Chapter 2: Jumpers and Connectors
mSATA Select
Connector type: 1x2 2-pin header
Connector location: mSATA_SEL1
1
2
Pin
Status
1-2 On
Short
1-2 Off
Open
1-2 Off: default
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
For mSATA1
For SATA2
CMOS Clear Select
Connector type: 1x2 2-pin header
Connector location: CLRCMOS1
1
2
Pin
Status
1-2
Short
2-3
Short
1-2 On: default
12
Settings
Normal
Clear CMOS
NEX 650-ADU User Manual
