iC7 Series PROFINET
Operating Guide
Bit num- Name
ber
8 Jog 1
9 Jog 2
10 Control by PLC
11 Reserved
12 User defined
13 User defined
14 User defined
15 User defined

2.4.2 Status Word (STW) in PROFIdrive Standard Telegram 1

Table 8: Status Word Bits in PROFIdrive Standard Telegram 1
Bit Name
Num-
ber
0 Ready to switch on
1 Ready to operate
2 Operation enabled
3 Operation fault
4 Coast stop
5 Quick stop
6 Switching on inhibi-
ted
7 Warning
Danfoss A/S © 2023.06
Description
0 = No function.
1 = Jog 1 on.
0 = Jog 1 off.
Operation is enabled, drive is in standstill and STW1 bit 4, 5, 6 = 0. The drive runs up along the ramp
to jogging setpoint 1.
1 = Jog 2 on.
0 = Jog 2 off.
Operation is enabled, drive is in standstill and STW1 bit 4, 5, 6 = 0. The drive runs up along the ramp
to jogging setpoint 1.
1 = Uses the process data (control by PLC).
0 = Ignores the current process data. This is linked to the submodule where the CTW is present. If
signals are to be covered, the CTW/STW profile (for example, the iC Speed Profile) must be part of
the signals list.
Reserved for future use.
These bits enable mapping application functionality of the drive to the control word. Mapping is
done through parameters. For more information, refer to the application guide.
Description
1 = Ready to switch on.
0 = Not ready to switch on.
1 = Ready to operate.
0 = Not ready to operate.
1 = Operation enabled.
0 = Operation disabled.
1 = Fault present.
0 = No fault.
1 = Coast stop not activated (No OFF2).
0 = Coast stop activated (OFF2).
1 = Quick stop not activated (No OFF3).
0 = Quick stop activated (OFF3).
1 = Switching on inhibited.
0 = Switching on not inhibited.
1 = A warning has occurred.
Product Overview
AQ408626183394en-000101 / 136R0280 | 13
