User Manual
Alarm ID
17
28, 29, 208,
212, 448-
479
532-547,
564-579
Alarm Name Corrective Measures
Generally, the inverter will be reconnected to the grid
after the grid returns to normal. If the fault occurs
repeatedly:
1. Measure the actual grid voltage. If grid phase vol-
tages differ greatly, contact the electric power com-
Grid Voltage
pany for solutions.
Imbalance
2. If the voltage difference between phases is within
the permissible range of the local power company,
modify the grid voltage imbalance parameter through
the App or the LCD.
3. If the fault still exists, contact SUNGROW.
1. Check whether the corresponding string is of re-
verse polarity. If so, disconnect the DC switch and ad-
just the polarity when the string current drops below
0.5 A.
PV Reverse Con-
2. If the fault still exists, contact SUNGROW.
nection Fault
*The code 28 to code 29 are corresponding to PV1 to
PV2 respectively.
*The code 448 to code 479 are corresponding to
string 1 to string 32 respectively.
1. Check whether the corresponding string is of re-
verse polarity. If so, disconnect the DC switch and ad-
just the polarity when the string current drops below
0.5 A.
PV Reverse Con-
2. If the alarm still exists, contact SUNGROW.
nection Alarm
*The code 532 to code 547 are corresponding to
string 1 to string 16 respectively.
*The code 564 to code 579 are corresponding to
string 17 to string 32 respectively.
