Data Flash Strobe
Description of the device
Features
The Data Flash Strobe is a compact LED strobe with an intense strobe effect. It has 8 sections which can
be used for creating dynamic strobe effects.
8 controllable sections
•
Double mounting bracket
•
Pro power connections
•
Input voltage: 110-240V AC, 50/60Hz
•
Power consumption: 120W
•
DMX channels: 12 channels
•
LED display for easy setup
•
Light source: SMD LEDS
•
Control modes: Auto, Built-in Programs, Sound-controlled, Master/Slave, DMX
•
Control protocol: DMX-512
•
Dimmer: 0-100%
•
•
Strobe: 0-20Hz
Protection rate: IP-20
•
Housing: Aluminum
•
Cooling: Convection
•
Connections: PowerCON IN/OUT & 3-pin XLR IN & OUT
•
•
Dimensions: 263 x 83 x 293 mm (LxWxH)
Weight: 2,60 kg
•
Frontside
01) 8 sections SMD LEDS
02) Adjustment screw
03) Mounting bracket
Ordercode: 40296
7
Fig. 01
