WaterLogic PUREZZA WL2FL FIREWALL Manual page 23

14 Solenoid Valve DC24V 500mm Mini
18 Cushion for solenoid valve
19 WL2 Mini Firewall Solenoid Valve Fixing Bracket
20 WL2FL Mini - Filter Bracket
15W UV Lamp (WL FW Brand) with 80mm wire +
21
connector
22 WL2 Firewall UV Lamp Fixing Rubber
23 Faucet UV -Spiral Quartz
WL2 Firewall Mark IV Stainless Assy (No internal
24
components)
25 JG 3/8" x 1/4" Reducing Fitting(PI211208S)
26 WL2 Firewall hot water faucet
27 WL2 Firewall PCB Cover
WL2 Firewall Display PCB
28
29 WL2FL H&C Silicone Button
30 WL2FL Light pipe for LED
WL2FL Manual Page 23 – Revision AU27-04-2023
