4-5. FUNCTIONS DESCRIPTION

1 [INPUT] + ENTER.
1-1 [Input type] + ENTER.
Select an input with
Select the video signal type with
• [SDTV Composite]: Composite video signal (Input #2 of the VSL121, #4 of the VSL241 and VSL300).
• [SDTV S.VIDEO]: S.VIDEO signal (Input #2 of the VSL121 & #4 of the VSL241 and VSL300).
• [SDTV YUV]: Component signal (Input #3 of the VSL241 and VSL300).
• [SDTV RGBS TTL]: RGBS video signal with TTL sync (Input #3 of the VSL241 and VSL300).
• [SDTV RGB SOG]: RGB video signal with Sync On Green (Input #3 of the VSL241 and VSL300).
• [SDTV RGBS ana.]: RGB video signal with analog sync (Input #3 of the VSL241 and VSL300).
• [Return]: Allows to return to the previous menu without safeguarding.
Then select the video standard (Inputs #1, 2 & 4) with
• [NTSC / PAL / SECAM]: automatic NTSC, PAL and SECAM standard detection.
• [NTSC]: NTSC standard detection only.
• [PAL]: PAL standard detection only.
• [SECAM]: SECAM standard detection only.
• [B & W 50/60 Hz]: Black and White detection.
• [Return]: Allows to return to the previous menu without safeguarding.
1-2 [Used input] + ENTER.
Select an input and then select an item with
• [used]: A signal is connected to the input.
• [unused]: No signal is connected to the input. The input is unused.
1-3 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
1-4 [Input priority] + ENTER.
Select an item with
• [none]:
• [Computer]: Priority to the Computer input. The last selected video input is automatically displayed if no
• [Video]:
• [Return]:
1-5 [Input status] + ENTER.
Indicates the status of the selected input.
+ ENTER.
+ ENTER between:
+ ENTER between:
No input priority.
signal is detected on the computer input.
Priority to Video input. The computer input is automatically displayed if no signal is detected on
the selected video input.
Allows to return to the previous menu without safeguarding.
Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued)
+ ENTER between:
+ ENTER between:
