1 About these instructions
1.5

Conventions

1.5.1

Symbols, marks, notes

The following symbols, marks and notes are used in these operating instructions or
on the packaging:
Identifies a possible hazard that can result in death or serious
injuries if you fail to follow the instructions given.
Identifies a possible hazard that can result in minor injuries if you
fail to follow the instructions given.
Identifies a hazardous situation that can result in damage if you fail
to follow the instructions given.
Safety measures for persons with implants
Magnetic field warning
Note about components susceptible to ESD
ESD wrist strap
Information for understanding or optimising work processes
► Work step to be undertaken
→ page 46
Page reference to a different part of these operating instructions
1.5.2

Abbreviations and glossary

ESD
EMC
Air gap
Measuring
scale
Target wheel
MiniCODER
46
Conventions
Electro-Static Discharge
Electromagnetic compatibility
Distance between the measuring surface on the MiniCODER
and the outside diameter of the target wheel
General term for target wheel, toothed rack or slotted disc
These instructions primarily cover target wheel applications.
Similar information then applies to other measuring scales.
Tooth wheel for measuring tasks, general term: Measuring
scale
Protected name for Lenord+Bauer sensors in the product fam-
ily GEL 24xx
Lenord+Bauer
GEL 2444
