Mechanical information
Emulation Adapter
Top view of the
Emulation Adapter
Ordering code
IEA-TC397XE Compact
Extender
Side view of the Extender
Top view of the Extender
Ordering code
IA292LFBGA-EXTENDER
To view Emulation Adapter schematics, visit isystem.com/schematics.
Side view of the Emulation Adapter, one Extender and Solder part (each Extender adds approx.
3,25mm)
29.1
W
17
Unit (mm)
M
Unit (mm)
N
22.4
Z
3.25
