Product Specifications

Hardware Specifications
Hardware Specifications
802.11n
802.11ac
802.11ax
Four spatial streams
● Radio 1 – 2.4 GHz: 2x2 MIMO, two spatial streams
● Radio 2 – 5 GHz: 2x2 MIMO, two spatial streams
Channels:
● Radio 1 – 2.4 GHz: 20 MHz and 40 MHz
● Radio 2 – 5 GHz: 20 MHz and 40 MHz
Combined peak data rate: 600Mbps
● Radio 1 – 2.4 GHz: 6.5 Mbps to 300 Mbps (MCS0 to MCS15 )
● Radio 2 – 5 GHz: 6.5 Mbps to 300 Mbps (MCS0 to MCS15)
Radio technologies: Orthogonal Frequency-Division Multiplexing (OFDM)
Modulation types: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
Packet aggregation:
● Aggregate MAC Protocol Data Unit (A-MPDU)
● Aggregate MAC Service Data Unit (A-MSDU)
Dynamic Frequency Selection (DFS)
Cyclic Delay/Shift Diversity (CDD/CSD)
Maximum Ratio Combining (MRC)
Space-Time Block Coding (STBC)
Low-Density Parity Check (LDPC)
Transmit beam-forming (TxBF)
Two spatial streams
● Radio 2 – 5 GHz: 2x2 MIMO, two spatial streams
Channels:
● Radio 2 – 5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz
Combined peak data rate: 1.732 Gbps
● Radio 2 – 5 GHz: 6.5 Mbps to 1.732 Gbps (MCS0 to MCS9)
Radio technologies: Orthogonal Frequency-Division Multiplexing (OFDM)
Modulation types: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
Packet aggregation:
● Aggregate MAC Protocol Data Unit (A-MPDU)
● Aggregate MAC Service Data Unit (A-MSDU)
Dynamic Frequency Selection (DFS)
Cyclic Delay/Shift Diversity (CDD/CSD)
Maximum Ratio Combining (MRC)
Space-Time Block Coding (STBC)
Low-Density Parity Check (LDPC)
Transmit beam-forming (TxBF)
Four spatial streams
● Radio 1 – 2.4 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams
● Radio 2 – 5 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams
Channels:
● Radio 1 – 2.4 GHz: 20 MHz and 40 MHz
● Radio 2 – 5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz
Combined peak data rate: 2.976 Gbps
● Radio 1 – 2.4 GHz: 8.6 Mbps to 0.574 Gbps (MCS0 to MCS11)
● Radio 2 – 5 GHz: 8.6 Mbps to 2.402 Gbps (MCS0 to MCS11)
