VSL range
4-4. CONTROL MODE (continued)
The menus of the V-SCALE C are configured as follow:
1. INPUT
2. OUTPUT
3. IMAGE
4. AUDIO
5. FRAME ALERT
6. CONTROL
1. Input 1 type 1. SDTV Composite
2. SDTV S.VIDEO
3. SDTV YUV
4. SDTV RGBS TTL
5. SDTV RGB SOG
6. SDTV RGBS ana.
7. Return
2. Used Inputs 1. Video
2. Computer
3. Return
3. VCR mode 1. Off
2. On
3. Return
4. Input priority 1. None
2. Video
5. Input status
3. Computer
6. Return 4. Return
1. Output Format 1. 640x480
2. 800x600
3. 1024x768
4. 1280x1024
5. 1400x1050
6. 1600x1200
7. 852x480
8. 1280x768
9. 1366x768
10. 1280x720p
11. Return
2. Output Rate 1. Internal 50 Hz
2. Internal 60 Hz
3. Follow Input
4. Return
3. Output Sync 1. H&V
2. COMP
3. SOG
4. Return
4. Output pattern 1. OFF
2. Grid
5. Output Status
4. Return
6. Return
1. Pos/Size adj. 1. H. Position
2. V. Position
3. H. Size
4. V. Size
5. Return
2. Aspect In 1. 4/3 Standard
2. 16/9 Letterbox
3. WS Anamorphic
4. Return
3. Aspect Out 1. Standard
2. Crop
3. Full Screen
4. Return
4. Under/over
5. Brightness
6. Contrast
7. Color
8. Hue
9. Sharpness
10. Preset
11. Return
1. Auto follow
2. Input 1
3. Input 2
4. Return
1. Record Frame 1. Captured input
2. Return
2. Display Frame 1. Off
2. Auto
3. Delete Frame
3. Return
4. Return
1. Versions
2. Key locking 1. All
2. Menu
3. Input
4. Return
3. 2:2 Pull down 1. Off
2. Auto
3. Return
4. Black delay 1. Short
2. Medium
3. Long
4. Return
5. Stand-by
6. Erase memories no yes
7. Default values no yes
8. Return
Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued)
1. NTSC/PAL/SECAM
2. NTSC
3. PAL
4. SECAM
5. B&W 50/60Hz
6. Return
