Specifications

Table 16: Embedded audio extraction

Characteristic
Embedded
Audio
Formatting
SD
HD
Channel Numbering
Audio Rates
Number of Channels Monitored for
Presence
Maximum Number of Channels
Monitored for Activity
Audio levels

Table 17: Headphones out

Characteristic
Meter Level to Headphone Output
Gain
Digital Input to Headphone Output
Gain Accuracy over Frequency
Digital Input to Headphone Output
Distortion (THD + N), Typical
Headphone Output Power
Capability

Table 18: LCD display

Characteristic
Display Area Horizontal
Vertical
12
Performance requirement
Performance requirement
± 1.0 dB, 20 Hz to 20 kHz, 0 to –40 dBFS
Performance requirement
WVR5200 Waveform Rasterizer Specifications and Performance Verification
Reference information
24-bit Embedded audio is not supported
(no AUX bits are extracted), only 20 most
significant bits will be extracted. Supports
SMPTE 272M Operation Level B only
(48 kHz audio sampling rate synchronized
with video).
Extract 20-bit audio formatted according to
SMPTE 272M.
Extract 20 or 24 bit audio formatting
according to SMPTE299M.
Channel numbers per SMPTE 272M (1
through 16) will be correctly shown on all
displays.
Supports 48 kHz audio sample rate.
16 channels are monitored for presence.
With Simultaneous inputs or dual link
formats, 16 channels of each selected SDI
input are monitored for presence.
Can only monitor channels set up for display.
Bars display signals up to 0 dBFS.
Must not exceed maximum power
specification on analog outputs. Configure
output attenuation if necessary.
Reference information
0 dB to –63 dB in 0.5 dB steps relative to
maximum output level.
<0.05% at –10 dBFS, 20 Hz to 20 kHz, into
32 Ω.
<0.2% at full scale into 32 Ω.
<2% at full scale into 16 Ω.
Capable of continuously driving a 6.25 dBu
sinewave into 32 Ω or 16 Ω.
Reference information
13 cm
10 cm
