Chapter 1: Product Introduction
Knowing Your NEX 650-ADU
Top View
COM1 Power Select
COM2 Power Select
mSATA Select
LVDS
Chassis Intrusion
LPT
AT/ATX Select
RTC CMOS Clear
USB 3.0 Connector
Front Panel Audio
2W Audio APM Output
PCIe
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
DIMM
TPM
COM4/
Backlight
COM6
Control Level
JGPIO_JP
4
SO-DIMM
mSATA
Mini-PCIe
USB 2.0
Panel Power Select
Backlight Power Select
CPU Fan
SATA Power
Backlight Volume Control
Backlight Power
SATA2 Connectors
4-pin ATX Power
System Panel Header
USB 2.0
DI/DO
System Fan
DI/DO
Power Select
NEX 650-ADU User Manual
