EVAL-AD7903SDZ User Guide
Reference Designator Part Description
C24, C29, C32, C36, Capacitor ceramic, 50 V, C0G/NP0, 0603
C38, C39, C43, C46,
C47, C49, C55, C60,
C61, C62, C63, C68,
C69, C70, C71, C72,
C73, C76, C81
R1 Resistor, thick film, 2.4 kΩ, 0603, 100 mW, 1%
R2 SMD resistor
R3 Resistor, 0603, 35.7 kΩ
R4 SMD resistor
R5 SMD resistor
R6 Resistor, 0603, 16.9 kΩ
R7 Resistor, 0805, 12.1 kΩ, 1%
R10 Resistor, 0603, 82 kΩ, 0.063 W, 1%
R11, R13, R42, R44 SMD resistor
R12, R14, R20, R21, SMD resistor
R23, R25, R26, R36,
R38, R40, R45, R48,
R53, R56, R63, R64,
R69, R70, R71, R72
R17, R22, R32, R37, Resistor, 0805, 49.9 Ω, 0.1%, 0.125 W
R46, R47, R54, R55
R27, R28, R34, R35, Resistor, 0805, 49.9 kΩ, 1%, 0.125 W
R49, R50, R73, R74
R24, R41, R67, R68 Resistor, 22 Ω, 1% 0805
R8, R9, R15, R16, R18, Not applicable
R19, R29, R30, R31, R33,
R39, R44, R59, R60,
R61, R62, R65, R66
Manufacturer
TDK
Yageo
Multicomp
Multicomp
Multicomp
Multicomp
Multicomp
Vishay Draloric
Multicomp
Multicomp
Multicomp
Panasonic
Panasonic
Vishay Draloric
Not applicable
Rev. 0 | Page 29 of 32
Part Number Stock Code
C1608C0G1H272J Do not place
RC0603FR-072K4L Farnell 1799329
MC 0.1W 0805 1% 62K Farnell 9333436
MC 0.063W 0603 1% Farnell 1170942
35K7
MC 0.0625W 0402 1% Farnell 1803723
53K6
MC 0.0625W 0402 1% Farnell 1803137
10K2
MC 0.063W 0603 1% Farnell 1170908
16K9
CRCW080512K1FKEA Farnell 1469866
MC 0.063W 0603 1% Farnell 9331573
82K
MC 0.063W 0603 1% Farnell 9330402
100K
MC 0.063W 0603 0R Farnell 9331662
ERA6AEB49R9V Farnell 1810805
ERJ-6ENF4992V Digi-Key
P49.9KCCT-ND
CRCW080522ROFKEAHP Farnell 1738936
Not applicable Do not place
UG-609
