD Display
3.
Six function buttons (yellow)
4.
Four function buttons (see chart, left)
5.
ON/OFF button
6.
Four current inputs and five voltage inputs
Connection Terminals
L1/A
1.
Four (4) current inputs on the top of the instrument to enable the use of current sensors (MN, SR,
AmpFlex
, MiniFlex
®
2.
Five (5) voltage inputs.
3.
Insertion locations for the current and voltage color-coded ID markers.
?
1
L2/B
L3/C
N/D
, MR, SL and J93 probes).
®
7.
USB port
8.
Input for external power supply
and battery charging
9.
Confirm/Enter button
10.
Navigation buttons
11.
Six mode buttons (see chart, left)
2
E/GND
L2/B
N/D
L1/A
L3/C
1000V CAT III
600V CAT IV
6
7
8
9
10
11
3
