Digital Input/Output Power Select; Jgpio_Jp Jumper - Nexcom NEX 650-ADU User Manual

Chapter 2: Jumpers and Connectors

Digital Input/Output Power Select

Connector type: 1x3 3-pin header
Connector location: JGPIO_PWR1
1 3
Pin Status
1-2 On Short
2-3 On Short
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
+12V
+5V

JGPIO_JP Jumper

Connector type: 1x3 3-pin header
Connector location: JGPIO_JP1
1 3
Pin Status
1-2 On Short
2-3 On Short
13
Settings
High
Low
