Hardware Installation and Reference Guide
Note
●
Reset button: When you press and hold the reset button for less than 2 seconds, all modules are reset.
When you press and hold the reset button for more than 5 seconds, all modules are reset, the initial
password is restored, the supervisor module is restored to factory settings, and the configuration backup
file is saved. If you log in to the web-based management system after a restart, you can select Delete
Backup or Restore Backup (the password is the default password). If you do not log in, factory settings
are used for the supervisor module. When you press and hold the reset button for 2s to 5s, no operation
is performed. The preceding events are executed after you release the re set button.
1.1.5

Technical Specifications

Table 1-2 Technical Specifications of an RG-NBS6002 Switch
Product
Model
CPU
Flash
Memory
SDRAM
Module Slot
Service
Module
Hot Swapping
Power Supply
Module
Power Supply
Redundancy
Fan Module
Certificate
Altitude
Off: The system is not powered on.
RG-NBS6002
Embedded CPU, single-core processor, and clock speed of 1 GHz
256 MB
DDRIII 1 GB
Two service module slots
M6000-24GT2XS
M6000-24SFP2XS
M6000-16GT8SFP2XS
M6000-16SFP8GT2XS
Power supply modules support hot swapping, while service modules do not.
RG-PA150I-FS: 100 V to 240 V; Power: 150 W
Supported (Power supply modules of the same model must be used.)
Fixed fans
CE
At 3000 m (3.11 miles) above sea level, the maximum operating temperature is 50° C
(122° F). Every time the altitude increases by 220 m (721.78 ft.), the maximum
operating temperature is decrease by 1° C (1.8° F).
Operating altitude: up to 5000 m above sea level (3.11 miles)
Storage altitude: up to 5000 m above sea level (3.11 miles)
6
Product Overview
