Chapter 2: Jumpers and Connectors
Front Panel Audio Header
Connector type: 2x5 10-pin header
Connector location: HD_AUDIO1
2
10
1
9
Pin
Definition
1
MIC2_L
3
MIC2_R
5
OUT2_R
7
J_SENSE
9
OUT2_L
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
GND
4
PRESENCE#
6
MIC_RET
10
OUT_RET
CPU FAN Connector
Connector type: 1x4 4-pin Wafer
Connector location: CPUF1
1
4
Pin
Definition
1
GND
2
+12V
3
CPU_FAN_SPEED
4
FAN_SPEED_CONTROL
21
NEX 650-ADU User Manual
