Chapter 2: Jumpers and Connectors

Panel Power Selection (LCD_VCC)

Connector type: 1x5 5-pin header
Connector location: PNL_PWR1
1 5
Pin Status
1-2 On Short
2-3 On Short
4-5 On Short
1-2 On: default
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
LVDD: +3V
LVDD: +5V
LVDD: +12V

Backlight Power Selection (LCD_BLT_VCC)

Connector type: 1x5 5-pin header
Connector location: BKT_PWR1
1 5
Pin Status
1-2 On Short
2-3 On Short
4-5 On Short LCD_BLT_VCC: DC_IN
1-2 On: default
10
Settings
LCD_BLT_VCC: +5V
LCD_BLT_VCC: +12V
