iC7 Series PROFINET
Operating Guide

4 PROFINET Configuration

4.1 Configuring the Ethernet Interface

The X1 and X2 interfaces are internally connected with an Ethernet switch and share the same physical MAC layer, and the same IP
settings apply to both interfaces.
IPv4 settings are configured in MyDrive
1. Configure IPv4 settings.
- In MyDrive Insight, go to Setup and Service → Interface configuration → Interface X1/X2 → IPv4 settings.
®
- In the control panel, navigate to parameter group 10.2 Communication Interfaces.
Table 10: IPv4 Settings
Function
Interface X1/X2
MAC address
IPv4 addressing
method
Requested IPv4
address
Requested IPv4
subnet mask
Requested IPv4
gateway address
Enable ACD
DNS server 1, 2

4.2 Configuring PROFINET Name of Station

1.
Navigate to parameter 10.3.2.2.1 Name of Station.
Table 11: PROFINET Configuration, Name of Station
Menu in- Parame-
dex ter name
10.3.2.2.1 Name of
Station
Danfoss A/S © 2023.06
Insight or in the control panel.
®
Value Description
00:1B:08:xx:xx:xx The MAC address of interface X1/X2. The value is read-only.
Disable Only link-local IP address in the 169.254.xxx.xxx range is active.
Static IP A static IP address is entered manually.
Automatic IP address is assigned via a DHCP or BOOTP server.
DCP (default) DCP is used with PROFINET where a PLC assigns the IP address, subnet
mask and other relevant parameters.
xxx.xxx.xxx.xxx If Automatic is selected as the IPv4 addressing method and no DHCP/
BOOTP server is present, the X1/X2 interface automatically configures an IP
address and subnet mask in the 169.254.xxx.xxx range.
xxx.xxx.xxx.xxx The requested IPv4 subnet mask for the interface.
xxx.xxx.xxx.xxx Requested IPv4 gateway address for the interface.
Enable/disable (de- Request to enable or disable Address Conflict Detection for the interface.
fault)
The change will not take effect before a power cycle is performed. If no
conflicts are detected, ACD activity displays 0. If an address conflict occurs,
the ACD activity will display 1, and the IPv4 interface will revert to an auto-
matically assigned IP address in the 169.254.xxx.xxx range.
Recommended setting for PROFINET is disabled.
xxx.xxx.xxx.xxx The user-requested Domain Name Server 1 for the interface (for manual IP
addressing mode only).
Parame- Value
ter num-
ber
7080 Accepted characters:
PROFINET Configuration
Additional informa-
tion
Each PROFINET de-
vice is identified with
a unique Name of
Station.
AQ408626183394en-000101 / 136R0280 | 23
