Table 18: LCD display (cont.)
Characteristic
Resolution
Color Palette
Pixel Defects

Table 19: External display output (EXT DISPLAY)

Characteristic
Content
Display Format
Digital Output Format
Connector
Analog Output Format
Analog Output Levels
Hot Plug Detection
DDC Function
Color Palette

Table 20: LTC time code input

Characteristic
LTC Input Connector
LTC Input Impedance
LTC Signal Characteristics
LTC Signal Amplitude Range,
Typical

Table 21: VITC decoding

Characteristic
Sources
WVR5200 Waveform Rasterizer Specifications and Performance Verification
Performance requirement
≤ 6 bad pixels
Performance requirement
Performance requirement
Performance requirement
Reference information
1024 (H) x 768 (V) pixels
6 bits per component. LSB is dithered to
improve picture.
Reference information
Identical to front-panel LCD display.
1024 (H) x 768 (V) pixels at 60 Hz (XGA)
Single link T.M.D.S.
Female DVI-I
RGB
0.7 V or 1 V for RGB signals, selectable.
Fixed 5 V for H and V sync signals.
Not supported.
Not supported.
6 bits per component.
Reference information
Balanced, unterminated via rear-panel GCI
remote connector. (See Table 27.)
Greater than 10 kΩ.
Linear Time Code per IEC Publication 461.
0.2 V to 5.0 V , balanced differential or
p-p p-p
single-ended.
Reference information
SDI input 1A, 1B, 2A, or 2B.
Specifications
13
