Installation
It is advised to turn off the water supply to the machine and disconnect the water supply during
these steps to make it easier to manoeuvre the machine. If you have enough working space around
you, this step is not necessary.
Safely isolate the WL2FX from the main power supply. To do this, remove the power plug from the
mains socket and unplug the other side of the power harness from the back of the machine. Place the
power lead in a safe position away from any water or trip hazard locations – It is recommended to
place in your tool bag.
For Mini Models only: Using appropriate personal protective equipment, drill 17mm hole into the
back of the machine as per below location. Take extreme caution while doing this task.
For Free Standing models only: Carefully knock through the knockout hole for the pedal wire harness
to go through. It may be necessary to enlarge the knockout hole using a 17mm drill bit for the
grommet to fit appropriately.
Fit the rubber grommet into the hole that has either been drilled for mini models or knocked out for
free standing models. The grommet is used to protect the harness as it goes through the machine.
