Chapter 2: Jumpers and Connectors
Audio Connectors
Connector type: 3.5mm audio jack
Connector location: JAUDIO1
Line-in
Line-out
Mic-in
Pin
Definition
1
GND
3
GND
5
MIC_OUT-R
22
LINE_OUT_LC
24
LINEOUT_JD
32
LINE1-L1
34
LININ_JD
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
MIC_OUT-L
4
MIC_JD
23
GND
25
LINE_OUT_RC
33
GND
35
LINE1-R1
16
NEX 614 User Manual
