Parcan 16 GU10D socket

Installing the Lamp

The Showtec Parcan 16 GU10D uses the GU10D (ordercode
manufacturers. Use only the appropriate lamp for your unit.
Note that, product versions that use other lamps, may be offered in the future. Check your product
specification label for information.
Always disconnect from electric mains power supply before changing lamps.
The lamp has to be replaced when it is damaged or deformed due to the heat.
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the
device was not designed for.
Damages caused by non-observance are not subject to warranty.
Procedure:
01) Disconnect the Parcan 16 GU10D from power before installing the lamp.
02) Pull the spring lever in the direction of the arrow and remove the rear cover of the lamp (Fig.03 and
Fig.04).
03) Remove the lamp from the box and hold it by the base. Read lamp instructions. Do not touch the
lamp bulb glass. Oil on hands shortens the lamp's lifespan. If you touch the bulb glass, wipe it off with
a clean, lint free towel and rubbing alcohol.
04) Insert the lamp (Fig.05).
05) Replace the rear cover of the lamp (Fig.06). Make sure that the screw at the bottom of the rear
cover fits in the hole at the bottom of the front cover.
06) The Parcan 16 GU10D is now ready to use.
Ordercode: 30115/30116
80418/80425)
Fig. 03
Fig. 05
9
as manufactured by all popular
Fig. 04
Fig. 06
