Specifications
Electrical Specifications

Table 1: SDI input waveform vertical characteristics

Characteristic
Vertical
Measurement
Accuracy
1X
5X
Gain
Variable Gain Range, Typical
Frequency Luminance
Response - Channel (Y)
HD
Chrominance
Channels (Pb,
Pr)
Frequency Luminance
Response - Channel (Y)
SD
Chrominance
Channels (Pb,
Pr)
YPbPr to RGB Conversion
Accuracy
WVR5200 Waveform Rasterizer Specifications and Performance Verification
The following tables list the specifications for the Tektronix WVR5200 Waveform
Rasterizer. Items listed in the Performance Requirement column are generally
quantitative and can be tested by the Performance Verification procedure in
Section 2 of this manual. Items listed in the Reference Information column are
useful operating parameters that have typical values; information in this column
is not guaranteed.
The specifications listed in the Electrical Specifications portion of these tables
apply over an ambient temperature range of +0 °C to +40 °C. The rated accuracies
are valid when the instrument is calibrated in an ambient temperature range of
+20 °C to +30 °C.
Performance requirement
± 0.5% of 700 mV full scale mode
± 0.2% of 700 mV full scale mode
X1, X2, X5, and X10
50 kHz to 30 MHz, ± 0.5%
50 kHz to 15 MHz, ± 0.5%
50 kHz to 5.75 MHz, ± 0.5%
50 kHz to 2.75 MHz, ± 0.5%
Reference information
Using graticule or cursor. Measure in YPbPr
mode.
0.25X to 2X, typical (variable gain multiplied
by fixed gain to get total gain).
50 kHz to 60 MHz for 1080P 60/59.94/50
formats (148.5 MHz interface sampling
frequency).
50 kHz to 30 MHz for 1080P 60/59.94/50
formats (148.5 MHz interface sampling
frequency).
0.1%, nominal
