Chapter 2: Jumpers and Connectors
Audio Connectors
Connector type: 2x 3.5mm jack
Connector location: AUDIO1 and AUDIO2
Line-out
Mic-in
Pin
Definition
1
GND
3
MIC1_JD
5
MIC_OUT_R_C
22
LINE_OUT_L_C
24
AGND_G
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
MIC_OUT_L_C
4
AGND_P
N/A
N/A
23
LINEOUT1_JD
25
LINE_OUT_R_C
18
NEX 650-ADU User Manual
