Product Appearance - Ruijie Reyee RG-NBS6002 Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
1.1 RG-NBS6002 Switch
1.1.1 Package Contents
Table 1-1 Package Contents
Item
Chassis
Power supply module filler panel
Service module filler panel
M4 x 10 mm screw
M4 x 8 mm screw
Foot pad
Mounting bracket
Yellow/green ground cable
Warranty Card
User Manual
Product management software of Ruijie Networks
Instruction
●
The preceding table lists items delivered in normal cases. The actually delivered items may vary with the
contract. Carefully check your goods against the package contents or contract. Contact the seller if you
have any questions or find any errors.
1.1.2

Product Appearance

The hardware of an RG-NBS6002 switch consists of the chassis, power supply system, system modules, and
heat dissipation system.
Power supply system: Provides two power supply module slots and supports 1+1 power redundancy. It is
recommended to configure power redundancy.
System modules: Provides two service module slots. All service modules can be configured in either of the two
slots. You can select different service modules based on actual application requirements.
Figure 1-1 RG-NBS6002 Switch Appearance (Service Module Combination of M6000-24GT2XS and
M6000-24SFP2XS)
Front View
Quantity
1
1
1
1
8
4
2
1
1
1
1
2
