Table 7: Arrowhead mode (NTSC/PAL composite limit display for SDI inputs) (cont.)
Characteristic
Luma Limit Detection Level
Accuracy, Typical
Luma Limit Area Threshold Range

Table 8: Spearhead HVS color space display

Characteristic
Signal to Graticule Accuracy

Table 9: Bowtie mode

Characteristic
Common SD
Mode
HD
Rejection
Ratio
Interchannel Timing Match
Functional Description
WVR5200 Waveform Rasterizer Specifications and Performance Verification
Performance requirement
Performance requirement
± 1%
Performance requirement
≥ 34 dB at 2.5 MHz
≥ 34 dB at 5 MHz
± 0.5 ns
Reference information
Detection level = ± 7 mV of cursor level,
nominal
0% to 10%
Reference information
Reference information
Displays Y minus Pr and Y minus Pb signals.
Requires bowtie signal to be useful. Null
in center indicates the channels are time
aligned.
Specifications
5
