Alarms

Table 36: Common alarms

Alarm
HW Fault
SDI Input Missing
SDI Input Signal Lock
Reference Missing
Ref Lock
Ref Fmt Mismatch
RGB Gamut Error
Composite Gamut Error
Luma Gamut Error
Video Fmt Change
Video Fmt Mismatch
Vid/Ref Mismatch
Line Length Error
Field Length Error
EAV Place Error
SAV Place Error
Timecode Vitc Missing
Timecode Vitc Invalid
Timecode Ltc Missing
Timecode Ltc Invalid
Timecode Anc Missing
Timecode Anc Invalid
Closed Caption Missing
CC Service(s) Missing
22
The following tables list the alarms that may be set for the waveform monitors.
Description
Indicates a system fault occurred. May require service.
Indicates that no signal is detected on the selected SDI input.
Indicates unable to lock to selected SDI input signal.
Indicates that no signal is detected on the Ref input when REF EXT is selected.
Indicates unable to lock to the Ref input signal when REF EXT is selected.
Indicates that the signal format detected on Ref input differs from the configured
External Ref format.
Indicates that the selected video input signal contains colors that violate the
configured Diamond gamut thresholds.
Indicates that the selected video input signal contains colors that violate the
configured Arrowhead gamut thresholds.
Indicates that the selected video input signal contains luminance levels that violate
the configured Luma gamut thresholds.
Indicates that a change occurred in the format of the selected video input signal.
Indicates that the signal format detected on the selected video input differs from the
configured Input Format or that the format detected differs from that indicated by the
signal's SMPTE 352 payload identifier.
Indicates that the Ref signal format is not compatible with the Input signal format.
(See Table 32.) (See Table 33.) (See Table 34.)
Indicates that the length of a video line differs from that expected for the detected
video format.
Indicates that the length of a video field differs from that expected for the detected
video format.
Indicates that the location of the EAV timing reference signal differs from that
expected for the detected video format.
Indicates that the location of the SAV timing reference signal differs from that
expected for the detected video format.
Indicates that a break or discontinuity in the VITC has occurred.
Indicates that the VITC was lost for one frame but has reappeared.
Indicates that a break or discontinuity in the LTC has occurred.
Indicates that the LTC was lost for one frame but has reappeared.
Indicates that a break or discontinuity in the ANC timecode has occurred.
Indicates that the ANC timecode was lost for one frame but has reappeared.
Indicates that the configured Closed Caption Transport stream or streams are not
present in the selected video input signal.
Indicates that one or more configured EIA 608 Required Services is not present in
the closed caption data stream.
