1-6. V-SCALE PLUS GENERAL INFORMATION

V-SCALE PLUS by Analog Way combines the functions of a High Resolution Video Scaler with a Video Switcher.
It is a state of the art Scaler / Line Multiplier / Quadrupler / Doubler which significantly increases Video image
resolution and brightness.
V-SCALE PLUS is fitted with a BNC, RGB and YUV component input and a DVI output providing perfect
connection with an LCD screen, a video projector or a plasma. V-SCALE PLUS offers a double analog output on both
HD15 and DVI-I connectors. Additionally, the V-SCALE PLUS can drive up to 3 displays simultaneously. A
Computer or external input is also provided for direct display of your presentations or Internet applications.
V-SCALE PLUS features a non volatile frame memory that can be used as a "welcome " or an "alert" message. This
frame can be acquired from any video input.
The very high quality decoder includes an advanced comb filter, an emphasized "natural" color processing, a highly
robust sync. detection and a new enhanced 3D (pixel by pixel basis) auto-adaptive de-interlacing scheme (for motion
artifacts). With automatic correction of the "film to video" transfer (3/2 pulldown for NTSC), it provides a "cinema
like" image.
The frame conversion & time base correction provides high end A/V Pro & home theater solutions.
1-7. DEVICES & OPTIONS REFERENCES
REFERENCE
VSL121
VSL300
VSL241
OPT-RMK2
OPT-LAN

1-8. INSTALLATION

IMPORTANT:
• Table Top Mounting: The devices can be used directly on a table: they are equipped with 4 plastic feet.
• Rack Mounting:
IMPORTANT:
V-SCALE.
V-SCALE C
V-SCALE PLUS
Rack Mounting Kit (optional) : allows mounting 2 VSL121/VSL300 in 1U 19" rack.
IP/LAN communication port (option available with the V-SCALE PLUS only)
Please read all the safety instructions (pages 2 to 4) before starting.
The V-SCALE & V-SCALE C are compatible with a 19" enclosure (optional rack mount kit:
OPT-RMK2). To install the device into a 19" rack: Remove the 4 plastic feet, fix the tablet to
the device using the front side screw of the device and fix the supplied screw to the bottom.
Then attach the device to the rack by using 4 screws in the front panel tablet holes (screws are
not included). Connect all of the cables to the devices and attach them to the rack with some tie
wraps.
The V-SCALE PLUS is compatible with a 19" enclosure. To install the V-SCALE PLUS into
a 19" rack: Attach the V-SCALE PLUS to the rack by using 4 screws in the front panel holes
(screws are not included). Connect all of the cables to the devices and attach them to the rack
with some tie wraps.
• The openings in the rear and side panels are for cooling. Do not cover these openings.
• Be sure that no weight is added onto the device in excess of 2 kg (4.4 lbs.).
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and
local electrical codes.
Chapter 1 : INTRODUCTION (continued)
DESIGNATION
