Table 41: WVR5200 Waveform Rasterizer video performance test record (cont.)
Performance test
Input 1A
Input 1B
Input 2A
Input 2B
SDI Serial Output Amplitude
(test limits assume ±3.5% gain uncertainty in test oscilloscope)
SDI Out 270 Mb/s
SDI Out 1.5 Gb/s
SDI Out 3 Gb/s
(option 3G)

Test Record - Option AUD

Table 42: Audio option AUD test record
Instrument Serial Number:
Temperature:
Date of Calibration:
Performance test
Headphone Level Accuracy Over Frequency
Left (100 Hz)
Right (100 Hz)
Left (1 kHz)
Right (1 kHz)
Left (20 kHz)
Right (20 kHz)
28
Minimum Incoming
28 dB
28 dB
28 dB
28 dB
745 mV
745 mV
745 mV
Certificate Number:
RH %:
Technician:
Minimum Incoming
–0.75 dBu
–0.75 dBu
–0.75 dBu
–0.75 dBu
–0.75 dBu
–0.75 dBu
WVR5200 Waveform Rasterizer Specifications and Performance Verification
Outgoing Maximum
849 mV
849 mV
849 mV
Outgoing Maximum
1.25 dBu
1.25 dBu
1.25 dBu
1.25 dBu
1.25 dBu
1.25 dBu
